Radio Frequency Range digi-MOD RL-DM8000 www.resi-linx.com RL-DM8000 8 Input DVB-T Encoder / Modulator User Guide and Install Manual Table of Contents Safety Precautions Package Contents Product Description Specification Installation Hardware Installations and Connections Device Programming and Setup Connecting to the GUI Interface... -
Page 2: Safety Precautions
Product Description resi-linx digi-MOD Series Encoder/ Modulators provides a DVB-T output stream - making it ideal for any Commercial RF Network. The high quality design allows for watching action packed movies and sports channels on any HDTV. The space saving design delivers up to 8 High Quality DVB-T channels in a single 1RU space. -
Page 3: Specification
Specification VIDEO INPUTS (VIDEO BY PRIORITY) Composite CVBS (RCA) AUDIO INPUTS Audio Inputs L/R (RCA) VIDEO ENCODER Mode MPEG-2 Video Resolutions 576p, 576i, 480p, 480i AUDIO ENCODER Audio Compression MPEG-1 Layer II RF DVB-T SUPPORT Frequency Channel Plan - Varies by Country RF Channel Output 8 multiplexed on to 2 x RF Output Channels Constellation... -
Page 4: Installation
Installation System Installer must adhere to Article 820-40 of the NEC that provides guidelines for proper grounding and specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible. -
Page 5: Encoder Programming And Setup Via Gui Interface
Encoder Programming and Setup via GUI Interface After connecting the device to the “Web Management” port located on the rear of the device and locating the device via the ‘Network’ tool in ‘My Computer’ STEP 1: Right Click and Select “View device Webpage”. Overview Page Welcome page showing overview status of the Encoder when fully functioning. -
Page 6: Rf Setup
STEP 3: Common Setup Tab Common Setup: Use the Common Setup Page to set the Output channel, Attenuation, LCN Mode, and Device Address. STEP 4: RF Setup Use the RF Setup Page to setup each RF Output. Select RF Output 1 or RF Output 2. Select and set the required parameters you require for your installation. - Page 7 STEP 5: Local Save Once all parameters are set you are required to do a Local Save. STEP 6: Encoder Setup NOTE: There is an Encoder tab present for each input on the device. Select the Encoder 1, 2, 3, 4 tab to program an individual encoder. Select and change all desired parameters. STEP 7: Local Save for each Encoder tab Once all parameters are set you are required to do a Local Save on EACH Encoder Tab where changes were performed Note: Local...
- Page 8 STEP 8: Upload and Reboot Once you have set all the encoder settings and performed a Local Save for each encoder Select “Upload and Reboot” after you have saved all your Local changes on each Tab. This function will upload and save all parameters set in the Common, RF, and Encoder sections of the device.
-
Page 9: Saving Your Configuration Files
STEP 11: Administration ADMINISTRATION PAGE FUNCTIONS ACTIONS Reboot Reboot device. All unsaved settings will be lost. Reset to Default Reset all settings back to original factory settings Backup Download all settings of device Upload Upload a saved config file New Password Create and save new password for GUI STEP 13: If required, change GUI Password and Submit. -
Page 10: Front Panel Lcd Encoder Menu Map
Front Panel LCD Encoder Menu Map COMMON SETUP Output Channel Attenuation LCN Mode Device Address Default Configuration Back to Main RF SETUP Select RF Enable RF Constellation Guard Interval OFDM RF Output Cell ID TS ID Network ID Org Network ID Network Name Back to Main ENCODER SETUP... -
Page 11: Modulator Configuration Via Front Panel Lcd
Modulator Configuration via Front Panel LCD Once the encoder is powered up it will go through its initial booting process. Once the unit has completed its initial “Booting” up process the LCD will display IN-1..., Bit Rate information, Channel-1.., and other information in the LCD Display Window. When visible the unit is ready for programming or operation. -
Page 12: Encoder Setup
RF SETUP MENU • Constellation – Use the Scroll Up/Down button to select Constellation. Press the OK button to enter the Constellation menu. Select the desired Constellation / QAM setting then press the OK button to set. • FEC – Use the Scroll Up/Down button to select the FEC menu. Press the OK button to enter the FEC menu. Use the Scroll Up/ Down button to select the desired FEC setting and press the OK button to set. -
Page 13: Network Setup
• Audio Input – Use the Scroll Up/Down button to select. Press the OK button to enter the Audio Input menu. Use the Scroll Up/ Down button to select the Audio Input option: Analog. Factory Set: Analog. • Audio Output – Use the Scroll Up/Down button to select Audio Output. Press the OK button to enter the Audio Output menu. Use the Scroll Up/Down button to select the Audio Output option: MP2 (MPEG2 Layer I Audio), AAC, or AC3. - Page 14 ITEM VALUE Password Serial Number Installation Date Purchase Date Video Input 1 Video Input 2 Video Input 3 Video Input 4 Video Input 5 Video Input 6 Video Input 7 Video Input 8 RL-DM8000 User Guide and Install Manual Page 14...
- Page 15 Notes RL-DM8000 User Guide and Install Manual Page 15...
-
Page 16: Www.resi-Linx.com
WARRANTY WARRANTY Vcomm Pty Ltd states that the warrant that the customer can rely on is that Vcomm Pty Ltd states that the warrant that the customer can rely on is that provided WARRANTY provided by the manufacturer. In the event of any warranty claim please by the manufacturer.
