Related Manuals for Kia SOUL 2016

Summary of Contents for Kia SOUL 2016

  • Page 2 Kia, THE COMPANY Thank you for becoming the owner of a new Kia vehicle. As a global car manufacturer focused on building high-quality vehi- cles with exceptional value, Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations.
  • Page 3 Thank you for choosing a Kia vehicle. The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the right to When you require service, remember that your Kia dealer discontinue or change specifications or design at any time knows your vehicle best.

  • Page 4: How To Use This Manual

    How To Use This Manual We want to help you get the greatest You will find various types of safety possible driving pleasure from your instructions in this manual. These vehicle. Your Owner’s Manual can instructions were prepared assist you in many ways. We strong- enhance your personal safety.

  • Page 6: Table Of Contents

    Electric Vehicle Guide Review of Electric Vehicle / High voltage battery / Charge / Driving Electric Vehicle / Etc. Introduction Vehicle data collection and event data recorders Your vehicle at a glance Exterior overview / Interior overview / Instrument panel overview / Motor room compartment Safety features of your vehicle Seats / Seat belts / Child restraint system / Air bag Features of your vehicle...
  • Page 7 Review of Electric Vehicle ............2 Main Components of Electric Vehicle........4 High voltage battery ..............5 EV Mode ..................7 ■ Available Range ..............7 ■ Near by stations ..............8 ■ Energy Information .............8 ■ ECO Driving ...............9 ■ Setting Charging Times.............9 ■ Setting Climate Times ............10 ■...

  • Page 8: Review Of Electric Vehicle

    REVIEW OF ELECTRIC VEHICLE Review of Electric Vehicle Characteristics of Electric Vehicles An electric vehicle is driven using a 1. It is driven using the electrical ener- Note battery and an electric motor. While gy that is stored inside the high general vehicles use an internal voltage battery.
  • Page 9 REVIEW OF ELECTRIC VEHICLE Battery Information • The vehicle is composed of a high voltage battery that drives the motor and air-conditioner, and an auxiliary battery (12 V) that drives the lamps, wipers, and audio sys- tem. • The auxiliary battery is automati- cally charged when the vehicle is in the ready ( ) mode or the high...

  • Page 10: Main Components Of Electric Vehicle

    MAIN COMPONENTS OF ELECTRIC VEHICLE Main Components of Electric Vehicle • High voltage battery (lithium- ion polymer) : Stores and sup- plies power necessary for the High Voltage electric vehicle to operate (12 V Junction Block auxiliary battery provides power to the vehicle features such as lights and wipers).
  • Page 11 • The charge amount of the high volt- recommend that you contact an age battery may gradually decrease authorized Kia dealer for inspec- when the vehicle is not driving. tion and maintenance. • The battery capacity of the high •...

  • Page 12: High Voltage Battery

    SOC 0% on recommend that you contact an operation. cluster gauge. If the vehicle is authorized Kia dealer to inspect kept at SOC 0% for a long peri- whether the high voltage battery The high voltage battery warmer sys- od, it may damage the high is still connected.

  • Page 13: Ev Mode

    EV MODE EV Mode (if equipped) ■ ■ Available Range The EV mode has a total of 6 menus including Available Range, Near by OPSE0Q4003N stations, Energy information, ECO Name Description If you select the "EV" menu at the driving, Set timings for Charging Reachable area Green Circle AVN home screen or press the "EV"...

  • Page 14: Near By Stations

    EV MODE ■ ■ Near by stations ■ ■ Energy Information Power Consumption Stations around the current location You can check battery information Power that is consumed by the is searched. Depending on the sym- and power consumption. drive system, climate and electri- bol color of the station, it is catego- cal components are displayed rized as Reachable area, Risky area...

  • Page 15: Eco Driving

    EV MODE ■ ■ ECO Driving ■ ■ Set Charging Times Driving History You can check ECO level information This is a feature that starts charging You can check the driving date and ECO driving history. the battery on the date and time that driving distance , and the aver- is designated by the user.
  • Page 16 EV MODE ■ ■ Set Climate Times Setting is saved and setting informa- Description tion is displayed on the screen. This is a feature that automatically When selecting the list again, change starts climate control on the reserved the setting. Description day and time along with the tempera- If you do not want use the reserved...

  • Page 17: Ev Setting

    EV MODE – Destination Unreachable Warning : If the destination set in the navigation cannot be reached with the remaining bat- tery charge, a warning message is displayed. ■ ■ EV Setting EV Route Settings You can change the EV warning alarm. Displays the EV route on the map.

  • Page 18: Charge Types For Electric Vehicle

    CHARGE TYPES FOR ELECTRIC VEHICLE Charging Information Charging Time Information • Normal Charge : Depending on the condition and dura- • Normal Charge : bility of the high voltage battery, charg- We recommend using normal Takes about 4-5 hours at room tem- er specifications, and ambient temper- charging for usual charging of the perature (depending on charger ) for...
  • Page 19 CHARGE TYPES FOR ELECTRIC VEHICLE Charging Types Charging Inlet Category Charging Connector Charging Outlet How to Charge Charging Time (Vehicle) Approx. 4-5 hours Use the normal (208V - 5.5kW: 5h charger that is Normal 10min, 240V - 6.3kW: installed in your 4h 30min.

  • Page 20: Charge Indicator Lamp For Electric Vehicle

    CHARGE INDICATOR LAMP FOR ELECTRIC VEHICLE Charging Status Information ■ ■ Normal charging and trickle ■ ■ Quick charge charging Operation of Charging Operation of Charging Indicator Lamp Indicator Lamp Details Details (OFF) (OFF) (OFF) Not Charged (OFF) (OFF) (OFF) Not Charged Blinking (OFF)

  • Page 21: Reserved Charging

    RESERVED CHARGING Reserved Charging (if equipped) • You can set-up a charging sched- • When reserved charging is set, charging is not initiated immedi- ule for your vehicle through the UVO audio control unit, the UVO ately when the normal charger or EV Services App, or by logging portable charging cable (ICCB: In- into MyUVO.com.
  • Page 22 RESERVED CHARGING After Deactivate Reserved Charge button [ ] has been pressed (pressed position), you can charge the battery at any given time. To change the status to reserved charging, please press Deactivate Reserved Charge button [ ] again (not pressed position). ❈...

  • Page 23: Reserved Climate Control

    RESERVED CLIMATE CONTROL Reserved Climate Control (if equipped) ❈ Lamp ON Conditions • You can set reserved climate con- trol using the AVN. 1. Blinks three times: When you Refer to the AVN for detailed infor- press the set button and enter the AVN reserved climate control set- mation about the reserved climate control setting.

  • Page 24: Precautions For Charging Electric Vehicle

    PRECAUTIONS FOR CHARGING ELECTRIC VEHICLE Charging Precautions ■ Normal Charger WARNING WARNING - Fires caused - Interference by dust or water with electronic medical devices Do not connect the charging cable connector plug to the When using medical electric vehicle if there is water or dust devices such as an implantable charging inlet.
  • Page 25 PRECAUTIONS FOR CHARGING ELECTRIC VEHICLE • Comply with the following in order WARNING WARNING - Touching the - Charging to prevent electrical shock when charging connector cable charging: Do not to touch the charging • Immediately stop charging – Use a waterproof charger. connector, charging plug, and when find...
  • Page 26 PRECAUTIONS FOR CHARGING ELECTRIC VEHICLE • Always keep the charging connec- WARNING - Cooling fan tor and charging plug in clean and dry condition. Be sure to keep the Do not touch the cooling fan charging cable in a condition while vehicle is charging.

  • Page 27: Charging Electric Vehicle (Normal Charge)

    CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) Normal Charge 3. Press the charging door open ■ Normal Charger switch [ ] to open the charging door. Charging door open switch can be operated only when vehi- cle is turned off. 4. If you cannot open the charging door due to freezing weather : 1) Remove any ice near the charg- ing door.
  • Page 28 CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) CAUTION - Charging Connector Door To avoid damage to your vehi- cle, do not attempt to connect the charging connector to your vehicle without first opening the door to the charging connector. OPSE0Q4012 OPSE0Q4013 5. Open the charging door and press 7.
  • Page 29 CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) • You can start charging when the Power button is in the OFF posi- tion and the shift lever is in P (Park). After charging has started, you can use electrical compo- nents such as the radio by press- ing the Power button to the ACC or ON position.

  • Page 30: Unlock Charging Door In Emergency

    CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) Depending on the condition and 11.You may prevent possible charg- durability of the high voltage battery, ing cable theft by taking the fol- charger specifications, and ambient lowing steps. Lock the door after temperature, the time required for the charging cable is connected, charging the battery may vary.

  • Page 31: Emergency Release Of The Charging Connector Lock System

    CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) Operation of Charging Indicator Lamp Details (OFF) (OFF) (OFF) Not Charged Blinking (OFF) (OFF) 0~33% (ON) Blinking (OFF) Charging 34~66% (ON) Blinking 67~99% (ON) Charging complete (ON) (ON) (ON) (100%)(turns OFF OPSE075034 OPSE0Q4008 in 3 seconds) ■...
  • Page 32 CHARGING ELECTRIC VEHICLE (NORMAL CHARGE) CAUTION In order to disconnect the charging connector, release the door lock to unlatch the charg- ing connector lock system. If not, the charging connector and the vehicle's charging inlet may be damaged. 2. Hold the charging connector han- OPSE0Q4034 dle and pull it while pressing the ■...

  • Page 33: Charging Electric Vehicle (Quick Charge)

    CHARGING ELECTRIC VEHICLE (QUICK CHARGE) Quick Charge (if equipped) ❈ If you use a quick charger when ■ Quick Charger vehicle already fully charged, some quick chargers will send out an error message. When the vehicle is fully charged, do not charge the vehicle.
  • Page 34 CHARGING ELECTRIC VEHICLE (QUICK CHARGE) 3. Press the charging door open switch [ ] to open the charging door. Charging door open switch can be operated only when vehi- cle is turned off. 4. If you cannot open the charging door due to freezing weather : 1) Remove any ice near the charging door.
  • Page 35 CHARGING ELECTRIC VEHICLE (QUICK CHARGE) ❈ Refer to the manual for each type 9. If you charge a second time after the initial quick charge (up to of quick charger for how to charge and remove the charger. 83%), it will charge up to 94%. (Takes an additional 15 minutes at ❈...

  • Page 36: Unlock Charging Door In Emergency

    CHARGING ELECTRIC VEHICLE (QUICK CHARGE) ❈ During cold weather, quick charg- ing may not be available to prevent high voltage battery degradation. • You can start charging when the Power button is in the OFF posi- tion and the shift lever is in P (Park).

  • Page 37: How To Disconnect Quick Charger

    CHARGING ELECTRIC VEHICLE (QUICK CHARGE) Operation of Charging CAUTION Indicator Lamp Details Depending on the condition and durability of the high voltage battery, charger specifications, (OFF) (OFF) (OFF) Not Charged and ambient temperature, the Blinking (OFF) (OFF) 0~33% time required for charging the (ON) Blinking (OFF) Charging...
  • Page 38 CHARGING ELECTRIC VEHICLE (QUICK CHARGE) CAUTION - Disconnecting charging plug When disconnecting the charg- ing connector, do not try to dis- connect it by force while not pressing the release button. This may damage the charging connector and vehicle charging inlet.

  • Page 39: Charging Electric Vehicle (Trickle Charge)

    CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) Trickle Charge Charging Connector Control Box Code and Plug Charging Cable (code set) Plug Electric Outlet OPSE0Q4021 OPSE0Q4022N OPSE0Q4023 ■ ■ How to Connect Portable Trickle Charge can be used when 2. Check if every LED lamp on the Normal Charge or Quick Charge is Charging Cable control box is turned on for 0.5...
  • Page 40 CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) 5. Press the charging door open switch [ ] to open the charging door. Charging door open switch can be operated only when vehi- cle is turned off. 6. If you cannot open the charging door due to freezing weather : 1) Remove any ice near the charg- ing door.
  • Page 41 CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) CAUTION - Charging Connector Door To avoid damage to your vehi- cle, do not attempt to connect the charging connector to your vehicle without first opening the door to the charging connector. OPSE0Q4013 OPSE0Q4044 9. Open the protective cover of the 11.Charging starts automatically.
  • Page 42 CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) • You can start charging when the Power button is in the OFF posi- tion and the shift lever is in P (Park). After charging has started, you can use electrical components such as the radio by pressing the Power button to ACC or ON posi- tion.

  • Page 43: Unlock Charging Door In Emergency

    CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) Depending on the condition and 14.You may prevent possible charg- durability of the high voltage battery, ing cable theft by taking the fol- charger specifications, and ambient lowing steps. Lock the door after temperature, the time required for the charging cable is connected, charging the battery may vary.

  • Page 44: Emergency Release Of The Charging Connector Lock System

    CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) Operation of Charging Indicator Lamp Details (OFF) (OFF) (OFF) Not Charged Blinking (OFF) (OFF) 0~33% (ON) Blinking (OFF) Charging 34~66% (ON) (ON) Blinking 67~99% Charging complete (100%)(turns OFF (ON) (ON) (ON) OPSE0Q4008 OPSE075034 in 3 seconds) ■...

  • Page 45: Charging Status Indicator Lamp For Portable Charging Cable

    OPSE0Q4048 Stop charging immediately when a leak is detect- Detects Leakage ed on the ICCB output terminal (we recommend that you contact an authorized Kia dealer) Failure When a failure is detected inside the ICCB (we ICCB Failure recommend that you contact an authorized Kia...

  • Page 46: How To Disconnect Portable Charging Cable (Iccb: In-Cablecontrol Box)

    CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) 2. Hold the charging connector han- CAUTION dle and pull it while pressing the release button (1). In order to disconnect the charging connector, release the door lock to unlatch the charg- CAUTION - Disconnecting ing connector lock system.
  • Page 47 CHARGING ELECTRIC VEHICLE (TRICKLE CHARGE) Plug Electric Outlet OPSE0Q4022N 5. Disconnect the plug from the household electric outlet. Do not pull the cable when disconnecting OPSE0Q4015 the plug. 3. Make sure to completely close the 6. Close the protective cover for the normal charging inlet cover.
  • Page 48 • Use the portable charging cable • If the ICCB case and normal damaged household electric outlet that is certified by Kia Motors. charging connector is damaged, can result in a risk of electric • Do not try to repair, disassemble, cracked, or the wires are exposed shock.

  • Page 49: Driving Electric Vehicle

    DRIVING ELECTRIC VEHICLE How to Start the Vehicle 5. Make sure the accelerator and brake pedal have clearance with your right foot. 6. Make sure to press and hold the brake pedal. 7. While pressing the brake pedal, place the shift lever in P (Park). Vehicle only starts when the shift lever is placed in P (Park).

  • Page 50: How To Stop The Vehicle

    DRIVING ELECTRIC VEHICLE How to Stop the Vehicle ❈ For vehicles with Shift Lock, you have to press the POWER button to the ON position, press and hold the brake pedal, then press the unlock button on the shift lever while it is placed in P (Park) in order to move the shift lever to R (Reverse).

  • Page 51: Pedestrian Warning System

    DRIVING ELECTRIC VEHICLE Pedestrian Warning System Active ECO system • When the Active ECO is activated, The Pedestrian Warning System it will remain on until the Active generates engine sound for pedestri- ans to hear vehicle sound because ECO button is pressed again. there is little sound while the Electric Active ECO does not turn off when Vehicle (EV) is operating.

  • Page 52: Range

    DRIVING ELECTRIC VEHICLE Range After “---” has been displayed, the vehi- Natural degradation may occur with the high voltage battery depending cle can drive an additional 3.1~9.3mi. (5~15km) (depending on driving on the number of years the vehicle is speed, heater/air conditioner, weather, used.

  • Page 53: Tips For Improving Distance To Empty

    DRIVING ELECTRIC VEHICLE Tips for Improving Distance Motor Operation Gauge to Empty • If you operate the air conditioner • POWER : It shows the energy /heater too much, the driving battery consumption rate of the vehicle uses too much electricity. This may when driving uphill or accelerat- reduce the distance to empty.

  • Page 54: State Of Charge (Soc) Gauge For High Voltage Battery

    DRIVING ELECTRIC VEHICLE State of charge (SOC) gauge for high voltage battery When there are 1-2 gauge bars left for the high voltage battery, the vehi- cle speed is limited and then eventu- ally the vehicle will be turned OFF. Charge the vehicle immediately.

  • Page 55: Warning Message On Lcd Display (Related To Charge)

    DRIVING ELECTRIC VEHICLE Warning Message on LCD Display (related to charge) ■ ■ Low Battery ■ ■ Low Battery. Charge imme- ■ ■ Charge immediately. Power diately limited OPSE044213L OPSE044214L OPSE044215L When the high voltage battery level When the high voltage battery level When the high voltage battery level reaches below 20%, this warning message illuminates.
  • Page 56 DRIVING ELECTRIC VEHICLE ■ ■ Power limited ■ ■ Unplug vehicle to start • When this warning messages is displayed, do not accelerate or start the vehicle suddenly. • Charge the battery immediately when the high voltage battery level is not enough. OPSE044223L OPSE044264L When the vehicle is started while the...
  • Page 57 DRIVING ELECTRIC VEHICLE ■ ■ Charging Door Open ■ ■ Charger Error! ■ ■ Quick Charger Error! OPSE045323L OPSE045324L OPSE044224L When the vehicle is started while the This message is displayed when the This message is displayed when the charging door is opened, this warn- charging failed by external normal charging failed by external quick ing message illuminates.

  • Page 58: Warning Lamp And Indicator Lamp (Related To Electric Vehicle)

    When the warning light turns an authorized Kia dealer rupting normal driving. ON while driving, or does not turn OFF after vehicle has started, have your vehicle inspected by an authorized Kia dealer.
  • Page 59 (yellow) to turn ON simultaneously. In this case, drive safely and have your vehicle inspected by an authorized Kia dealer. In this case, operation of the brake pedal may be more difficult than normal and the braking distance...
  • Page 60 DRIVING ELECTRIC VEHICLE ■ ■ ECOMINDER ® indicator Active ECO system This indicator light illuminates: • The Active ECO system always remembers the previous status before the vehicle was turned off. • When the Active ECO button is ® pressed the ECOMINDER indica- tor (green) will illuminate to show that the Active ECO is operating.

  • Page 61: Safety Precautions For Electric Vehicle

    SAFETY PRECAUTIONS FOR ELECTRIC VEHICLE Responding to Vehicle Accidents in your Electric Vehicle When a vehicle accident occurs, WARNING WARNING - Damaged - Vehicle fires move the vehicle to a safe place, turn battery OFF the vehicle and remove the aux- iliary battery (12 V) terminal to pre- Do not touch harmful gas and vent high voltage electricity from...
  • Page 62 OPSE0Q4054 Contact the fire department or an If towing is required, lift all four authorized Kia dealer. wheels off the ground and tow the vehicle. If you must tow the vehicle using only two wheels, lift the front wheels off the ground and tow the vehicle.
  • Page 63 If heat treatment is required, we This may damage the electric recommend that you contact an power system. authorized Kia dealer. WARNING - Damaging Battery OPSE0Q4053 When you clean the motor com- • An air inlet is installed under the...

  • Page 64: Service Plug

    OPSE0Q4042 dioxide (a major cause of global OPSE0Q4033L warming). This also helps curb the Kia Motors 'Soul Electric Vehicle' uses depletion of oil resources. eco-friendly bioplastics, fiber, and WARNING - Service plug board for the interior materials and...
  • Page 65 ENVIRONMENTAL FRIENDLINESS MARK List of Parts with Environmental Friendliness Mark SKIN-C/PAD MAIN SKIN - DR TRIM UPR NON WOVEN - HEADLINER THREAD - FLOOR CARPET THREAD - FLOOR MAT FLOOR CONSOLE - MAIN, REAR FLOOR CONSOLE - UPPER PILLAR TRIM - FRONT PILLAR TRIM - REAR Bio Materials PILLAR TRIM - CENTER LWR...
  • Page 66 Introduction Vehicle Data Collection and Event Data Recorders ..... . 1-2...
  • Page 67 Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR, event data recorder (EDR). The ter understanding of the circum- special equipment is required, and stances in which crashes and access to the vehicle or the EDR is main purpose of an EDR is to...

  • Page 68: Your Vehicle At A Glance

    Your vehicle at a glance Exterior overview ......2-2 Interior overview ......2-4 Instrument panel overview .

  • Page 69: Exterior Overview

    Your vehicle at a glance EXTERIOR OVERVIEW ■ Front view 1. Hood .............4-22 2. Head lamp ........4-83, 7-64 3. Fog lamp ........4-86, 7-67 4. Wheel and tire ........7-36 5. Outside rearview mirror ......4-36 6. Front windshield wiper blades ..4-87, 7-29 7.
  • Page 70 Your vehicle at a glance ■ Rear view 10. Door locks...........4-11 11. Rear combination lamp.......7-68 12. High mounted stop lamp ....7-70 13. Rear window wiper blade ..4-87, 7-31 14. Tailgate..........4-15 15. Rear camera display......4-80 16. Antenna ..........4-127 17. Parking assist system......4-76 ❈...

  • Page 71: Interior Overview

    Your vehicle at a glance INTERIOR OVERVIEW 1. Inside door handle ........4-12 2. Power window switch ......4-17 3. Central door lock switch......4-13 4. Power window lock switch.....4-20 5. Outside rearview mirror control.....4-37 6. Outside rearview mirror folding .....4-38 7. Instrument panel illumination control switch ............4-41 8.

  • Page 72: Instrument Panel Overview

    Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Audio remote control buttons....4-128 2. Driver’s front air bag ......3-46 3. Horn............4-32 4. Instrument cluster .........4-40 5.Wiper and washer control lever .....4-87 6. Cruise control button ......5-32 7. POWER button ........5-5 8.

  • Page 73: Motor Room Compartment

    Your vehicle at a glance MOTOR ROOM COMPARTMENT 1. Coolant reservoir ........7-21 2. Brake fluid reservoir ......7-24 3. Fuse box..........7-51 4. Positive battery terminal ......7-33 5. Negative battery terminal ......7-33 6. Radiator cap ..........7-23 7. Windshield washer fluid reservoir ..7-26 ❈...

  • Page 74: Safety Features Of Your Vehicle

    Safety features of your vehicle Seats ........3-2 •...
  • Page 75 Safety features of your vehicle SEATS Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (Driver’s seat) (4) Headrest Rear seat (5) Seatback folding (6) Headrest OPSE034001...
  • Page 76 Safety features of your vehicle WARNING WARNING WARNING - Seat cushion - Loose - Driver respon- objects sibility for passengers Occnpants should never sit on Do not place anything in the dri- aftermarket seat cushions or sit- ting cushions. The passenger's ver's foot well or under the front hips may slide under the lap por- seats.
  • Page 77 Safety features of your vehicle WARNING WARNING WARNING - Rear - Unexpected - Small seatbacks Seat Movement Objects Always lock the rear seatback After adjusting a manual seat, Use extreme caution when pick- before driving. Failure to do so always check that it is locked by ing small objects trapped under could result in passengers or shifting your weight to the front...
  • Page 78 Safety features of your vehicle Seatback angle Seat height (for driver’s seat) Front seat adjustment Forward and backward OPS033003 OPS033004 OPS033002 To recline the seatback: To change the height of the seat, push the lever upwards or down- 1. Lean forward slightly and lift up the To move the seat forward or back- wards.
  • Page 79 Safety features of your vehicle Headrest (for front seat) For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most people's head is similar with the height of the top of their eyes.
  • Page 80 Safety features of your vehicle OPS033010 OYFH034205 OPS033047L Adjusting the height up and down Removal and installation ✽ ✽ NOTICE To remove the headrest: To raise the headrest, pull it up to the desired position (1). To lower the If you recline the seatback towards 1.
  • Page 81 Safety features of your vehicle Seatback pocket WARNING - Headrest Reinstallation To reduce the risk of injury to the head or neck, always make sure the headrest is locked into position and adjusted properly after reinstalling. OPS033048L To reinstall the headrest : OPS033016 1.
  • Page 82 Safety features of your vehicle Rear seat adjustment Folding the rear seat The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING - Folded down seatback Never allow passengers sit on top of the folded down seatback while OPS033015 OPSE034018...
  • Page 83 Safety features of your vehicle Headrest For maximum effectiveness in case of WARNING - Cargo an accident, the headrest should be adjusted so the middle of the head- Do not place heavy objects in rest is at the same height as the cen- the rear seats, since they can- ter of gravity of an occupant's head.
  • Page 84 Safety features of your vehicle Adjusting the height up and down Removal and installation WARNING - Headrest installation After installing the headrest, make sure that it is installed in the right direction. A headrest installed reversely could increase whiplash injury during rear impact.
  • Page 85 Safety features of your vehicle SEAT BELTS Seat belt restraint system Seat belts are designed to bear upon WARNING - Shoulder Belt the bony structure of the body, and • For maximum restraint system pro- should be worn low across the front •...
  • Page 86 Safety features of your vehicle Seat belt warning • No modifications or additions WARNING - Seat belt should be made by the user which will either prevent the seat belt buckle adjusting devices from operating to Do not allow foreign material remove slack, or prevent the seat (gum, crumbs, coins, etc.) to belt assembly from being adjusted...
  • Page 87 Safety features of your vehicle Conditions Warning Pattern Conditions Warning Pattern Vehicle Chime- Vehicle Seat Belt Light-Blink Seat Belt Light-Blink Speed Sound Speed Unbuckled 6 seconds Unbuckled 6 seconds Buckled 6 seconds None Above 6mph Unbuckled Continuously (10 km/h) Below 3 mph 6 seconds None (5 km/h)
  • Page 88 Safety features of your vehicle Seat belt - Driver's 3-point system Riding in an improper position The seat belt automatically adjusts to adversely affects the front passen- with emergency locking retractor the proper length only after the lap ger's seat belt warning system. It is belt portion is adjusted manually so important for the driver to instruct the that it fits snugly around your hips.
  • Page 89 Safety features of your vehicle Release the button to lock the Front seat anchor into position. Try sliding the height adjuster to make sure that it has locked into position. WARNING - Shoulder belt positioning Never position the shoulder belt across your neck or face.
  • Page 90 Safety features of your vehicle Seat belts - Front passenger and It automatically adjusts to the proper Do NOT fold down the left portion of rear seat 3-point system with length only after the lap belt portion the rear seat back when the rear of the seat belt is adjusted manually center seat belt is buckled.
  • Page 91 Safety features of your vehicle Stowing the rear seat belt CAUTION - Seat belt guide Remove the seat belt from the guides before using. If you pull on the seat belt when it is stored in the guides, it may damage the guides and/or belt webbing.
  • Page 92 Safety features of your vehicle 3 Point rear center belt WARNING - Rear center seat belt Do not separate mini tongue and mini buckle even if there is not an occupant. If it is separated, It may hit the rear seat occupants in a collision or sudden stops.
  • Page 93 Safety features of your vehicle To unfasten the rear center belt There will be an audible “click” when Pre-tensioner seat belt the tab locks in the buckle. The seat belt automatically adjusts to the proper length only after the lap belt is adjusted manually so that it fits snug- ly around your hips, if you lean for- ward in a slow, easy motion, the belt...
  • Page 94 Safety features of your vehicle (1) Retractor Pretensioner • Both the driver's and front passen- ger's seat belt pre-tensioner sys- The purpose of the retractor pre- tem may be activated not only in tensioner is to make sure that the certain frontal collision but also in shoulder belts fit in tightly against certain side collision or rollover, if...
  • Page 95 “Child restraint system” in this have an authorized Kia dealer burn you. section. inspect the pre-tensioner seat belt and SRS air bag system as soon as possible.
  • Page 96 Safety features of your vehicle ✽ ✽ NOTICE Larger children If the shoulder belt portion slightly touches the child’s neck or face, try Children who are too large for child Small children are best protected placing the child closer to the center of restraint systems should always from injury in an accident when the vehicle.
  • Page 97 Safety features of your vehicle Restraint of pregnant women Injured person Do not lie down Pregnant women should wear A seat belt should be used when an To reduce the chance of injuries in lap/shoulder belt assemblies when- injured person is being transported. the event of an accident and to ever possible according to specific When this is necessary, you should...
  • Page 98 This should be done even if no damage is visible. Additional questions concerning seat belt oper- ation should be directed to an authorized Kia dealer. 3 25...
  • Page 99 Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the vehicle should Children could be injured or killed in WARNING - Hot child sit in the rear seat and must always a crash if their restraints are not be properly restrained to minimize properly secured.
  • Page 100 After an accident, have an author- Always use a child restraint ized Kia dealer check the child system which is appropriate for restraint system, seat belt, tether your child's height and weight.
  • Page 101 To secure a child authorized Kia dealer. ✽ ✽ NOTICE restraint system, use the following procedure. If the vehicle headrest prevents...
  • Page 102 Safety features of your vehicle If the vehicle headrest prevents prop- er installation of a child seat (as described in the child seat system manual), the headrest of the respec- tive seating position shall be read- justed or entirely removed. OEN036101 OEN036102 To install a child restraint system on...
  • Page 103 Safety features of your vehicle The lap/shoulder belt automatically returns to the “emergency lock mode” whenever the belt is allowed to retract fully. Therefore, the preced- ing seven steps must be followed each time a child restraint is installed. To remove the child restraint, press the release button on the buckle and then pull the lap/shoulder belt out of the restraint and allow the seat belt...
  • Page 104 Safety features of your vehicle Securing a child restraint seat WARNING - Tether strap with tether anchor system Never mount more than one child restraint to a single tether or to a single lower anchorage point. increased load caused by multiple seats may cause the tethers or anchorage points to break.
  • Page 105 Safety features of your vehicle Securing a child restraint seat with Lower Anchor Position Indicator WARNING - Unused rear child seat lower anchor system seatbelts Always fasten the seatbelts behind the child restraint seat when they are not used to secure the child seat.
  • Page 106 Safety features of your vehicle Once you have installed the LATCH WARNING - LATCH lower child restraint, assure that the seat is properly attached to the LATCH and anchors tether anchors. Never attempt to attach a Also, test the child restraint seat LATCH equipped seat in the before you place the child in it.
  • Page 107 Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side air bag (4) Curtain air bag Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and sever- ity of injury in the event of a collision...

  • Page 108: Air Bag

    Safety features of your vehicle How does the air bag system • The front air bags will completely • In order to help provide protection, operate the air bags must inflate rapidly. inflate and deflate in an instant. The speed of the air bag inflation is It is virtually impossible for you to •...
  • Page 109 Safety features of your vehicle Noise and smoke WARNING WARNING - Airbag infla- - Hot compo- When inflated, the air bags make a tion nents loud noise and leave smoke and Sit as far back as possible from powder in the air inside the vehicle. Do not touch the air bag storage the steering wheel while still This is normal and is a result of the...

  • Page 110: Air Bag Warning Light

    Safety features of your vehicle Do not install a child restraint on Air bag warning light WARNING - Air bag the front passenger’s seat. deployment When children are seated in the rear outboard seats of a vehicle equipped with side and/or cur- tain air bags, install the child restraint system as far away from the door side as possible.

  • Page 111: Srs Components And Functions

    6 seconds, then go off. Have the system 11. Occupant detection system checked by an authorized Kia dealer- (Front passenger’s seat only) ship if: 12. Driver’s and front passenger’s • The light does not turn on briefly...
  • Page 112 Driver’s front air bag (1) occurs, this indicates a malfunction in the air bag system. Have an authorized Kia dealer inspect the air bag system as soon as possible. • The light does not turn on briefly when you turn the POWER button •...
  • Page 113 Safety features of your vehicle Driver’s front air bag (2) Driver’s front air bag (3) Passenger’s front air bag B240B02L B240B03L B240B05L Upon deployment, tear seams mold- A fully inflated air bag, in combina- ed directly into the pad covers will tion with a properly worn seat belt, WARNING - Air bag...

  • Page 114: Occupant Detection System (Ods)

    • If an air bag deploys, there may be your vehicle immediately inspected a loud noise followed by a fine dust by an authorized Kia dealer. released in the vehicle. These con- ditions are normal and are not haz- ardous - the air bags are packed in ✽...
  • Page 115 Safety features of your vehicle Main components of the occu- If the front passenger seat is occupied • The ODS (Occupant Detection pant detection system by a person that the system deter- System) may not function properly if mines to be of appropriate size, and the passenger takes actions which •...
  • Page 116 Safety features of your vehicle ✽ ✽ NOTICE Condition and operation in the front passenger occupant detection system Do not modify or replace the front passenger seat. Don't place anything Indicator/Warning light Devices Condition detected by the on or attach anything such as a blan- "PASSENGER AIR occupant detection Front passenger...
  • Page 117 Safety features of your vehicle (Continued) OVQ036013N 1KMN3663 1KMN3665 - Never put a heavy load or an - Never sit with hips shifted - Never place feet on the dash- active electronic device on towards the front of the seat. board.
  • Page 118 Safety features of your vehicle ✽ ✽ NOTICE If the PASSENGER AIR BAG “OFF” Proper position indicator is still on, ask the passen- The PASSENGER AIR BAG “OFF” ger to move to the rear seat. indicator illuminates for about 4 sec- onds after the POWER button is turned to the ON position or after WARNING...

  • Page 119: Driver's And Passenger's Front Air Bag

    Safety features of your vehicle Any child age 12 and under should Driver's and passenger's front The indication of the system's pres- ride in the rear seat. Children too air bag ence are the letters "AIR BAG" large for child restraints should use embossed on the air bag pad cover Driver’s front air bag the available lap/shoulder belts.
  • Page 120 The advanced SRS offers the ability front passenger's air bag under cer- Kia dealer using original Kia parts to control the air bag inflation with tain conditions. For more detail, see designed for this vehicle and two levels.
  • Page 121 That contact is Kia’s toll-free can be provided by the pre-tensioner Customer Assistance center at 1- seat belt.

  • Page 122: Side Air Bag

    Safety features of your vehicle Side air bag Your vehicle is equipped with a side air • The side air bag is supplemental to bag in each front seat. The purpose of the driver's and the passenger's the air bag is to provide the vehicle's seat belt systems and is not a sub- driver and/or the front passenger with stitute for them.

  • Page 123: Curtain Air Bag

    Kia deal- OPS033024 opposite side. Also, the curtain air bags er. Inform the dealer that your vehi-...
  • Page 124 Safety features of your vehicle Why didn’t my air bag go off in a Air bag collision sensors collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional protection.
  • Page 125 Have the vehicle checked and installed. repaired by an authorized Kia deal- This may cause unexpected air bag deployment, which • Installing bumper guards (or side could result in serious per- step or running board) or replacing sonal injury or death.
  • Page 126 Safety features of your vehicle Also, the side and curtain air bags are If the vehicle chassis is impacted by designed to inflate when a rollover is bumps or objects on unimproved detected by a rollover sensor. roads, the air bags may deploy. Drive carefully on unimproved roads or on Although the front air bags (driver’s surfaces not designed for vehicle...
  • Page 127 Safety features of your vehicle Air bag non-inflation conditions OUN036087 OVQ036018N • Air bags are not designed to inflate • Front air bags may not inflate in 1VQA2086 in rear collisions, because occu- side impact collisions, because • In certain low-speed collisions the pants are moved backward by the occupants move to the direction of air bags may not deploy.
  • Page 128 Safety features of your vehicle 1VQA2089 1VQA2090 1VQA2091 • In an angled collision, the force of • Just before impact, drivers often • Front air bags may not inflate in impact may direct the occupants in brake heavily. Such heavy braking rollover accidents because front a direction where the air bags lowers the front portion of the vehi-...

  • Page 129: Srs Care

    • If components of the air bag sys- inspected by an authorized Kia dealer. tem must be discarded, or if the vehicle must be scrapped, certain Any work on the SRS system, such safety precautions...

  • Page 130: Adding Equipment To Or Modifying Your Air Bag-Equipped Vehicle

    Safety features of your vehicle Adding equipment to or modi- Air bag warning label WARNING - Tampering fying your air bag-equipped with SRS vehicle Do not tamper with or discon- If you modify your vehicle by changing nect SRS wiring, or other com- your vehicle's frame, bumper system, ponents of the SRS system.

  • Page 131: Features Of Your Vehicle

    Features of your vehicle Smart key ....... . . 4-4 Panoramic sunroof .
  • Page 132 • A/V Mode ........4-48 • Lighting control ......4-82 •...
  • Page 133 • Checking the amount of air conditioner refrigerant and Audio system ......4-127 compressor lubricant .

  • Page 134: Smart Key

    Should key is dangerous. Children copy lose your keys, this number will adults and they could press the enable an authorized Kia dealer to start button. The key would duplicate the keys easily. Remove enable children...
  • Page 135 Features of your vehicle Door Lock The button will only operate when the smart key is within 28~40 in. (0.7~1m) from the outside door handle. Even though you press the outside door handle button, the doors will not lock and the chime will sound for 3 seconds if any of following occur: •...
  • Page 136 Features of your vehicle Unlocking • The button will only operate when Using the button on the smart key the smart key is within 28~40 in. 1. Press the unlock button(2) of the Using the door handle button (0.7~1m) from the outside door smart key.

  • Page 137: Loss Of The Smart Key

    You should immediately take the times. vehicle and remaining key to your Once the tailgate is opened and authorized Kia dealer(tow the vehi- Start-up then closed, the tailgate will lock cle, if necessary) to protect it from You can start the vehicle without automatically.

  • Page 138: Smart Key Precautions

    Keep the smart key away from with the mechanical key and contact If the key is determined to be invalid, water or any liquid as it can an authorized Kia dealer. the vehicle will not start. become damaged and not func- tion properly.
  • Page 139 If you need additional keys or lose operation. activates automatically. Without a your keys, contact an authorized valid smart key for your vehicle, the Kia dealer. vehicle will not start. ✽ ✽ NOTICE In order to prevent theft of your vehi- CAUTION...

  • Page 140: Battery Replacement

    If you are unsure how to use or replace the battery, contact an authorized Kia dealer. • Using the wrong battery can cause the smart key to malfunction. Be sure to use the correct battery.

  • Page 141: Door Locks

    Features of your vehicle DOOR LOCKS O perating door locks from • Once the doors are unlocked, they outside the vehicle may be opened by pulling the door handle. • When closing the door, push the door by hand. Make sure the doors are closed securely.

  • Page 142: Operating Door Locks From Inside The Vehicle

    Features of your vehicle Operating door locks from • To open a door, pull the door han- If a power door lock ever fails to func- inside the vehicle dle (3) outward. tion while you are in the vehicle, try one or more of the following tech- •...

  • Page 143: Auto Door Lock/Unlock Feature

    Features of your vehicle With central door lock switch • When pressing the rear portion (2) Impact sensing door unlock of the switch, all vehicle doors will system Driver’s door unlock. In the event of air bag deployment • If the vehicle is in the ready ( resulting from a vehicle impact, all mode and any front door is opened, doors will automatically unlock.

  • Page 144: Child-Protector Rear Door Lock

    Features of your vehicle Child-protector rear door lock 3. Close the rear door. To open the rear door, pull the out- side door handle. Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle (1) until the rear door child safety lock is unlocked.

  • Page 145: Tailgate

    Features of your vehicle TAILGATE ✽ ✽ NOTICE Opening the tailgate Closing the tailgate In cold and wet climates, door lock and door mechanisms may not work properly due to freezing conditions. The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when opening the tailgate.

  • Page 146: Emergency Tailgate Safety Release

    Features of your vehicle Emergency tailgate safety WARNING release • No one should be allowed to occupy the cargo area of the vehicle at any time. The cargo area is a very dangerous loca- tion in the event of a crash. •...

  • Page 147: Windows

    Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up/down (7) Power window lock switch In cold and wet climates, power win-...

  • Page 148: Power Windows

    Features of your vehicle ✽ ✽ NOTICE Window opening and closing Power windows While driving with the rear windows The POWER button must be in the down or with the sunroof (if ON position for power windows to equipped) in an open (or partially operate.
  • Page 149 Features of your vehicle Auto up/down window 1. Turn the POWER button to the ON (for driver's window) position. 2. Close the driver’s window and continue pulling up the driver’s power window switch for at least 1 second after the window is com- pletely closed.
  • Page 150 Features of your vehicle Power window lock button And if the power window switch is WARNING pulled up continuously again within 5 seconds after the window is lowered Always check for obstructions by the automatic window reversal before raising any window to feature, the automatic window rever- avoid injuries or vehicle damage.
  • Page 151 Features of your vehicle • When the power window lock Always double check to make sure switch is pressed : all arms, hands, head and other obstructions are safely out of the way - The driver's master control can before closing a window. operate all the power windows.

  • Page 152: Hood

    Features of your vehicle HOOD Opening the hood Closing the hood 1. Before closing the hood, check the following: • All filler caps in the motor com- partment must correctly installed. 2. Lower the hood halfway and push down to securely lock in place. WARNING OPSE044025 Before closing the hood, ensure...
  • Page 153 Features of your vehicle WARNING - Fire risk Do not leave gloves, rags or any other combustible material in the motor compartment. Doing so may cause a heat-induced fire. WARNING - Unsecured hood Always double check to be sure that the hood is firmly latched before driving away.

  • Page 154: Panoramic Sunroof

    Features of your vehicle PANORAMIC SUNROOF (IF EQUIPPED) ✽ ✽ NOTICE ✽ ✽ NOTICE • In cold and wet climates, the sun- The sunroof cannot tilt when it is in roof may not work properly due to the slide position but can be slid freezing conditions.

  • Page 155: Sunroof Open Warning

    Features of your vehicle When the sunshade is opened Sunroof open warning Sliding the sunroof (if equipped) If you pull the sunroof glass control lever backward, the sunroof glass will slide all the way open. To stop the sunroof glass movement at any point, pull or push the sunroof control lever momentarily.

  • Page 156: Tilting The Sunroof

    Features of your vehicle Automatic reversal Tilting the sunroof To tilt down (or close) the sunroof - Push the sunroof glass control lever forward or pull it downward When you push the sunroof glass control lever forward or pull it down- ward while the sunshade opened, the glass will be tilt down.

  • Page 157: Sunshade

    Features of your vehicle Do not extend the face, neck, arms Sunshade CAUTION - Sunroof motor or body outside the sunroof while damage driving. If you try to open the sunroof when the temperature is below WARNING - Sunroof freezing or when the sunroof is Operation covered with snow or ice, the When closing the sunroof, make...

  • Page 158: Resetting The Sunroof

    Features of your vehicle ✽ ✽ NOTICE To close the sunshade when the Resetting the sunroof sunroof glass is closed Wrinkles formed on the sunshade as Whenever the vehicle battery is dis- - Press the sunshade close button (2). material characteristic are normal. connected or discharged, you must ❈...
  • Page 159 Features of your vehicle 5.Push the sunroof control lever for- ward in the direction of close, until the sunroof operates as follows again: The sunshade and sunroof glass slide open → The sunroof glass slide close → The sunshade close Then, release the lever.

  • Page 160: Steering Wheel

    Take your vehicle to becomes inoperative, the vehicle may • The steering gets heavy immedi- an authorized Kia dealer and have still be steered, but it will require ately after turning the POWER the vehicle checked as soon as increased steering effort.

  • Page 161: Tilt And Telescopic Steering

    Features of your vehicle (Continued) Tilt and telescopic steering • When you operate the steering Tilt and telescopic steering allows wheel in low temperature, abnor- you to adjust the steering wheel mal noise may occur. If tempera- before you drive. You can also raise it ture rises, the noise will likely dis- to give your legs more room when appear.

  • Page 162: Heated Steering Wheel

    Features of your vehicle ✽ ✽ NOTICE Heated steering wheel Horn The heated steering wheel will turn off automatically approximately 30 minutes after the heated steering wheel is turned on. CAUTION • Do not install any grip to oper- ate the steering wheel. This causes damage to the heated steering wheel system.

  • Page 163: Flex Steer

    Features of your vehicle Normal mode FLEX STEER If the steering wheel mode button is not pressed for about 4 seconds, the LCD display will change to the previ- ous screen. OPS043036 OPSE044129 The normal mode offers medium The FLEX STEER controls steering steering effort.
  • Page 164 Features of your vehicle Sport mode Comfort mode • For your safety, if you press the steering mode button while operat- ing the steering wheel, but the steering effort will not change immediately. After operating the steering wheel, the steering effort will change automatically to the selected mode.

  • Page 165: Mirrors

    Features of your vehicle MIRRORS Day/night rearview mirror Electric chromic mirror (ECM) Inside rearview mirror (if equipped) (if equipped) Adjust the rearview mirror so that the The electric rearview mirror automat- center view through the rear window ically controls the glare from the is seen.
  • Page 166 Features of your vehicle Outside rearview mirror CAUTION - Cleaning Be sure to adjust the mirror angles mirror before driving. When cleaning the mirror, use a Your vehicle is equipped with both paper towel or similar material left-hand and right-hand outside dampened with glass cleaner.
  • Page 167 Features of your vehicle Remote control CAUTION CAUTION - Rearview - Outside mirror mirror • The mirrors stop moving when Do not scrape ice off the mirror they reach the maximum face; this may damage the sur- adjusting angles, but the face of the glass.
  • Page 168 Features of your vehicle Folding the outside rearview mirror Center (AUTO, 3) : The mirror will fold or unfold auto- matically as follows: • Without smart key system - The mirror will fold or unfold when the door is locked or unlocked by the transmitter.

  • Page 169: Outside Rearview Mirror

    Features of your vehicle Outside mirror defroster CAUTION - Electric type ■ Type A outside rearview mirror electric type outside rearview mirror operates even though the POWER button is in the OFF position. However, to prevent unnecessary battery dis- charge, do not adjust the mirrors longer than necessary while the vehicle is in not the ready ( mode.

  • Page 170: Instrument Cluster

    Features of your vehicle INSTRUMENT CLUSTER 1. Motor operation gauge 2. Speedometer 3. Range meter 4. Warning and indicator lights 5. State of charge gauge 6. LCD display ❈ The actual cluster in the vehicle may differ from the illustration. For more details, refer to the "Gauges"...

  • Page 171: Instrument Cluster Control

    Features of your vehicle Instrument Cluster Control LCD Display Control Adjusting Instrument Cluster Illumination OPSE044117L • If you hold the illumination control OPS043040 button ("+" or "-"), the brightness The LCD display modes can be will be changed continuously. OPSE044039 changed by using the control buttons •...

  • Page 172: Gauges

    Features of your vehicle Motor operation gauge Gauges • CHARGE : It shows the charging status of the battery Speedometer when it is being charged regenerative brakes (decelerating or driving on a downhill road). The more electric energy is charged, the lower the gauge level.
  • Page 173 Features of your vehicle State of charge (SOC) gauge for When there are 1-2 gauge bars left high voltage battery for the high voltage battery, the vehi- cle speed is limited and then eventu- ally the vehicle will be turned OFF. Charge the vehicle immediately.
  • Page 174 Features of your vehicle Odometer Outside Temperature Gauge The outside temperature on the dis- play may not change immediately like a general thermometer to pre- vent the driver from being inattentive. The temperature unit can be changed by using the "User Settings" mode of the LCD display ❈...

  • Page 175: Reduction Gear Shift Indicator

    Features of your vehicle Reduction gear shift indicator OPSE044125L This indicator displays which reduc- tion gear shift lever is selected. • Park :P • Reverse : R • Neutral : N • Drive :D • Regenerate brake : B ❈ For the detailed explanation of each shift range,...

  • Page 176: Lcd Display

    Features of your vehicle LCD DISPLAY LCD Modes Modes Symbol Explanation This mode displays EV system energy flow and ECO level. EV information For more details, refer to “EV information mode" in this chapter. This mode displays driving information like the tripmeter, Trip Computer energy consumption, and so on.

  • Page 177: Ev Information Mode

    Features of your vehicle EV energy flow ECO Level EV information mode EV information mode shows EV energy flow and ECO level. EV energy flow ECO Level To change the EV information mode, OPSE044240L OPSE044241L press the (MOVE) button EV energy flow notifies the drivers of When the vehicle is started, the ECO energy flow in operating modes.

  • Page 178: A/V Mode

    Features of your vehicle A/V Mode Service Mode Service Interval OPSE044274L Service required OPSE044242 If you do not have your vehicle serv- OPSE044266N This mode displays the state of the iced according to the already inputted A/V system. Service interval service interval, “Service required”...

  • Page 179: User Settings Mode

    Features of your vehicle Master Warning Mode User Settings Mode Description • This warning light informs the driver the following situations - TPMS - Service reminder The Master Warning Light illumi- nates when more than one of the above warning situations occur. At OTF044192L this time, the LCD Modes Icon will Service interval OFF...
  • Page 180 Features of your vehicle Door Auto Unlock Two Press Unlock • Off: • Off: Auto Lock The auto door unlock operation will The two press unlock function will • Off: be canceled. be deactivated. Therefore, all doors The auto door lock operation will will unlock if the door is unlocked.
  • Page 181 Features of your vehicle Lamp Settings Energy Consumption Auto Reset • Auto Reset : One Touch Turn Lamp (if equipped) Language The average energy consumption will If this item is checked, the lane Choose the language you prefer reset automatically when charge the change signals will blink 3, 5 or 7 within the LCD.

  • Page 182: Warning Messages

    Features of your vehicle Service Interval Low Battery. Charge immediately Warning Messages Low Battery OPSE044136N OPSE044214L OPSE044213L On this mode, you can activate the When the high voltage battery level service interval function with mileage reaches below 10%, this warning When the high voltage battery level (mi.
  • Page 183 Features of your vehicle Charge immediately. Power limited Power limited When this warning message is dis- played, do not accelerate or start the vehicle suddenly. Charge the battery immediately when the high voltage battery level is not enough. OPSE044215L OPSE044264L When the high voltage battery level In the following cases, this warning reaches below 7%, this warning...
  • Page 184 Make sure Remove the charging connector and Refrain from driving when the warn- to close the charging door after start the vehicle. ing message is displayed. In this charging is complete. case, have your vehicle inspected by an authorized Kia dealer.
  • Page 185 Turn off the POWER button and stop your vehicle to the nearest author- nated even after the ambient temper- the vehicle so that the battery tem- ized Kia dealer and have the vehicle ature has increased, have your vehi- perature decreases. inspected.
  • Page 186 POWER button once braking distance may become longer. more, it will turn to the ON position). Refrain from driving when the warn- ing message is displayed. In this case, have your vehicle inspected by an authorized Kia dealer as soon as possible.
  • Page 187 Features of your vehicle Low Key Battery Press brake pedal to start vehicle Key not in vehicle OPSE044142L OPSE044152L OPSE044138L • This warning message illuminates • This warning message illuminates • This warning message illuminates if the battery of the smart key is if the POWER button changes to if the smart key is not in the vehicle discharged when the POWER but-...
  • Page 188 • It means that you could start the • At this time, the immobilizer indica- engine by pressing the POWER tor light blinks. button once more. • If the warning illuminates each time you press the POWER button, have your vehicle inspected by an authorized Kia dealer.
  • Page 189 Features of your vehicle Check BRAKE SWITCH fuse Door Open Tailgate Open OPSE044157L OPSE043121 OPSE043122 • This warning message illuminates • It means that any door is open. • It means that the tailgate is open. if the brake switch fuse is discon- nected.
  • Page 190 Features of your vehicle Turn on FUSE SWITCH Charger Error! Quick Charger Error! OPSE044154L OPSE045323L OPSE045324L • This warning message illuminates • This message is displayed when • This message is displayed when if the fuse switch on the fuse box is the charging failed by external nor- the charging failed by external OFF.

  • Page 191: Trip Computer

    Features of your vehicle TRIP COMPUTER Trip Modes Overview Energy consumption Description Energy consumption The trip computer is a microcomput- • Average energy consumption er-controlled driver information sys- tem that displays information related • Instant energy consumption to driving. ✽ ✽ NOTICE TRIP A Some driving information stored in •...

  • Page 192: Trip A/B

    Features of your vehicle Instant energy consumption (2) Manual reset Trip A/B To clear the average energy con- • This mode displays the instant ener- sumption manually, press the but- gy consumption during the last few ton (MOVE) on the steering wheel for seconds when the vehicle speed is more than 1 second when the aver- more than 10 km/h (6.2 MPH).
  • Page 193 Features of your vehicle Average Vehicle Speed (2) Elapsed Time (3) One time driving information mode • The average vehicle speed is cal- • The elapsed time is the total driv- culated by the total driving dis- ing time since the last elapsed time tance and driving time since the reset.

  • Page 194: Range

    Features of your vehicle Range After “---” has been displayed, the vehi- cle can drive an additional 3.1~9.3mi. (5~15km) (depending on driving speed, heater/air conditioner, weather, driving style, and other factors). Distance to empty that is displayed on the instrument cluster after com- pleting a recharge may vary signifi- cantly depending on previous operat- ing patterns.

  • Page 195: Warning And Indicator Lights

    When the warning light turns ON rupting normal driving. while driving, or does not turn OFF after vehicle has started, have your vehicle inspected by an authorized Kia dealer. 4 65...
  • Page 196 In this case, drive safely and have your vehicle inspected by an In this case, have your vehicle authorized Kia dealer. inspected by an authorized Kia dealer. In this case, operation of the brake pedal may be more difficult than normal and the braking distance can increase.
  • Page 197 In this case, have your vehicle - If the warning light illuminates towed to an authorized Kia dealer with the parking brake released, it and inspected. indicates the brake fluid level in reservoir is low.
  • Page 198 ABS (The normal braking sys- In this case, have your vehicle Also, the vehicle will not stop in as tem will still be operational without inspected by an authorized Kia short a distance with only a portion the assistance of the anti-lock dealer.
  • Page 199 Kia the risk of a crash or injury. In this case, have your vehicle inspect- dealer. ed by an authorized Kia dealer as In this case, avoid high speed soon as possible. driving and abrupt braking.
  • Page 200 System In this case, have your vehicle warning light turns off. If the warn- (TPMS)” in chapter 6. inspected by an authorized Kia ing light remains on, In this case, dealer. have your vehicle inspected by an authorized Kia dealer.
  • Page 201 TPMS. and can contribute to loss of vehicle control and increased In this case, have your vehicle braking distances. inspected by an authorized Kia Tailgate Open Warning dealer as soon as possible. • Continued driving or low pres- Light sure tires will cause the tires to For more details, refer to “Tire...

  • Page 202: Indicator Lights

    • When there is a malfunction with the ESC system. - Blinking: Emergency driving. In this case, have your vehicle inspected by an authorized Kia When ready indicator light is OFF or dealer. blinking, there is a failure. In this case, have your vehicle inspected by an authorized Kia dealer.
  • Page 203 Features of your vehicle Electronic Stability ® Immobilizer Indicator ECOMINDER indicator Control (ESC) OFF Light Active ECO system Indicator Light This indicator light illuminates: This indicator light illuminates: This indicator light illuminates for up to 30 seconds: • Once you set POWER button to •...
  • Page 204 • When you turn the turn signal light • When the headlights are on and in In this case, have your vehicle the high beam position inspected by an authorized Kia dealer. • When the turn signal lever is pulled into the Flash-to-Pass position.
  • Page 205 Features of your vehicle Front Fog Indicator Cruise SET Indicator Light (if equipped) Light This indicator light illuminates: This indicator light illuminates: • When the cruise control speed is set. • When the front fog lights are on. For more details, refer to “Cruise Cruise Indicator Light Control System”...

  • Page 206: Parking Assist System

    Features of your vehicle PARKING ASSIST SYSTEM ■ Front The parking assist system assists Operation of the parking the driver during movement of the assist system vehicle by chiming if any object is Operating condition sensed within the distance of 39 in (100 cm) in front or 47in(120cm) behind the vehicle.
  • Page 207 ON. 12 in. (30cm) Buzzer sounds Rear continuously ✽ ✽ NOTICE The indicator may differ from the illustration as objects or sensors status. If the indicator blinks, the system should be checked by an authorized Kia dealer. 4 77...

  • Page 208: Non-Operational Conditions Of Parking Assist System

    Features of your vehicle There is a possibility of parking The following objects may not be Non-operational conditions of parking assist system assist system malfunction when: recognized by the sensor: 1. Driving on uneven road surfaces 1. Sharp or slim objects such as Parking assist system may not such as unpaved roads, gravel, ropes, chains or small poles.

  • Page 209: Self-Diagnosis

    Always visually check in front and authorized Kia dealer. sensor. Sensor damage could occur. behind the vehicle when driving. Your new vehicle warranty does not...

  • Page 210: Rear Camera Display

    Features of your vehicle REAR CAMERA DISPLAY This system is a supplemental sys- WARNING - Backing up tem that helps the driver by display- using camera ing objects behind the vehicle when backing up. Never rely solely on the rear camera display when backing.

  • Page 211: Lighting

    Features of your vehicle LIGHTING Headlamp escort (if equipped) Battery saver function Daytime running light (if equipped) If you turn the POWER button to the • The purpose of this feature is to ACC or OFF position with the head- prevent the battery from being dis- Daytime Running Lights (DRL) may lights ON, the headlights remain on...

  • Page 212: Abnormal Lamp Operation

    If this is OXM049110 the case, contact an authorized Kia The light switch has a Headlight and dealer and have the system checked. a Parking light position.
  • Page 213 Features of your vehicle Auto light position Parking light position ( Headlight position ( OAM049041 OAM049042 OMD040095 When the light switch is in the AUTO When the light switch is in the park- When the light switch is in the head- light position, the taillights and head- ing light position (1st position), the light position (2nd position), the...

  • Page 214: High Beam Operation

    Features of your vehicle • Never place anything over sensor High beam operation (1) located on the instrument panel. This will ensure better auto- light system control. • Don’t clean the sensor using a win- dow cleaner. The cleaner may leave a light film which could inter- fere with sensor operation.

  • Page 215: Turn Signals And Lane Change Signals

    Features of your vehicle One-touch lane change function Turn signals and lane change To signal a lane change, move the signals turn signal lever slightly and hold it in (if equipped) position (B). The lever will return to To activate an one-touch lane the OFF position when released.

  • Page 216: Front Fog Light

    Features of your vehicle Front fog light (if equipped) OAM049046N Fog lights are used to provide improved visibility when visibility is poor due to fog, rain or snow, etc. The fog lights will turn on when the fog light switch (1) is turned to the on position after the headlight is turned on.

  • Page 217: Wipers And Washers

    Features of your vehicle WIPERS AND WASHERS Windshield wipers Windshield wiper/washer Rear window wiper/washer OAM049101N Operates as follows when the OAM049100N/OAM049048N POWER button is turned ON. A : Wiper speed control D : Rear wiper/washer control MIST : For a single wiping cycle, push ·...

  • Page 218: Windshield Washers

    Features of your vehicle LO : Normal wiper speed Windshield washers The reservoir filler neck is located in the front of the motor compartment HI : Fast wiper speed on the passenger side. ✽ ✽ NOTICE CAUTION - Washer pump If there is heavy accumulation of To prevent possible damage to snow or ice on the windshield, defrost...

  • Page 219: Rear Window Wiper And Washer Switch

    Features of your vehicle Rear window wiper and washer CAUTION - Wipers& wind- switch shields • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry. • To prevent damage to the wiper blades, do not use gasoline, kerosene, paint thinner, or other solvents on or near them.

  • Page 220: Interior Light

    Features of your vehicle INTERIOR LIGHT Do not use the interior lights for Map lamp • ROOM (2) : extended periods when the vehicle is - The map lamp and room lamp ■ Type A not in the ready ( ) mode.

  • Page 221: Room Lamp

    Features of your vehicle ✽ ✽ NOTICE • DOOR (3) : Room lamp - The map lamp and room lamp • When the lamp is turned on by ■ Type A comes on when a door is opened. pressing the lens (1), the lamp does The lamps go out after approxi- not turn off even if the DOOR mately 30 seconds.

  • Page 222: Luggage Room Lamp

    Features of your vehicle Luggage room lamp Glove box lamp Vanity mirror lamp ■ Type A OPS043055 ■ Type B OPS043057 OAM042336 The glove box lamp comes on when Pull the sunvisor downward and you the glove box is opened. can turn the vanity mirror lamp ON or OFF by pushing the button.

  • Page 223: Defroster

    Features of your vehicle DEFROSTER Rear window defroster activate rear window CAUTION - Conductors defroster, press the rear window ■ Type A defroster button located in the center To prevent damage to the con- facia switch panel. ductors bonded to the inside surface of the rear window, The indicator on the rear window never use sharp instruments or...

  • Page 224: Automatic Climate Control System

    Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM ■ ■ Type A 1. Fan speed control button 2. Front windshield defroster button 3. Rear windshield defroster button 4. Temperature control knob/button 5. AUTO (automatic control) button 6. OFF button 7. HEAT button ■...

  • Page 225: Automatic Heating And Air Conditioning

    Features of your vehicle ✽ ✽ NOTICE ■ Type A Automatic heating and air conditioning • To turn the automatic operation off, select any button or switch of ■ Type A the following: - Mode selection button - Air conditioning (A/C) button - Heater (HEAT) button - DRIVER ONLY button - Front windshield defroster button...

  • Page 226: Manual Heating And Air Conditioning

    Features of your vehicle Manual heating and air 1. Start the vehicle. conditioning 2. Set the mode to the desired posi- tion. The heating and cooling system can be controlled manually by pushing 3. Set the temperature control to the buttons other than the AUTO button.
  • Page 227 Features of your vehicle Mode selection ■ Type A OPSE045313N ■ Type B OPSE044167 The mode selection button controls OPSE044058 the direction of the air flow through the ventilation system. 4 97...
  • Page 228 Features of your vehicle The air flow outlet port is converted as follows: Vent mode (B, D) Floor mode (C, E, A, D) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each out- floor, with a small amount of the air let can be controlled to direct the air being directed to the windshield and...
  • Page 229 Features of your vehicle ■ Type A Temperature control ■ Type A OPSE045314N ■ Type B OPS043059 OPSE045312N ■ Type B Instrument panel vents The outlet port can be opened or closed separately using the thumb- wheel. Also, you can adjust the direction of air delivered from these vents using the vent control lever as shown.
  • Page 230 Features of your vehicle Air intake control The temperature will decrease to the Temperature scale conversion minimum (62°F(17°C)) by pushing If the battery has been discharged or ■ Type A the button ( disconnected, the temperature mode When pushing the button, the tem- display will reset to Centigrade.
  • Page 231 Features of your vehicle Recirculated air position Outside (fresh) air position WARNING - Recirculated The indicator light on the The indicator light on the button illuminates when button does not illuminate Continuous use of the climate the recirculated air posi- when the outside (fresh) control system in the recirculat- tion is selected.
  • Page 232 Features of your vehicle Fan speed control To change the fan speed, press the WARNING - Sleeping with button ( ) for higher speed, or push ■ Type A AC On the button ( ) for lower speed. To turn the fan speed control off, press Do not sleep in a vehicle with the OFF button and select outside the air conditioning or heating...
  • Page 233 Features of your vehicle Air conditioning HEAT Button • Air conditioner/Heater uses energy from the battery. If you use the ■ Type A ■ Type A heater or air conditioner for too long, distance to empty can be reduced due to too much power consumption.
  • Page 234 Features of your vehicle Driver Only Button • Air conditioner/Heater uses energy If you select the driver seat air condi- from the battery. If you use the tioning in the front windshield defrost ■ Type A heater or air conditioner for too mode ( ) air comes out from long, distance to empty can be...
  • Page 235 Features of your vehicle Reserved Climate Control Button Blower OFF The indicator lamp lighting conditions (if equipped) 1.Blinking three times: ■ Type A When you press the reserved cli- mate control button and enter the corresponding settings screen on 2.Remaining turned on: When reserved climate control is set 3.Blinking continuously: When the climate control is operat-...

  • Page 236: System Operation

    Features of your vehicle Climate information screen System operation Operation Tips selection (if equipped) • To keep dust or unpleasant fumes Ventilation from entering the vehicle through 1. Set the mode to the position. the ventilation system, temporarily 2. Set the air intake control to the set the air intake control to the outside (fresh) air position.
  • Page 237 Air conditioning Air conditioning system operation tips CAUTION - Excessive A/C All Kia Air Conditioning Systems are • If the vehicle has been parked in • When using the air condition- filled with R-134a refrigerant. direct sunlight during hot weather,...

  • Page 238: Climate Control Air Filter

    • When the air flow rate suddenly ever, continual operation in this decreases, the system should be mode may cause the air inside the checked at an authorized Kia vehicle to become stale. dealer. Blower • During cooling operation, you may...

  • Page 239: Checking The Amount Of Air Conditioner Refrigerant And Compressor Lubricant

    When the amount of refrigerant is be serviced by an authorized tem is under very high pres- low, the performance of the air con- Kia dealer. The Electric Vehicle sure. If proper service proce- ditioning is reduced. Overfilling also (EV) air conditioning system is...

  • Page 240: Air Conditioning Refrigerant Label

    Features of your vehicle Air Conditioning refrigerant Each symbols and specification on label air conditioning refrigerant label means as below ; ■ Example 1. Classification of refrigerant 2. Amount of refrigerant 3. Classification of Compressor lubri- cant Refer to chapter 8 for more detail location of air conditioning refrigerant label.

  • Page 241: Windshield Defrosting And Defogging

    Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the Automatic climate control WARNING - Windshield temperature control to the extreme system heating right/hot position and the fan speed To defog inside windshield control to the highest speed. Do not use the posi- ■...
  • Page 242 Features of your vehicle To defrost outside windshield 3. Press the defrost button ( 3. Press the defrost button ( 4. The air-conditioning and heater 4. The air-conditioning and heater ■ Type A will be turned on according to the will be turned on according to the detected ambient temperature, detected ambient temperature and...

  • Page 243: Defogging Logic

    Features of your vehicle ■ Type A Defogging logic The indicator on the air intake button blinks 3 times with 0.5 seconds of To reduce the possibility of fogging up interval. It indicates that the defog- the inside of the windshield, the air ging logic is canceled or returned to intake or air-conditioning and heater the programmed status.

  • Page 244: Clean Air

    Features of your vehicle CLEAN AIR OPSE044274N When the POWER button is in the ON position, the clean air function turns on automatically. Also, the clean air function turns off automatically, when the POWER but- ton turns to the OFF position.

  • Page 245: Auto Defogging System

    Features of your vehicle AUTO DEFOGGING SYSTEM This indicator illuminates If your vehicle is equipped with the when the auto defogging auto defogging system, it is automati- system senses the mois- cally activated when the conditions ture of inside the wind- are met.

  • Page 246: Storage Compartment

    Features of your vehicle STORAGE COMPARTMENT These compartments can be used to Center console storage Glove box store small items. • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage compart- ment covers closed while driving. Do not attempt to place so many items in the storage compartment that the storage compartment...

  • Page 247: Sunglass Holder

    Features of your vehicle Sunglass holder To close the sunglass holder, push it Luggage box ■ Type A Do not place other items in the sun- glass holder. WARNING - Sunglass holder • Do not keep objects except sunglasses inside the sun- glass holder.

  • Page 248: Interior Features

    Features of your vehicle INTERIOR FEATURES Cup holder Sunvisor WARNING - Hot liquids Do not place uncovered cups with hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you burn yourself. Such a burn to the driver could lead to loss of con- trol of the vehicle.

  • Page 249: Seat Warmer

    Features of your vehicle Seat warmer (if equipped) During mild weather or under condi- CAUTION - Vanity tions where the operation of the seat ■ Type A mirror lamp warmer is not needed, keep the switches in the "OFF" position. If you use the vanity mirror lamp, turn off the lamp before •...
  • Page 250 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE WARNING - Seat heater With the seat warmer switch in the Be careful not to spill liquid such as burns ON position, the heating system in the water or beverages on the seat. If you The seat warmer may cause seat turns off or on automatically spill some liquid, wipe the seat with a...

  • Page 251: Seat Air Ventilation

    Features of your vehicle Seat air ventilation (if equipped) • If you want to cool your seat cush- Rear seat warmer (if equipped) ion, press the switch (blue color). • Each time you press the button, the airflow will change as follows: HIGH ( MIDDLE ( LOW (...

  • Page 252: Power Outlet

    Features of your vehicle • When pressing the switch for more Power outlet (if equipped) The devices should draw less than than 1.5 seconds with the seat 10 amps with the vehicle is in the ■ Front (Type A) warmer operating, the seat warmer ready ( ) mode.

  • Page 253: Clothes Hanger

    Features of your vehicle Clothes hanger (if equipped) Floor mat anchor(s) WARNING - Electric ■ Driver's side ■ Passenger's side shock Do not put a finger or a foreign element (pin, etc.) into a power outlet and do not touch with a wet hand.You may get an electric shock.

  • Page 254: Luggage Net Holder

    If necessary, contact your authorized To avoid any interference with pedal Kia dealer to obtain a luggage net. operation, Kia recommends that only the Kia floormat designed for use in To prevent damage to the goods or your vehicle be installed.

  • Page 255: Cargo Area Cover

    Features of your vehicle Removal and installation Cargo area cover (if equipped) OPS045357 2. Firmly hold the folded part of the OPS043199 OPS045355 cover and lift it up. Use the cargo area cover to hide To remove the cargo area cover: items stored in the cargo area.
  • Page 256 Features of your vehicle WARNING - Objects • Do not place objects on the cargo area cover. Such objects may be thrown about inside the vehicle and possibly injure vehicle occupants during an accident or when braking. • All cargo should be evenly distributed, properly secured and never piled higher than the seatback.

  • Page 257: Audio System

    Features of your vehicle AUDIO SYSTEM If you install aftermarket HID head Antenna CAUTION - Antenna lamps, your vehicle’s audio and elec- tronic devices may malfunction. Before entering a place with a low height clearance or a car wash, remove the antenna pole by rotating it counterclockwise.

  • Page 258: Audio Remote Control

    Features of your vehicle VOLUME (VOL+/ VOL-) (1) Audio remote control WARNING - Distracted (if equipped) • Push the VOL + to increase volume. Driving • Push the VOL - to decrease volume. Driving while distracted can result in a loss of vehicle control SEEK/PRESET ( ) (2) that may lead to an accident,...

  • Page 259: Aux, Usb And Ipod ® Port

    Features of your vehicle ® RADIO mode Aux, USB and iPod * port When using a portable audio device connected to the power outlet, noise It will function as the PRESET STA- may occur during playback. If this TION select buttons. happens, use the power source of the portable audio device.

  • Page 260: Speaker Lights

    Features of your vehicle ✽ ✽ NOTICE Speaker lights (if equipped) 1. OFF : The light turns off. 2. MUSIC : When the doors are opened, the lighting system will not operate. The red light blinks according to the sound of the audio. If the audio is not turned on, the light does not turn on.

  • Page 261: How Vehicle Audio Works

    Features of your vehicle How vehicle audio works This can be due to factors, such as AM reception the distance from the radio station, FM reception closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area.
  • Page 262 Features of your vehicle FM radio station JBM003 JBM004 JBM005 • Station Swapping - As an FM sig- FM broadcasts are transmitted at • Fading - As your vehicle moves high frequencies and do not bend to away from the radio station, the nal weakens, another more power- follow the earth's surface.
  • Page 263 Features of your vehicle Using a cellular phone or a two- WARNING WARNING - Cell phone - Audio System way radio Do not disassemble, assemble, When a cellular phone is used inside Do not use a cellular phone or modify the audio system. the vehicle, noise may be produced while driving.
  • Page 264 Features of your vehicle • Pay attention to the volume setting CAUTION WARNING - Distracted when turning the device on. A sud- Driring den output of extreme volume • When cleaning the device, upon turning the device on could make sure to turn off the Driving while distracted can lead to hearing impairment.

  • Page 265: Using The Usb Device

    Features of your vehicle USING THE USB DEVICE (Continued) (Continued) • An encrypted MP3 PLAYER is • You may hear a strange noise • To use an external USB device, not recognizable. when connecting or disconnect- make sure the device is not con- ing a USB device.
  • Page 266 Features of your vehicle (Continued) (Continued) • If you use devices such as a • Some USB flash memory read- USB hub purchased separately, ers (such as CF, SD, micro SD, the vehicle’s audio system may etc.) external-HDD type not recognize the USB device. In devices can be unrecognizable.

  • Page 267: Using Ipod Device

    Features of your vehicle ® USING iPod DEVICE (Continued) (Continued) • Some iPod devices, such as the • When connecting iPod with the ® ® iPhone is a registered grademark of ® iPhone connected iPod Power Cable, insert the con- ®...

  • Page 268: Bluetooth Wireless Technology

    • Bluetooth refers to a short-distance ® Bluetooth SIG, lnc. and any use of wireless networking technology such marks by Kia is under license. which uses a 2.4GHz ~ 2.48GHz frequency connect various A Bluetooth ®...

  • Page 269: Precautions For Safe Driving

    Features of your vehicle When connecting a Bluetooth Precautions for Safe Driving ® • Park the vehicle when connecting Phone the head unit with the mobile phone. • Bluetooth Handsfree is a feature ® • Bluetooth connection ® • Before connecting the head unit that enables drivers to practice become intermittently disconnect- with the mobile phone, check to...

  • Page 270: Voice Recognition

    Features of your vehicle Voice Recognition (Continued) - When driving on rugged and uneven roads • When using the voice recognition - During severe rain (heavy rains, feature, only commands listed windstorms) within the user's manual are sup- ported. • Phone related voice commands used only when...
  • Page 271 Features of your vehicle ■ ■ AUDIO : AM1A0B2AN, AM1A0B2KN PS34001N 4 141...

  • Page 272: Audio

    Features of your vehicle ❈ In Setup>Display, the radio pop up SYSTEM CONTROLLERS SETUP CLOCK screen will be displayed when AND FUNCTIONS Briefly press the key (under 0.8 sec- [Mode Pop up] is turned onds) : Moves to the Display, Sound, When the pop up screen is dis- ❈...
  • Page 273 Features of your vehicle (6) PWR/VOL knob SCAN Power : Turns power On/Off by Radio mode pressing the knob - Shortly press the key : Previews Volume : Sets volume by turning each broadcast for 5 seconds the knob left/right each.
  • Page 274 Features of your vehicle (11) BACK (13) TUNE knob Go to previous depth(no previous AM/FM mode : screen) - Changes frequency by turning the knob left/right. (12) SiriusXM Radio Mode: ® FOLDER Radio mode - Changes the station by turning the knob left/right.
  • Page 275 Features of your vehicle SETUP Mode Pop up [Mode Pop up] Changes selection mode Display Settings • During On state, press the RADIO key to display the mode MEDIA SETUP change pop up screen. Press key Select CLOCK [Display] through TUNE knob or key Select menu through Media Display...
  • Page 276 Features of your vehicle SOUND SETTINGS Sound Settings Speed Dependent Volume Control This feature will gradually increase This menu allows you to set the the volume as speed increases to ‘Bass, Middle, Treble’ and the Sound SETUP Press key Select CLOCK offset outside noise.
  • Page 277 Features of your vehicle ❈ Adjust the number currently in CLOCK SETTINGS Sound Settings focus to make the settings and This menu is used to set the time. press the tune knob to move to the SETUP Select [Clock Settings] Set through next setting.
  • Page 278 Features of your vehicle SYSTEM SETTINGS Memory Information • Off : This mode is for expert users and omits some information during Displays currently used memory and voice command operation. (When total system memory. SETUP using Expert mode, guidance Press key Select CLOCK Select [Memory Information] OK...
  • Page 279 Features of your vehicle RADIO : FM, AM OR SIRIUS ® Preset SEEK Selecting through manual search Press the Turn the TUNE knob left/right to • Briefly pressing the key (under 0.8 adjust the frequency. seconds): Plays the frequency saved in the corresponding key. •...
  • Page 280 Features of your vehicle MENU Within key are the A.Store MENU (Auto Store) and Info functions. A.Store Press the key Set [A.Store] MENU through TUNE knob or key. Saves broadcasts with superior reception to keys. If no frequencies are received, then the most recently received frequency will be broadcast.

  • Page 281: Siriusxm ® Satellite Radio Information

    Features of your vehicle ® Satellite Radio reception SiriusXM Satellite Radio service: SiriusXM Satellite Radio factors: information SiriusXM is a subscription-based To receive the satellite signal, your satellite radio service that broad- vehicle has been equipped with a casts music, sports, news and enter- Satellite Radio channels: tainment programming to radio satellite radio antenna located on the...
  • Page 282 Features of your vehicle For information on extended sub- NOTE: scription terms, contact SiriusXM at SiriusXM services require a sub- 1-888-539-7474. scription sold separately, or as a package, by Sirius XM Radio Inc. If you decide to continue service after your trial, the subscription plan you choose will automatical- ly renew thereafter and you will be charged according to your chosen...
  • Page 283 SiriusXM • Shortly pressing the key (under 0.8 in order for the radio to receive the seconds): Previews each broad- Your Kia vehicle is equipped with a 3- activation signal. cast for 10 seconds each month trial subscription to SiriusXM ❈...
  • Page 284 Info (Information) antenna or antenna cable is bro- Displays the Artist/Song info of the ken or unplugged. Please consult current song. with your Kia dealership. 2. Acquiring Signal If this message is displayed, it means that the antenna is covered ®...
  • Page 285 Features of your vehicle BASIC METHOD OF USE : Repeat Random While song (file) is playing While song (file) is playing USB / iPod / My Music ® (RPT) key (RDM) key USB, iPod , My Music mode: RPT on My Music mode: RDM on screen ®...
  • Page 286 Features of your vehicle Changing Song/File Scan Folder Search : USB Mode While file playing While song (file) playing While song (file) is playing SCAN FOLDER (Folder Up) key SEEK TRACK • Searches the next folder. • Shortly pressing the key : Scans all •...
  • Page 287 Features of your vehicle MENU : USB Folder Random Information Press the USB mode key to MENU Press the key Set [ F.RDM] Press the key Set [ Info] MENU MENU set the Repeat, Folder Random, through the TUNE knob or through the TUNE knob or Folder...
  • Page 288 Features of your vehicle Copy MENU : iPod Information ® In iPod mode, press the ® MENU Press the key Set [ Copy] Press the key Set [ Info] MENU MENU Repeat, Random, through the TUNE knob or through the TUNE knob or key.
  • Page 289 Features of your vehicle MENU : My Music Mode Random Delete Press the key Set [ RDM] Press the key Set [ Delete] MENU MENU through the TUNE knob or through the TUNE knob or In My Music mode, press the MENU key to set the Repeat, Random, key.
  • Page 290 Features of your vehicle Delete Selection My Music • Even if memory is available, a AUX is used to play external MEDIA Press the key Set [ MENU maximum of 6,000 songs can be currently connected with the AUX Del.Sel] through the TUNE knob stored.
  • Page 291 Bluetooth SIG, Inc. and any use of [Audio Streaming] of Phone is such marks by Kia is under license. turned What is Bluetooth Wireless Other trademarks and trade names ®...
  • Page 292 Features of your vehicle Starting Bluetooth Using the Bluetooth ® Wireless ® Wireless Technology Audio Technology audio features • Press the key to change • Play / Stop MEDIA the mode in order of USB➟AUX Press the TUNE knob to play and ➟My Music➟BT Audio.
  • Page 293 Features of your vehicle PHONE(IF EQUIPPED) Making a call using the USB, iPod ® , My Music Modes Steering-wheel mounted controls - Briefly press the key: Move to next or previous song. Before using the Bluetooth Wireless ® - Press and hold the key: Rewinds Technology phone features or fast-forwards the current song.
  • Page 294 ➁ The most recently called number are registered trademarks owned by is redialed. Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth ®...
  • Page 295 Features of your vehicle 2.Select [OK] button to enter the Pair [Non SSP supported device] Pairing Key / PHONE Phone screen. on the Steering Remote (SSP: Secure Simple Pairing) Controller 4.After a few moments, a screen is displayed where the passkey is entered.
  • Page 296 " and "Visit http://www.kia.com/us/en/content/own ers/bluetooth for additional information on pairing your Bluetooth-enabled mobile phone, and to view a phone compatibility list.
  • Page 297 Features of your vehicle • Bluetooth Bluetooth Pairing through [PHONE] Wireless Technology • Only ® Wireless ® Setup features supported within the vehi- Technology Handsfree cle are as follows. Some features Bluetooth audio related features may not be supported depending are supported.
  • Page 298 Features of your vehicle • After pairing is complete, a con- Connecting a Device From the paired phone list, select the tacts download request is sent device you want to connect and once to the mobile phone. Some select [Connect]. SETUP Press key Select...
  • Page 299 Features of your vehicle Changing Priority From the paired phone list, select • Priority icon will be displayed when the phone you want to switch to the the selected phone is set as a pri- highest priority, then select [Change ority phone.
  • Page 300 Features of your vehicle Disconnecting a Device Deleting a Device • When deleting the currently con- nected device, the device will auto- matically be disconnected to pro- SETUP SETUP Press key Select Press key Select ceed with the deleting process. CLOCK CLOCK [Phone] Select [Phone List]...
  • Page 301 Features of your vehicle • If you select the [Call History] but- Answering Calls USING Bluetooth Wireless ® ton but there is no call history data, Technology(if equipped) a prompt is displayed which asks to download call history data. Answering a Call Phone Menu Screen Answering a call with a Bluetooth ®...
  • Page 302 Features of your vehicle • When an incoming call pop-up is Favorites Call History displayed, most Audio and SETUP mode features are disabled. Only Press the Select Press the Select [Call the call volume will operate. PHONE PHONE [Favorites] History] •...
  • Page 303 Features of your vehicle Contacts • Up to 1,000 contacts saved in your • It is not possible to begin down- Bluetooth Wireless Technology loading a contact list when the con- ® phone can be downloaded into the tact download feature has been Press key Select PHONE...
  • Page 304 ® are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth enabled cell phone is ®...
  • Page 305 Features of your vehicle Downloading Contacts Outgoing Volume 1) Connect/Disconnect Phone SETUP SETUP Connect/ disconnects currently Press key Select Press key Select CLOCK CLOCK selected phone [Phone] Select [Contacts Download] [Phone] Select [Outgoing Volume] 2) Change Priority : Sets currently selected phone to highest connec- tion priority 3) Delete : Deletes the currently...
  • Page 306 Features of your vehicle Turning Bluetooth System Off SETUP Press key Select CLOCK [Phone] Select [Bluetooth System Off] Once Bluetooth Wireless Technology ® is turned off, Bluetooth Wireless ® Technology related features will not be supported within the audio sys- tem.
  • Page 307 Features of your vehicle Skipping Prompt Messages VOICE RECOGNITION If prompt feedback is in [ON], then the system will say “Please say a While prompt message is being stat- command after the beep (BEEP)” ed Shortly press the key on the Using Voice Recognition •...
  • Page 308 Contact Tips: “County Finance Department” instead of “CFD”). The Kia Voice Recognition System • If a name is not recognized from may have difficulty understanding While Voice Recognition is operating the contact list, change it to a more some accents or uncommon...
  • Page 309 Features of your vehicle Illustration on using voice commands More Help Here are some examples of mode commands. • Starting voice command. You can say a radio type like 'FM', 'AM', or 'Satellite'. Shortly pressing the key (under 0.8 seconds): You can also say a media source like 'USB', 'My Music', or 'iPod ®...

  • Page 310: Voice Command List

    Features of your vehicle Voice Command List • Common Commands: These commands can be used in most operations. (However a few commands may not be available during certain operations) Command Function Command Function More Help Provides guidance on commands that can be Contacts Displays the Contacts screen.
  • Page 311 Features of your vehicle Command Function Command Function FM Preset 1~6 Plays the most recently played broadcast My Music Plays the music saved in My Music. saved in FM Preset 1~6. AUX (Auxiliary) Plays the connected external device. AM Preset 1~6 Plays the broadcast saved in AM Preset 1~6.
  • Page 312 Features of your vehicle • FM/AM radio commands: Commands available during • Satellite radio commands: Commands that can be FM, AM radio operation. used while listening to Satellite Radio. Command Function Command Function Preset 1~6 Plays the broadcast station saved in Preset 1~6. Channel 0~223 Plays the selected Satellite Radio channel.
  • Page 313 Features of your vehicle • USB commands: Commands available during USB • iPod Commands: Commands available during iPod ® ® operation. operation. Command Function Command Function Random Randomly plays the files within the current Random Randomly plays the songs within the current folder.
  • Page 314 Features of your vehicle • Bluetooth ® • My Music Commands: Commands available during Wireless Technology Audio Commands: Commands available during Bluetooth My Music operation. Wireless ® Technology audio streaming from mobile phone oper- ation Command Operation. Command Function Random Randomly plays all saved files.
  • Page 315 Bluetooth SIG, Inc. and any use of such marks by Kia is under license. SiriusXM services require a subscription sold sep- arately, or as a package, by Sirius XM Radio Inc. If...

  • Page 316: Driving Your Vehicle

    Driving your vehicle Before driving ......5-3 Cruise control system..... . . 5-32 •...
  • Page 317 Winter driving ......5-44 • Snowy or icy conditions ..... . . 5-44 •...

  • Page 318: Before Driving

    Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside Fluid levels, such as coolant, brake • Close and lock all doors. mirror(s), and outside lights are fluid, and washer fluid should be •...
  • Page 319 Driving your vehicle WARNING WARNING WARNING - Check sur- - Loose - Driving while roundings objects intoxicated Always check the surrounding Securely store items in your Do not drive while intoxicated. areas near your vehicle for peo- vehicle. When you make a sud- Drinking and driving is danger- ple, especially children, before den stop or turn the steering...

  • Page 320: Power Button

    Driving your vehicle POWER BUTTON Illuminated POWER button POWER button position ACC (Accessory) Amber Not illuminated Press the POWER button while it is To turn off the vehicle, press the in the OFF position without depress- POWER button with the shift lever in ing the brake pedal.
  • Page 321 Driving your vehicle START/RUN WARNING - Starting vehicle Never press the POWER button while the vehicle is in motion Redish orange Not illuminated except in an emergency. If the vehicle stops while the vehicle Press the POWER button while it is To start the vehicle, depress the is in motion, this would result in in the ACC position without depress-...

  • Page 322: Starting The Vehicle

    Driving your vehicle Starting the vehicle • Even if the smart key is in the vehi- CAUTION cle, if it is far away from you, the 1. Carry the smart key or leave it vehicle may not start. If the vehicle stalls while the inside the vehicle.
  • Page 323 Driving your vehicle • When the stop lamp fuse is blown, WARNING - Unintended you can't start the vehicle normally. vehicle movement Replace the fuse with a new one. If it is not possible, you can start the Never leave the smart key in the vehicle by pressing the POWER vehicle with children or vehicle button for 10 seconds while it is in...

  • Page 324: Pedestrian Warning System

    Driving your vehicle ✽ ✽ NOTICE Pedestrian Warning System Turing off the Vehicle If the " (ready)" indicator light The Pedestrian Warning System on the instrument cluster is still on, generates engine sound for pedestri- be careful that the vehicle is not ans to hear vehicle sound because there is little sound while the Electric turned off and can move when you...

  • Page 325: Active Eco Operation

    Driving your vehicle ACTIVE ECO SYSTEM Active ECO operation • When the Active ECO is activated, it will remain on until the Active ECO button is pressed again. Active ECO does not turn off when the vehicle is restarted. To turn off Active ECO, press the Active ECO button again.

  • Page 326: Reduction Gear

    Driving your vehicle REDUCTION GEAR Depress the brake pedal and the lock release button when shifting. Press the lock release button when shifting. The shift lever can be shifted freely. OPSE054007 5 11...

  • Page 327: Reduction Gear Operation

    Driving your vehicle Transaxle ranges Reduction gear operation CAUTION - Reduction The indicator in the instrument clus- gear ter displays the shift lever position WARNING - Leaving the To avoid damage to your reduc- when the POWER button is in the vehicle tion gear, do not accelerate the ON position.
  • Page 328 Driving your vehicle R (Reverse) N (Neutral) B (Regenerative brake): maximum regenerative braking mode Use this position to drive the vehicle The wheels and gear are not backward. engaged. The vehicle will roll freely Use it when you desire to use regen- even on the slightest incline unless erative braking.
  • Page 329 3. Move the shift lever. 4. Have your vehicle inspected by an authorized Kia dealer immediately. • While the charging cable is con- nected, you cannot use the shift lever for safety reasons.

  • Page 330: Good Driving Practices

    Driving your vehicle Moving up a steep grade from a Good driving practices standing start • Never move the gear shift lever To move up a steep grade from a from P (Park) to any other position standing start, depress the brake with accelerator pedal...

  • Page 331: Brake System

    Take your vehicle to they have been affected in this way. Do not drive with your foot rest- an authorized Kia dealer and have Always test your brakes in this fash- ing on the brake pedal. This will the system checked.
  • Page 332 Driving your vehicle In the event of brake failure Disc brakes wear indicator WARNING - Brake wear If service brakes fail to operate while When your brake pads are worn and the vehicle is in motion, you can new pads are required, you will hear Do not ignore high pitched make an emergency stop with the a high-pitched warning sound from...

  • Page 333: Electric Parking Brake (Epb)

    Driving your vehicle ✽ ✽ NOTICE Releasing the parking brake Electric parking brake (EPB) A click or electric brake motor Applying the parking brake whine sound may be heard while operating or releasing the EPB, but these conditions are normal and indicate that the EPB is functioning properly.
  • Page 334 Do not follow the above procedure R (Reverse) or D (Drive). checked by an authorized Kia dealer. when driving on a flat level ground. 1. The vehicle is in the ready ( The vehicle may suddenly move for- EPB (electric parking brake) may be mode.
  • Page 335 Driving your vehicle System warning If the above situation occurs, depress • A click or electric brake motor the brake pedal and release EPB by whine sound may be heard while pressing the EPB switch. operating or releasing the EPB, but these conditions are normal and indicate that the EPB is functioning WARNING...
  • Page 336 Driving your vehicle EPB malfunction indicator If this occurs, have your vehicle • The EPB warning light may illumi- checked by an authorized Kia dealer nate if the EPB switch operates as soon as possible. abnormally. Shut the vehicle power...

  • Page 337: Anti-Lock Brake System (Abs)

    Do not operate the electric park- should be driven at reduced speeds Kia dealer by loading the vehicle on ing brake while the vehicle is in the following circumstances: a flatbed tow truck and have the sys- moving except in an emergency •...
  • Page 338 ABS to on, you may have a problem with operation of the anti-lock brake control the force being delivered to your ABS. Contact an authorized Kia system may result in a longer stop- the brakes. dealer as soon as possible.

  • Page 339: Electronic Stability Control (Esc)

    - including driving at safe speeds ABS system is normal. Otherwise, for the conditions. you may have a problem with the ABS. Contact an authorized Kia The Electronic Stability Control (ESC) dealer as soon as possible. system is an electronic system...
  • Page 340 Driving your vehicle ✽ ✽ NOTICE ESC operation When operating When the ESC is in opera- ESC ON condition A click sound may be heard in the tion, the ESC indicator light motor compartment when the vehi- • When the POWER button blinks.
  • Page 341 Driving your vehicle ESC operation off ESC OFF state This car has 2 kinds of ESC off states. If the POWER button is turn off when ESC is off, ESC remains off. Upon restarting the vehicle, the ESC will automatically turn on again. OPSE054013L OPSE054014L •...
  • Page 342 Driving your vehicle Indicator light ESC OFF usage CAUTION When driving ■ ESC indicator light Driving with varying tire or • ESC should be turned on for daily wheel sizes may cause the ESC driving whenever possible. system to malfunction. When •...

  • Page 343: Vehicle Stability Management (Vsm)

    Driving your vehicle ✽ ✽ NOTICE Vehicle stability management The VSM does not operate when: (VSM) • Driving on bank road such as gra- • When operating the vehicle on a dient or incline dynamometer, ensure that the This system provides further ESC is turned off (ESC OFF light...

  • Page 344: Hill-Start Assist Control (Hac)

    2 seconds. authorized Kia dealer and have the even with installed VSM. Always The HAC is activated only for about 2 system checked.

  • Page 345: Good Braking Practices

    Kia dealer for assis- and stop in a safe place. tance.
  • Page 346 Driving your vehicle • If your vehicle is equipped with an • Under some conditions your park- automatic transaxle, don't let your ing brake can freeze in the vehicle creep forward. To avoid engaged position. This is most like- creeping forward, keep your foot ly to happen when there is an firmly on the brake pedal when the accumulation of snow or ice...

  • Page 347: Cruise Control System

    Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) • If the cruise control is left on WARNING - Misuse of (CRUISE indicator light in the instrument cluster illuminated), the Cruise Control cruise control can be switched on Do not use cruise control if the accidentally.

  • Page 348: Cruise Control Switch

    Driving your vehicle Cruise control switch To set cruise control speed: OPS053018 3. Push the SET - switch, and OPS053016 OPS053017 release it at the desired speed. CRUISE : Turns cruise control sys- 1. Press the CRUISE button on the The SET indicator light in the tem on or off.

  • Page 349: To Increase Cruise Control Set Speed

    Driving your vehicle To increase cruise control set To decrease the cruising To temporarily accelerate with speed: speed: the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed.

  • Page 350: To Cancel Cruise Control, Do One Of The Following

    Driving your vehicle Each of these actions will cancel To cancel cruise control, do To resume cruising speed at cruise control operation (the SET one of the following: more than approximately 20 indicator light in the instrument clus- mph (30 km/h): ter will go off), but it will not turn the system off.

  • Page 351: To Turn Cruise Control Off, Do One Of The Following

    Driving your vehicle To turn cruise control off, do one of the following: OPS053017 • Press the CRUISE button (the CRUISE indicator light in the instrument cluster will go off). • Turn the vehicle off. Both of these actions cancel cruise control operation.

  • Page 352: Economical Operation

    Driving your vehicle ECONOMICAL OPERATION Your vehicle's energy economy • Drive at a moderate speed. The • Be sure that the wheels are depends mainly on your style of driv- faster you drive, the more energy aligned correctly. Improper align- ment can result from hitting curbs ing, where you drive and when you your vehicle uses.
  • Page 353 Driving your vehicle • Travel lightly. Don't carry unneces- WARNING sary weight in your vehicle. Weight reduces energy economy. - Vehicle off during motion • Open windows at high speeds can Never turn the POWER button reduce energy economy. off to coast down hills or any- time the vehicle is in motion.

  • Page 354: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions • If stalled in snow, mud, or sand, Reducing the risk of a rollover use second gear. Accelerate slow- When hazardous driving conditions This multi-purpose passenger vehi- ly to avoid spinning the drive are encountered such as water, cle is defined as a Crossover Utility wheels.

  • Page 355: Rocking The Vehicle

    Driving your vehicle If at all possible, avoid sharp turns or Rocking the vehicle CAUTION - Vehicle rocking abrupt maneuvers, do not load your If it is necessary to rock the vehicle roof rack with heavy cargo, and Prolonged rocking may cause to free it from snow, sand, or mud, never modify your vehicle in any way.

  • Page 356: Smooth Cornering

    Driving your vehicle Smooth cornering Driving at night • Adjust your mirrors to reduce the glare from other driver's head- lights. • Keep your headlights clean and properly aimed. (On vehicles not equipped with the automatic head- light aiming feature.) Dirty or improperly aimed headlights will make it much more difficult to see at night.

  • Page 357: Driving In The Rain

    Driving your vehicle Driving in the rain • A heavy rainfall will make it harder Driving in flooded areas to see and will increase the dis- Avoid driving through flooded areas tance needed to stop your vehicle, unless you are sure the water is no so slow down.

  • Page 358: Driving Off-Road

    Driving your vehicle Driving off-road WARNING WARNING - Under/over - Tire tread Drive carefully off-road because your inflated tires Always check the tire tread vehicle may be damaged by rocks or Always check the tires for prop- before driving your vehicle. roots of trees.

  • Page 359: Winter Driving

    Driving your vehicle WINTER DRIVING Snow tires Snowy or icy conditions If you mount snow tires on your vehi- To drive your vehicle in deep snow, it cle, make sure they are radial tires of may be necessary to use snow tires the same size and load range as the or to install tire chains on your tires.
  • Page 360 Driving your vehicle Tire chains When using tire chains, install them When mounting snow chains, park on the front tires only. the vehicle on level ground away from traffic. Turn on the vehicle Hazard Warning flashers and place a triangu- CAUTION - Snow chains lar emergency warning device behind...

  • Page 361: Use High Quality Ethylene Glycol Coolant

    Kia dealer or a service tions on the container. Window wash- • Stop driving and retighten the station. er anti-freeze is available from an...

  • Page 362: Don't Let Ice And Snow Accumulate Underneath

    Driving your vehicle TRAILER TOWING Don't let ice and snow accu- We do not recommend using this mulate underneath vehicle for trailer towing. Under some conditions, snow and ice can build up under the fenders and interfere with the steering. When driving in severe winter conditions where this may happen, you should periodically check underneath the...

  • Page 363: Vehicle Load Limit

    Driving your vehicle VEHICLE LOAD LIMIT Vehicle capacity weight: Towing capacity: Tire and loading information label We do not recommend using this 827 lbs. (375 kg) vehicle for trailer towing. Vehicle capacity weight is the maxi- mum combined weight of occupants and cargo.
  • Page 364 Driving your vehicle Cargo capacity: Steps for determining correct 6. If your vehicle will be towing a trail- load limit er, load from your trailer will be The cargo capacity of your vehicle transferred your vehicle. will increase or decrease depending 1.
  • Page 365 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 1400 lbs Vehicle Capacity 1400 lbs Vehicle Capacity 1400 lbs Weight (635 kg) Weight (635 kg) Weight (635 kg) Subtract Occupant Subtract Occupant...

  • Page 366: Certification Label

    Driving your vehicle Certification label To find out the actual loads on your The label will help you decide how front and rear axles, you need to go much cargo and installed equipment to a weigh station and weigh your your vehicle can carry.
  • Page 367 Driving your vehicle WARNING WARNING - Over loading - Loose cargo Do not overload your vehicle. Do not travel with unsecured Overloading your vehicle can blunt objects in the passenger cause heat buildup in your vehi- compartment of your vehicle cle's tires and possible tire fail- (e.g.

  • Page 368: Vehicle Weight Glossary

    Driving your vehicle VEHICLE WEIGHT GLOSSARY This section will guide you in the Cargo weight GVWR proper loading of your vehicle and/or (Gross vehicle weight rating) This figure includes all weight added trailer, to keep your loaded vehicle to the Base Curb Weight, including This is the maximum allowable weight within its design rating capa- cargo and optional equipment.

  • Page 369: What To Do In An Emergency

    What to do in an emergency Road warning ......6-2 Towing ........6-20 •...

  • Page 370: Road Warning

    What to do in an emergency ROAD WARNING Hazard warning flasher Depress the flasher switch with the ignition switch in any position. The flasher switch is located in the center console switch panel. All turn signal lights will flash simultaneously. •...

  • Page 371: In Case Of An Emergency While Driving

    3. Try to start the vehicle again. If from traffic. If you have a flat tire while your vehicle will not start, contact 4. When changing a flat tire, follow an authorized Kia dealer or seek driving the instruction provided later in other qualified assistance. this section.

  • Page 372: If The Vehicle Will Not Start

    What to do in an emergency IF THE VEHICLE WILL NOT START If vehicle doesn't turn over or WARNING - Push/pull turns over slowly start 1. Be sure the shift lever is in N Do not push or pull the vehicle (Neutral) or P (Park) and the to start it.

  • Page 373: Emergency Starting

    What to do in an emergency EMERGENCY STARTING Jump starting Jumper Cables WARNING - Battery Jump starting can be dangerous if Never attempt to check the elec- done incorrectly. Therefore, to avoid trolyte level of the battery as harm to yourself or damage to your this may cause the battery to vehicle or battery, follow these jump rupture or explode causing seri-...
  • Page 374 What to do in an emergency Jump starting procedure Do not allow the jumper cables to WARNING - Battery contact anything except the cor- 1. Make sure the booster battery is rect battery terminals or the cor- Keep all flames or sparks away 12-volt and that its negative termi- rect ground.

  • Page 375: Push-Starting

    If the cause of your battery discharg- could cause a collision with the ing is not apparent, you should have towing vehicle. your vehicle checked by an author- ized Kia dealer.

  • Page 376: If The Vehicle Overheats

    If overheating happens again, cle. (If the air conditioning had call an authorized Kia dealer for been in use, it is normal for cold assistance. water to be draining from it when Serious loss of coolant indicates you stop).

  • Page 377: Tire Pressure Monitoring System (Tpms)

    What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if pro- Please note that the TPMS is not a vided), should be checked monthly substitute for proper tire mainte- when cold and inflated to the inflation nance, and it is the driver’s responsi- pressure recommended by the vehi- bility to maintain correct tire pres-...
  • Page 378 3 seconds, take your vehicle placard or tire inflation pressure label leads to a proportional lowering of to your nearest authorized Kia deal- located on the driver’s side center pil- tire pressure. er and have the system checked.
  • Page 379 Monitoring System. Have the system or transmitting towers, etc. This can vehicle control. checked by an authorized Kia dealer interfere with normal operation of as soon as possible to determine the Tire Pressure Monitoring cause of the problem.

  • Page 380: Changing A Tire With Tpms

    Kia dealer as soon as possible or be deactivated. If the TPMS sensor After you replace the low pressure replace the flat tire with the spare...
  • Page 381 What to do in an emergency You may not be able to identify a low • The TPMS cannot alert you to This device complies with Part tire by simply looking at it. Always severe and sudden tire damage 15 of the FCC rules. use a good quality tire pressure caused by external factors such as Operation is subject to the following...

  • Page 382: If You Have A Flat Tire (With Tire Mobility Kit)

    Kia deal- car tire caused by nails or similar er as soon as possible. objects and reinflates the tire.
  • Page 383 • Use of the Tire Mobility Kit may not the sealant bottle! be effective for tire damage larger than approximately 0.24 in (6 mm). Please contact the nearest Kia dealership if the tire cannot be made roadworthy with the Tire Mobility Kit.

  • Page 384: Components Of The Tire Mobility Kit

    What to do in an emergency 9. Hose to connect compressor and Components of the Tire Mobility Kit sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing. WARNING - Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.

  • Page 385: Using The Tire Mobility Kit

    What to do in an emergency Using the Tire Mobility Kit 1. Detach the speed restriction label (0) from the sealant bottle (1), and place it in a highly visible place inside the vehicle such as on the steering wheel to remind the driv- er not to drive too fast.

  • Page 386: Distributing The Sealant

    29 PSI(200kpa). This Therefore, remove the tire pressure could result in an accident due sensors and wheel stained by to sudden tire failure. sealant and we recommend that inspect at an authorized Kia dealer.

  • Page 387: Technical Data

    - To increase the inflation pres- including sealant Sealant volume: sure : Switch on the compres- approved by Kia, the tire pres- 12.2 cu. in. (200 ml) sor, position I. To check the cur- sure sensors may be damaged rent inflation pressure setting, by sealant.

  • Page 388: Towing

    Use wheel lift or ation as a rollover. we recommend having it done by an flatbed equipment. authorized Kia dealer or a commer- cial tow-truck service. Proper lifting and towing procedures are neces- sary to prevent damage to the vehi- cle.

  • Page 389: Removable Towing Hook (Front)

    What to do in an emergency Removable towing hook CAUTION WARNING - Towing gear - Towing EV ■ Front position Never tow the vehicle with the Failure to place the shift lever in front wheels on the ground (for- N (Neutral) may cause internal ward or backward), as this may damage to the transaxle.

  • Page 390: Emergency Towing

    OPSE064009 • The drivers of both vehicles should If towing is necessary, we recom- communicate with each other fre- mend you to have it done by an quently. authorized Kia dealer or a com- mercial tow truck service.
  • Page 391 What to do in an emergency Emergency towing precautions • Attach a towing strap to the tow hook. • Turn the ignition switch to ACC so • Using a portion of the vehicle other the steering wheel isn’t locked. than the tow hooks for towing may •...
  • Page 392 What to do in an emergency CAUTION To avoid serious damage to the reduction gear, limit the vehicle speed to 10 mph (15 km/h) and drive less than 1 mile (1.5 km) when towing. ✽ ✽ NOTICE Before towing, check the reduction gear for fluid leaks under your vehi- cle.

  • Page 393: Maintenance

    Maintenance Motor room compartment....7-3 Tires and wheels ......7-36 •...

  • Page 394: Motor Room Compartment

    Maintenance MOTOR ROOM COMPARTMENT 1. Coolant reservoir 2. Brake fluid reservoir 3. Fuse box 4. Positive battery terminal 5. Negative battery terminal 6. Radiator cap 7. Windshield washer fluid reservoir ❈ The actual motor compartment in the vehicle may differ from the illustration. OPSE075001...

  • Page 395: Maintenance Services

    Kia dealer meets Kia’s high service tion procedures. quality standards and receives tech- Maintenance Service and Record nical support from Kia in order to pro- Retention are the owner's responsi- Should you have any doubts con- vide you with a high level of service bility.

  • Page 396: Owner Maintenance Precautions

    As explained earlier in this section, become entangled in moving several procedures can be done only parts, if you must run the vehi- by an authorized Kia dealer with spe- cle in the ready ( ) mode while cial tools.

  • Page 397: Owner Maintenance

    When you stop for fuel: formed by the owner or an author- wheel. Notice any increased steer- • Check the coolant level in the ized Kia dealer at the frequencies ing effort or looseness in the steer- coolant reservoir. indicated to help ensure safe,...
  • Page 398 Maintenance At least monthly: At least once a year: • Check the coolant level in the • Clean the body and door drain coolant reservoir. holes. • Check the operation of all exterior • Lubricate the door hinges and lights, including the stoplights, turn checks, and hood hinges.

  • Page 399: Scheduled Maintenance Service

    Maintenance SCHEDULED MAINTENANCE SERVICE If your vehicle is operated under the Follow the Normal Maintenance above conditions, should Schedule if the vehicle is usually inspect, replace or refill more fre- operated where none of the following conditions apply. If any of the follow- quently than the following Normal ing conditions apply, follow the Maintenance Schedule.
  • Page 400 Maintenance NORMAL MAINTENANCE SCHEDULE The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the fre- quency of service is determined by whichever occurs first. : When adding coolant, use only deionized water or soft water for your vehicle and never mix hard water in the coolant filled at the factory.
  • Page 401 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 7,500 miles (12,000 km) or 6 months 15,000 miles (24,000 km) or 12 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Inspect air conditioning compressor, air conditioner refriger- ant and performance (if equipped) ant and performance (if equipped) ❑...
  • Page 402 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 22,500 miles (36,000 km) or 18 months 30,000 miles (48,000 km) or 24 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Rotate tires - including tire pressure and tread wear ant and performance (if equipped) (Every 3,750 miles (6,000 km) or 6 months) ❑...
  • Page 403 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 37,500 miles (60,000 km) or 30 months 45,000 miles (72,000 km) or 36 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Inspect reduction gear oil ❑ Rotate tires - including tire pressure and tread wear ant and performance (if equipped) ❑...
  • Page 404 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 52,500 miles (84,000 km) or 42 months 60,000 miles (96,000 km) or 48 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Rotate tires - including tire pressure and tread wear ant and performance (if equipped) (Every 3,750 miles (6,000 km) or 6 months) ❑...
  • Page 405 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 67,500 miles (108,000 km) or 54 months 75,000 miles (120,000 km) or 60 months ❑ Rotate tires - including tire pressure and tread wear ❑ Inspect air conditioning compressor, air conditioner refriger- (Every 3,750 miles (6,000 km) or 6 months) ant and performance (if equipped) ❑...
  • Page 406 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 82,500 miles (132,000 km) or 66 months 90,000 miles (144,000 km) or 72 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Rotate tires - including tire pressure and tread wear ant and performance (if equipped) (Every 3,750 miles (6,000 km) or 6 months) ❑...
  • Page 407 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 97,500 miles (156,000 km) or 78 months 105,000 miles (168,000 km) or 84 months ❑ Inspect air conditioning compressor, air conditioner refriger- ❑ Rotate tires - including tire pressure and tread wear ant and performance (if equipped) (Every 3,750 miles (6,000 km) or 6 months) ❑...
  • Page 408 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) 112,500 miles (180,000 km) or 90 months 120,000 miles (192,000 km) or 96 months ❑ Rotate tires - including tire pressure and tread wear ❑ Inspect air conditioning compressor, air conditioner refriger- (Every 3,750 miles (6,000 km) or 6 months) ant and performance (if equipped) ❑...
  • Page 409 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving Maintenance item...
  • Page 410 Maintenance Maintenance Driving Maintenance item Maintenance intervals operation condition Inspect more frequently C, D, E, F, Drive shaft and boots depending on the condition G, H, I, K Replace more frequently Climate control air filter (if equipped) C, E, G depending on the condition SEVERE DRIVING CONDITIONS A : Repeatedly driving short distance of less than 8 km (5...

  • Page 411: Explanation Of Scheduled Maintenance Items

    For more information on checking aged parts. the pads or lining wear limit, we rec- Brake fluid ommend you to refer to the Kia web- Check the brake fluid level in the site. Coolant brake fluid reservoir. The level should (http://www.kiatechinfo.com)
  • Page 412 Maintenance Steering gear box, linkage & Air conditioning refrigerant boots/lower arm ball joint Check the air conditioning lines and With the vehicle stopped and off, connections for leakage and dam- check for excessive free-play in the age. steering wheel. Check the linkage for bends or dam- age.

  • Page 413: Coolant

    Maintenance COOLANT The high-pressure cooling system Checking the coolant level Turn the vehicle off and wait until it has a reservoir filled with year round cools down. Use extreme care when antifreeze coolant. The reservoir is removing the radiator cap. Wrap a WARNING filled at the factory.
  • Page 414 If the coolant level is low, add enough 45%. specified coolant to provide protec- tion against freezing and corrosion. Bring the level to F, but do not over- fill. If frequent additions are required, see an authorized Kia dealer for a cooling system inspection.

  • Page 415: Changing The Coolant

    Maintenance For mixture percentage, refer to the Changing the coolant following table. Have the coolant changed by an authorized Kia dealer according to Mixture Percentage the Maintenance Schedule at the Ambient (volume) beginning of this chapter. Temperature Antifreeze Water Put a thick cloth around the radiator 5°F (-15°C)

  • Page 416: Brake Fluid

    Kia dealer. If the level is low, add fluid to the When changing and adding brake MAX level. The level will fall with fluid, handle it carefully.
  • Page 417 Maintenance CAUTION Brake fluid Do not allow brake fluid to con- tact the vehicle's body paint, as paint damage will result. Brake fluid, which has been exposed to open air for an extended time should never be used as its quality cannot be guaranteed.

  • Page 418: Washer Fluid

    Maintenance WASHER FLUID Checking the washer fluid WARNING WARNING - Flammable - Coolant level Fluid • Do not use radiator coolant or Do not allow the washer fluid to antifreeze in the washer fluid reservoir. come in contact with open flames or sparks.The windshield •...

  • Page 419: Climate Control Air Filter

    Maintenance CLIMATE CONTROL AIR FILTER Filter inspection & replacement The climate control air filter should be replaced according to the mainte- nance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
  • Page 420 Maintenance OPSE074021 OPS073011 3. Remove the climate control air fil- 4. Replace the climate control air filter. ter case by pulling out both sides 5. Reassemble in the reverse order of the cover. of disassembly. When replacing the climate control air filter install it properly.

  • Page 421: Wiper Blades

    Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
  • Page 422 Maintenance Front windshield wiper blade 1JBA7037 OHM078059 Type B 1LDA5023 1. Raise the wiper arm. Type A 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip. CAUTION - Wiper arms 1JBA7038 Do not allow the wiper arm to 2.
  • Page 423 Maintenance Rear window wiper blade OSBL071001 OSBL071002 4. Push down the wiper arm (3) and OHM078062 install the new blade assembly in 1. Raise the wiper arm and pull out the reverse order of removal. the wiper blade assembly. 5. Return the wiper arm on the wind- shield.
  • Page 424 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, have an authorized Kia dealer replace the wiper blade.

  • Page 425: Battery

    Maintenance BATTERY For best battery service Always read the following WARNING - Risk of instructions carefully when handling a battery. explosion Keep lit cigarettes and If any electrolyte gets into other flames your eyes, flush your eyes sparks away from the with clean water for at least battery.

  • Page 426: Battery Recharging

    Maintenance ✽ ✽ NOTICE Battery recharging WARNING - Risk of elec- If you connect unauthorized elec- Your vehicle has a maintenance-free, trocution tronic devices to the battery, the bat- calcium-based battery. Never touch the electrical igni- tery may be discharged. Never use •...

  • Page 427: Reset Items

    Maintenance When recharging battery, 1.Turn off the battery charger main Reset items observe the following precautions: switch. Items should be reset after the bat- • The battery must be removed from 2.Unhook the negative clamp from tery has been discharged or the bat- the vehicle and placed in an area the negative battery terminal.

  • Page 428: Tires And Wheels

    Maintenance TIRES AND WHEELS Tire care WARNING - Tire under For proper maintenance, safety, and inflation maximum fuel economy, you must Inflate your tire consistent with always maintain recommended tire the instructions provided in this inflation pressures and stay within manual.

  • Page 429: Checking Tire Inflation Pressure

    Use a good quality gauge to check • Never overload your vehicle. Be authorized Kia dealer. tire pressure. You cannot tell if your careful not to overload a vehicle • Overinflation produces a harsh...

  • Page 430: Tire Rotation

    Maintenance Remove the valve cap from the tire • Inspect your tires frequently for Tire rotation valve stem. Press the tire gauge firm- proper inflation as well as wear and To equalize tread wear, it is recom- ly onto the valve to get a pressure damage.

  • Page 431: Wheel Alignment And Tire Balance

    Maintenance Wheel alignment and tire bal- WARNING - Mixing tires ance Do not mix bias ply and radial The wheels on your vehicle were ply tires under any circum- aligned and balanced carefully at the stances. This may cause unusu- factory to give you the longest tire life al handling characteristics.

  • Page 432: Tire Replacement

    CAUTION - Wheels less than 1/16 inch (1.6 mm) of tread left on the tire. Replace the tire when Wheels that do not meet Kia this happens. specifications may fit poorly Do not wait for the band to appear and result in damage to the...

  • Page 433: Tire Traction

    Maintenance 2. Tire size designation Tire traction Tire sidewall labeling A tire’s sidewall is marked with a tire Tire traction can be reduced if you size designation. You will need this drive on worn tires, tires that are information when selecting replace- improperly inflated or on slippery ment tires for your vehicle.
  • Page 434 Maintenance P - Applicable vehicle type (tires Wheel size designation Tire speed ratings marked with the prefix “P’’ are Wheels are also marked with impor- The chart below lists many of the dif- intended for use on passenger tant information that you need if you ferent speed ratings currently being vehicles or light trucks;...
  • Page 435 Maintenance 3. Checking tire life (TIN : Tire 4. Tire ply composition and mate- WARNING - Tire age Identification Number) rial Replace tires within the recom- Any tires that are over 6 years old, The number of layers or plies of rub- mended time frame.
  • Page 436 Maintenance 6. Maximum load rating Tread wear Traction - AA, A, B & C This number indicates the maximum The tread wear grade is a compara- The traction grades, from highest to load in kilograms and pounds that tive rating based on the wear rate of lowest, are AA, A, B and C.
  • Page 437 Maintenance Temperature -A, B & C Tire terminology and definitions Cold Tire Pressure: The amount of air pressure in a tire, measured in The temperature grades are A (the Air Pressure: The amount of air pounds per square inch (psi) or kilo- highest), B and C representing the inside the tire pressing outward on pascals (kPa) before a tire has built...
  • Page 438 Maintenance Intended Outboard Sidewall: The Maximum Loaded Vehicle Weight: Pneumatic tire: A mechanical device made of rubber, chemicals, side of an asymmetrical tire, that The sum of curb weight; accessory weight; vehicle capacity weight; and fabric and steel or other materials, must always face outward when mounted on a vehicle.
  • Page 439 Vehicle Capacity Weight: The num- All season tires between the tread and the bead. ber of designated seating positions Kia specifies all season tires on multiplied by 150 lbs. (68 kg) plus the Speed Rating: An alphanumeric some models to provide good per- rated cargo and luggage load.
  • Page 440 Maintenance Snow tires • When driving on roads covered Radial-ply tires with snow or ice, drive at less than If you equip your vehicle with snow Radial-ply tires provide improved 20 mph (30 km/h). tires, they should be the same size tread life, road hazard resistance and •...
  • Page 441 - If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. - To prevent damage to the tire, inspect the tire condition and pressure every 1,900 miles (3,000 km).
  • Page 442 Maintenance • It is not easy to recognize the tire damage with your own eyes. But if there is the slightest hint of tire damage, even though you cannot see the tire damage with your own eyes, have the tire checked or replaced because the tire damage may cause air leakage from the tire.

  • Page 443: Fuses

    Avoid devices and then separation (-) ter- using the system involved and imme- minal from the battery in a safe Normal diately consult an authorized Kia place. dealer. OPS073054 • Do not arbitrarily modify or add-on Three kinds of fuses are used: micro electric wiring of the vehicle.
  • Page 444 Kia dealer. function. recommend that you consult with an authorized Kia dealer. ✽ ✽ NOTICE The actual fuse/relay panel label may differ depending on equip- ment/options.
  • Page 445 Spare fuses are provided in the motor compartment fuse panel. 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer. 7 53...
  • Page 446 4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer.
  • Page 447 Multi fuse CAUTION - Fuse panel If the multi fuse is blown, consult an covers authorized Kia dealer. After checking the fuse panel in the motor compartment, secure- ly install the fuse panel cover with using cover locking sound. If not, electrical failures may occur from water contact.

  • Page 448: Fuse/Relay Panel Description

    Maintenance Fuse/relay panel description OPSE075010N Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. ✽ ✽ NOTICE OPSE074028L Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
  • Page 449 Maintenance Instrument panel (Driver’s side fuse panel) Fuse Name Fuse rating Circuit Protected POWER OUTLET 2 Front Power Outlet BCM, Mood Lamp Module, A/V & Navigation Head Unit, Smart Key Control Module, Power Outside Mirror Switch, E/R Junction Block (Power Outlet Relay) POWER OUTLET 1 Rear Power Outlet MODULE 6...
  • Page 450 Maintenance Fuse Name Fuse rating Circuit Protected MODULE 1 IBAU Integrated Brake Actuation Unit Tire Pressure Monitoring Module, Crash Pad Switch, Center Fascia Switch, Electronic Parking Brake MODULE 2 Module, Stop Lamp Switch, Rear Parking Assist Sensor RH/LH (IN/OUT), Front Parking Assit Sensor LH/RH (OUT/IN) MODULE 3 ATM Lever Indicator, Multipurpose Check Connector, PCB Block (IG3 #4 Relay)
  • Page 451 Maintenance Motor compartment fuse panel OPSE074012 OPSE074027L 7 59...
  • Page 452 Maintenance Fuse Name Fuse rating Circuit Protected MDPS MDPS Unit 150A Alternator Smart Junction Block (Fuse - (S/HEATER FRT, TAIL GATE OPEN, DR LOCK, P/WINDOW LH, P/WINDOW RH, MODULE 7)) Smart Junction Block (Fuse - (STOP LAMP) Arisu-LT2) Smart Junction Block (Fuse - (PDM 1, PDM 2, BRAKE SWITCH, Leak Current Autocut Device) IPS1, Arisu-LT1) PCB Block (Button Start (IG2) Relay) POWER OUTLET...
  • Page 453 Maintenance Fuse Name Fuse rating Circuit Protected Button Start (ACC) Relay, Button Start (IG1) Relay BLOWER Blower Relay IG3 1 IG3 #1/#2/#3/#4/#5 Relay EPB 1 Electronic Parking Brake Module EPB 2 Electronic Parking Brake Module Blower Relay, A/C Control Module, A/C Compressor, E/R Junction Block (Cooling Fan 1/2 Relay), Heater IG3 2 Assembly (PTC Heater) CHARGER 1...
  • Page 454 Maintenance Motor compartment fuse panel (Battery terminal cover) OPSE074014 ✽ ✽ NOTICE The actual fuse/relay panel label may differ depending on equip- ment/options. OPSE074015L...

  • Page 455: Light Bulbs

    - Light WARNING Lights the correct bulbs and the expertise, replacement consult an authorized Kia dealer. In Prior to working on the light, many cases, it is difficult to replace Be sure to replace the burned- firmly apply the parking brake,...

  • Page 456: Front Light Replacement

    Maintenance Front light replacement If the headlight aiming adjustment is necessary after headlight assembly is reinstalled, consult an authorized Kia dealer. OHD076046 OPS073020 WARNING - Halogen (1) Headlight (High) bulbs (2) Headlight (Low) Handle halogen bulbs with care. (3) Front position light/ •...
  • Page 457 Maintenance • Always handle them carefully, and 1. Turn off the vehicle and open the avoid scratches and abrasions. If hood. the bulbs are lit, avoid contact with 2. Disconnect the power connector liquids. Never touch the glass with from the back of the headlight bare hands.
  • Page 458 Maintenance Headlight bulb (High, Low) 5. Pull out the end of the front 11. Install a new headlight bulb and bumper. snap the headlight bulb retaining wire into position by aligning the If you can reach the bulb without wire with the groove on the bulb. removing the headlight assembly, you do not need to do step 4,5 and 6.
  • Page 459 If the light bulb is not operating, have assembly by turning the socket the vehicle checked by an authorized counterclockwise until the tabs on Kia dealer. the socket align with the slots on the assembly. 8.Pull the bulb out of the socket.

  • Page 460: Side Repeater Light Bulb Replacement

    Side marker light (LED) cover. Kia dealer. (2) Tail and side marker light(LED) (3) Rear turn signal light ✽ ✽ NOTICE (4) Back-up light If the headlight aiming adjustment is necessary after the headlight assembly is reinstalled, consult an authorized Kia dealer.
  • Page 461 Maintenance Turn signal light 6. Insert a new bulb by inserting it into the socket and rotating it until it locks into place. 7. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly and turning the socket clockwise.
  • Page 462 Tail,stop light and side marker light (LED type) If the light does not operate, have the system be checked by an authorized Kia dealer. Back-up OPS073036 OPS073045 Follow the steps 1 to 3 from the pre- vious page.

  • Page 463: License Plate Light Bulb Replacement

    Maintenance LED type License plate light bulb replacement OPS073053 OPS073050 4.Pull out the module from the high 1. Remove the lens by pressing the mounted stop light assembly by tabs. pulling both clips. 2. Remove the socket from the lens. 5.Replace the LED with new one.

  • Page 464: Interior Light Bulb Replacement

    Maintenance Interior light bulb replacement Map lamp Luggage lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interi- or light housing. 2. Remove the bulb by pulling it straight out. WARNING - Interior lights Room lamp Prior to working on the Interior Lights, ensure that the “OFF”...

  • Page 465: Appearance Care

    Maintenance APPEARANCE CARE Exterior care Even prompt washing with plain CAUTION water may not completely remove all Exterior general caution these deposits. A mild soap, safe for • Do not use strong soap, chem- It is very important to follow the label use on painted surfaces, may be ical detergents or hot water, directions when using any chemical...
  • Page 466 Maintenance High-pressure washing Waxing • When using high-pressure wash- Wax the vehicle when water will no ers, make sure to maintain suffi- longer bead on the paint. cient distance from the vehicle. Always wash and dry the vehicle Insufficient clearance or excessive before waxing.
  • Page 467 Maintenance ✽ ✽ NOTICE Underbody maintenance CAUTION - Drying vehicle Corrosive materials used for ice and If your vehicle is damaged and • Wiping dust or dirt off the snow removal and dust control may requires any metal repair or body with a dry cloth will collect on the underbody.
  • Page 468 Maintenance Aluminum wheel maintenance Corrosion protection High-corrosion areas The aluminum wheels are coated If you live in an area where your vehi- Protecting your vehicle from corro- with a clear protective finish. cle is regularly exposed to corrosive sion materials, corrosion protection is •...
  • Page 469 Maintenance High temperatures can also acceler- Keep your vehicle clean • When cleaning lower door panels, ate corrosion of parts that are not rocker panels and frame members, The best way to prevent corrosion is properly ventilated so the moisture be sure that drain holes are kept to keep your vehicle clean and free can be dispersed.

  • Page 470: Interior Care

    Maintenance Keep paint and trim in good con- Don't neglect the interior Interior care dition Moisture can collect under the floor Interior general precautions Scratches or chips in the finish mats and carpeting and cause corro- Prevent chemicals such as perfume, should be covered with "touch-up"...
  • Page 471 Maintenance Cleaning the upholstery and inte- Cleaning the lap/shoulder belt CAUTION - Leather rior trim webbing When cleaning leather products Clean the belt webbing with any mild Vinyl (steering wheel, seats etc.), use soap solution recommended for Remove dust and loose dirt from neutral detergents or low alco- cleaning upholstery or carpet.

  • Page 472: California Perchlorate Notice

    Maintenance CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special handling may apply, See www.dtsc.ca.gov/haz- ardouswaste/ perchlorate. Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a).

  • Page 473: Specifications, Consumer Information And Reporting Safety Defects

    Specifications, Consumer information and Reporting safety defects Dimensions ....... . 8-2 Power electric specifications .
  • Page 474 Specifications, Consumer information and Reporting safety defects DIMENSIONS Item in (mm) Overall length 162.9 (4,140) Overall width 70.9 (1,800) Overall height 62.9 (1,600) Front tread 205/60R16 62.1 ( 1,576) Rear tread 205/60R16 62.4 ( 1,585) Wheelbase 101.2 ( 2,570) POWER ELECTRIC SPECIFICATIONS Max.

  • Page 475: Gross Vehicle Weight

    Back seat folded with luggage under tray AIR CONDITIONING SYSTEM Weight of volume Item Classification A/CON (STD) HEATPUMP (OPT) Refrigerant 550±25g 900±25g R-134a Compressor lubricant 180±10g POE (RB100EV) We recommend that you contact an authorized Kia dealer for more details.

  • Page 476: Bulb Wattage

    Specifications, Consumer information and Reporting safety defects BULB WATTAGE Light Bulb Wattage Bulb type Headlamps (High) H7LL Headlamps (Low) H7LL Front turn signal lamps Front position lamps Front Front fog lamps* 9006 Front day time running lamps* Front side marker Side Repeater lamps (Outside Mirror)* Rear tail,stop lamps and side marker Rear tail lamps and side marker...

  • Page 477: Tires And Wheels

    Specifications, Consumer information and Reporting safety defects TIRES AND WHEELS Inflation pressure psi (kPa) Wheel lug nut Load Capacity Speed capacity Wheel Item Tire size Normal load Maximum load torque size lb•ft, N•m (kg•m) LI * SS * Km/h Front Rear Front Rear...

  • Page 478: Recommended Lubricants And Capacities

    Volume Classification 1.4±0.1 US qt. “75W/85,GL-4 or other brands meeting the GL-4 Reduction gear oil (1.3±0.1l) specification approved by Kia Motors Corp.” 5.39 US qt. Mixture of antifreeze and water Coolant (5.1l) (Ethylene glycol base coolant for aluminum radiator) Brake fluid...

  • Page 479: Vehicle Identification Number (Vin)

    Specifications, Consumer information and Reporting safety defects VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Frame number ■ VIN label (if equipped) OUN088001 ORP082002 The vehicle identification number The VIN is also on a plate attached ORP082004 (VIN) is the number used in register- to the top of the dashboard.

  • Page 480: Motor Number

    Specifications, Consumer information and Reporting safety defects TIRE SPECIFICATION AND MOTOR NUMBER AIR CONDITIONER PRESSURE LABEL COMPRESSOR LABEL ■ Type A OPSE084004N OPSE084001 ■ Type B The motor number is stamped on the ORP082003 motor compartment as shown in the The tires supplied on your new vehi- drawing.

  • Page 481: Refrigerant Label

    Specifications, Consumer information and Reporting safety defects REFRIGERANT LABEL OPSE084002L The refrigerant label is located on the underside of the hood.
  • Page 482 Roadside Assistance is provided on all new current Emergency roadside assistance model year Kia Vehicles from the date the vehicle is deliv- Kia's toll free Roadside Assistance hot line is staffed 24 ered to the first retail buyer or otherwise put into use (in-...
  • Page 483 Roadside Assistance benefits are not available for any ment is included for meals, lodging, or rental vehicle Kia vehicle that has ever been or should be issued a “sal- expenses. Trip interruption coverage is limited to $100 vage” title or similar “branded” title under any state’s per day subject to a three day maximum limit per incident.
  • Page 484 Specifications, Consumer information and Reporting safety defects Registering your vehicle in a foreign country 3. There may not be an Authorized Kia Dealer in the area in which you plan to register your vehicle. You may If you plan to register your vehicle in a foreign country,...
  • Page 485 Authorized Kia electronic systems may be adversely affected. To avoid Dealer, in order to ensure that you do not void your war- damage to your vehicle, consult an Authorized Kia Dealer ranty. concerning the proper equipment and installation.
  • Page 486 However, NHTSA cannot become involved in indi- vidual problems between you, your dealer, or Kia Motors America, Inc. Electrical troubleshooting manual: This manual complements the Service Manual by provid-...

  • Page 487: Index

    Index...
  • Page 488 Index Audio ........4-141 Audio remote control ..... . 4-128 Aux, USB and iPod ®...
  • Page 489 Index Bonnet see the hood ......4-22 Lower anchor system ......3-32 Brake system.
  • Page 490 Index Dimensions ........8-2 Energy consumption ......4-61 Display illumination, see instrument panel illumination.
  • Page 491 Index Glove box lamp....... 4-92 A/V Mode....... . . 4-48 Gross vehicle weight.
  • Page 492 Index Rear seat warmer ......4-121 LCD Modes ....... . . 4-46 Seat air ventilation .
  • Page 493 Index Maintenance services ......7-3 Outside rearview mirror folding ....4-38 Owner maintenance .
  • Page 494 Index Hight adjustment ......3-16 Lap/shoulder belt ......3-15 Precautions .
  • Page 495 Index Special driving conditions ..... . 5-39 Driving at night ......5-41 Driving in flooded areas.
  • Page 496 Index Removable towing hook..... . 6-21 Windows ........4-17 Trailer Towing .

Table of Contents

Save PDF
