7
TVC-FA301N
Installation Manual
Ver 1.15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVC-FA301N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TVLogic TVC-FA301N

Summary of Contents for TVLogic TVC-FA301N

  • Page 1 TVC-FA301N Installation Manual Ver 1.15...

  • Page 2: ① Camera Address [Id] Setup

    Camera Setup ① ② ③ ④ Communication Type Output Power ① CAMERA ADDRESS [ID] SETUP Change the Camera ID as shown below. - Up to 15 addresses can be set to control multiple cameras. ※ Do not use number 0. - Factory default is set to 1.

  • Page 3: Protocol Setup

    ② PROTOCOL SETUP Change the communication protocol as shown below. : Factory Default Protocol BAUD RATE Switch 9600 bps VISCA 38400 bps 2400 bps PELCO-D 9600 bps 38400 bps 4800 bps PELCO-P 9600 bps - Set the protocol correspond to the controller. - Be sure to change the protocol while the power is off.

  • Page 4: ④ Communication Setup

    ④ COMMUNICATION SETUP (OFF: ↑ ON:↓ Select RS-422 or RS-232C by using ON/OFF DIP switch no.1 and COMMUNICATION RS-422 RS-232C MEMO...

  • Page 5: Bracket Installation

    Bracket Installation Fix the bracket to the bottom of the camera with screws (4EA). Ceiling type Wall mount type Fix the camera into the ceiling bracket. Fix the camera into the wall mount bracket. Loosen slightly a hexagon screw and use. Fix the camera using the 4 screws on both sides of the bracket.

  • Page 6: Camera Connection

    CAMERA CONNECTION ● RS-232C VISCA Connector (MINI DIN 8PIN, FEMALE) PIN NO. VISCA IN VISCA OUT DTR IN DTR OUT DSR IN DSR OUT TXD IN TXD OUT RXD IN RXD OUT NOT CONNECTED NOT CONNECTED NOT CONNECTED NOT CONNECTED SAMPLE TVR-200H...
  • Page 7 ● RS-422 CONNECTOR PIN NO. RS-422 TXD IN+ TXD IN- RXD IN+ RXD IN- TXD OUT+ TXD OUT- RXD OUT+ RXD OUT- SAMPLE TVR-200H...
  • Page 8  RJ-45 CONNECTOR PIN NO. RJ-45 RXD OUT+ RXD OUT- TXD OUT+ RXD IN+ RXD IN- TXD OUT- TXD IN+ TXD IN- SAMPLE...
  • Page 9 RS-422 CONNECTION (TVR-200H)  TVC-FA301N RS-422 Connection 1. Check : a) Camera Firmware Ver. : 2.00 or higher b) Additional Camera Type (end with B) 2. DIP switch no.5 has to be set to ON. (on the bottom of the camera) 3.
  • Page 10  422 connection wtih RJ-45 connector from TVR-200H controller. 1. Check : a) Camera Mech Firmware Ver. 2.00 or higher b) Additional Camera Type B 2. DIP switch no.5 has to be set to ON. (on the bottom of the camera) 3.
  • Page 11  422 connection of 4 cameras with RJ-45 connector from TVR-200H controller. See page 11 for more detail.
  • Page 12  RJ-45 Connector ⇦⇨ 9P Connector connection diagram. MEMO...
  • Page 13  TVC-FA301N camera & TVR-200H setup check 1. Set each camera's ID and Protocol 0 (ex: VISCA, 9600) and set the Communication 1 dip switch up. 2. Setup and connecting of TVR-200H Press and hold the MENU button on the bottom of the LCD screen to set the Baudrate and Interface values using the joystick.
  • Page 14 Refer to page 15 for more information. 1. Set the camera ID, protocol and communication as shown below. ● RS-232C Connection between TVC-FA301N and TVR-200H Press and hold the MENU button on the bottom of the LCD screen to select Baudrate 9600, Interface...
  • Page 15 See page 15 for more detail. See page 15 for more detail.
  • Page 16 1. 232C-LAN cable connection diagram between the cameras. (* It differs from normal network cable formation) * If you only want to connect the camera using the network direct line, use the optional KTM-100. Configuration of camera and camera control line using 2 LAN cables 2) Using 1 LAN cable divided into 4 lines for camera and control line.
  • Page 17 2. KTM-100 (Optional Product) Main purpose of this product is to quickly respond to control lines and camera problems. If you installed the camera, display, and control lines into the control room, using KTM-100 would make the connection easier. For RS-232C connection, with supplied LAN gender, up to 7 cameras can be installed in a simple way by connecting KTM-100 to the camera using "Direct"...

  • Page 18: Installation Check

    Installation Check 1. Before applying power, make sure that there is no abnormality in wiring. 2. Make sure to change the camera and controller settings (protocol and video output format, etc.) while the power is off. 3. Check that the communication between the camera and the controller (RS-232C, RS422) match. 4.
  • Page 19 MEMO...
  • Page 20 FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.tv 12F, ACE HIGH-END 8, 84 Gasan digital 1-ro, Geumcheon-gu, Seoul, 153-802, KOREA TEL : +82-70-8668-6611, FAX : 82-2-6123-3201, E-mail : sales@tvlogic.co.kr...
