4.0 THE MOTION DETECTOR

4.1 Product overview

Item
1
1
2
2
3
3
Motion Detector – front side of housing
14
Part Explanation
LED indicator Status/fault
Red Fault, functional test
Orange Configuration process, update
Green Configuration successful
Sensor area With lens
Sneak-by guard Increased security
Item
1
2
1
2
3
3
Motion Detector – rear side of housing
Part Explanation
For setting pet
Green rotary switch immunity/sneak-by
guard
Scan for device
QR code
identification
For device resetting
Contact switch
and theft protection
