- Page 1 18 kilograms group 0 + I IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT. Illustrations and designs may vary. follow us on the only choice motherschoice.com.au...
- Page 2 Safety Please read this user guide carefully before install the child seat and for future reference. This child seat suitable children from new-born to 13 kg (Group 0+) and from 9kg to 18kg (Group 1). Please read this instruction carefully otherwise incorrect installation may cause serious injury.
- Page 3 Features Warning label Backrest Shoulder strap slots Shoulder pad Harness Buckle Buckle release button Recline position label Adjuster Seat base Lap belt routing slot Adjuster strap Red handle Shoulder belt routing slot t of Shoulder belt routing slot Lap belt routing slot Hook Recline position...
- Page 4 Suitability The Ebony car seat is certified to ECE R44/04 as a child safety seat for age groups 0+ and I. To make sure your child has optimum protection at any age, the Ebony car seat has two different installation options:...
- Page 5 For Group I IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE CHILD'S WEIGHT EXCEEDS 9 KG. Only suitable if the approved vehicles are fitted with 3 point safety-belts, approved to UN/ECE Regulation No. 16 or other equivalent standards. If there is a front airbag: slide passenger seat back all the way or nearly so, observe any instructions in vehicle owner's manual.
- Page 6 Installing your child into the child seat Check the height of the shoulder strap. If it is unsuitable, you should adjust the strap’s height. Press the adjuster and at the same time pull out the harness, Release the buckle by sliding the red button downwards.
- Page 7 Installing your child seat - Rearward Facing For use with Group 0+ - From birth to approx. 18 months (13kg). WARNING! DO NOT place rear-facing child seat on front seat with airbag, DEATH OR SERIOUS INJURY can occur The seat must be fully reclined when rearward facing.
- Page 8 Installing your child seat - Forward Facing For use with Group I - from approx. 9 months to 4 years (9-18kg). IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE CHILD'S WEIGHT EXCEEDS 9 KG To secure your child seat by default forward facing using the 3- point belt of your vehicle proceed as follows:...
-
Page 9: Cleaning And Maintenance
Cleaning & Maintenance To remove the cover for cleaning, you should loosen the harness straps as far as possible, release the harness buckle, and take out the harness straps from the hook. Put the straps through to the front of the seat. Carefully pull up the cover from the backrest. IMPORTANT - The cover is a safety feature. - Page 10 notes:...
- Page 11 notes:...
- Page 12 motherschoice.com.au IGC DOREL NEW ZEALAND LTD 14 Sir William Avenue East Tamaki Auckland 2013 Email: customerservice@igc.co.nz Phone: 0800 628 000 (toll free) Hours: 8:00 am - 5:00 pm Monday to Friday Specifications are subject to change without notice. Copy or reproduction without permission is prohibited. ©...
