USER MANUAL
®
Mobeye
CM2410
GSM fire alarm communicator
Accessory for Ei Electronics fire detector
SW version 4.n
Incl. CM2400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM2410 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mobeye CM2410

  • Page 1 USER MANUAL ® Mobeye CM2410 GSM fire alarm communicator Accessory for Ei Electronics fire detector SW version 4.n Incl. CM2400...
  • Page 2 • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. ® • Repair of the device may only be carried out by people, trained for Mobeye repair. • If the device must be repaired, only original replacement components may be used.
  • Page 3: Table Of Contents

    List of SMS commands for configuration Possible settings Phone numbers Identification text Alarm texts SMS on/off Call on/off Set time and date Test message System reset Request list of the settings, status and signal strength Mobeye Internet Portal Technical messages and status feedback...
  • Page 5: General Description

    Mobeye GSM communicator sends an alarm SMS text message and calls the phone numbers as programmed by the user. - In case the batteries need to be replaced, the Mobeye GSM communicator sends a ‘battery low’ SMS text message to the administrator (first telephone number).
  • Page 6: Getting Started

    2. GETTING STARTED To get started with the Mobeye CM2410 at least the following steps need to be taken in following order: 1. Place a SIM card (with PIN code 0000 or without PIN code) 2. Place the batteries 3. Enter the program mode 4.
  • Page 7: Enter The Program Mode

    Without this number, the Mobeye CM2410 cannot function. When the CM2410 is in initial (factory) status and in program mode, the first number is programmed by calling the telephone number of the Mobeye CM2410 using the administrators’...
  • Page 8: Mount The Gsm Module Housing To The Ceiling

    2.5 MOUNT THE GSM MODULE HOUSING TO THE CEILING Mount the housing in which the module is fixed to the desired place to the ceiling, using the plugs and screws which can be found inside the Ei Electronics box. Please refer to the manual of the Ei Electronics detector for the ideal location and installation method.
  • Page 9: Perform A Test

    2.7 PERFORM A TEST After the previous steps, the GSM fire detector is operational. In order to execute a test, press the TEST & HUSH (or TEST & STUMM) button of the EI detector during a few seconds (this can take up to 5 seconds). The siren will sound and the GSM module will establish network connection in order to send the SMS messages and call the contact persons.
  • Page 10: Combine Other Ei Detectors And A Wireless Network

    3.1 COMBINATIONS OF EI ELECTRONICS DETECTORS The CM2410 can be applied in various combinations: - A stand-alone GSM smoke or heat detector can be the combination of the Mobeye CM2410 and the Ei605C, Ei605TYC, Ei603C or Ei603TYC (smoke or hear) detector, or any other detector in the Ei600 and Ei650-series.
  • Page 11: Use Of External Power Supply

    4. USE OF EXTERNAL POWER SUPPLY Although the Mobeye CM2410 is designed to run on batteries, it is possible to use an external power supply. In this mode the module is always in connection with the GSM network and therefore always in program mode. In case the power fails, the batteries take over the functioning and the first telephone number (TEL1) is informed by an SMS text message.
  • Page 12: Configuration

    5. CONFIGURATION To program the Mobeye CM2410, the GSM module must have network connection. In case only batteries are used, first switch the unit to the program mode. Next send SMS commands for the configuration. All settings are stored and will be kept in the unit, even in case the power supplies are removed.
  • Page 13: Programming The Settings By Sms

    5.3 PROGRAMMING THE SETTINGS BY SMS To program the settings by SMS text message: 1. Be sure the CM2410 is in program mode (please refer to 5.1). 2. Send an SMS text message with the (security) code and the command.
  • Page 14: List Of Sms Commands For Configuration

    INSTCODE: 0000···9999 1111 Telephone number for TEL1: Empty …. alarm messages TEL5: Delete telephone number DEL1 …. DEL5 Mobeye Identification text NAME: 20 characters Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Alarm text input 1 TEXT1: 20 characters...
  • Page 15: Possible Settings

    6. POSSIBLE SETTINGS 6.1 PHONE NUMBERS The Mobeye CM2410 is able to send alarm messages to up to 5 phone numbers. The first telephone number (TEL1) belongs to the administrator. Only this number receives all system messages. The other phone numbers (including the administrator) only get the alarm messages.
  • Page 16: Alarm Texts

    6.3 ALARM TEXTS A unique alarm text can be programmed into the Mobeye CM2410. The user defined text has a maximum length of 20 characters. The default alarm text is Fire alarm! SMS command to change the text: TEXT1: example: 1111 TEXT2:Fire alarm, get help 6.4 SMS ON/OFF...
  • Page 17: Test Message

    6.7 TEST MESSAGE The Mobeye CM2410 can send regular test SMS messages (keep alive) to the administrator (first phone number), to ensure the proper functioning of the unit. The timing of the test message is determined by the time of programming. The test time can also be programmed.
  • Page 18: Request List Of The Settings, Status And Signal Strength

    Before sending the request, make sure the unit is in the program mode (please refer to 5.1). Upon sending the command, the Mobeye CM2410 returns an SMS text message to the originator of the request. The commands are case insensitive.
  • Page 19: Mobeye Internet Portal

    8. MOBEYE INTERNET PORTAL The Mobeye CM2410 sends GSM messages to the preset contact persons. It is also possible to connect the system to the Mobeye Internet Portal. In this secured internet environment the Mobeye CM2410 system(s) can be administered.
  • Page 20: Technical Messages And Status Feedback

    9. TECHNICAL MESSAGES AND STATUS FEEDBACK Technical messages In the event of technical issues the administrator (TEL1) receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be replaced. supply OK No external power supply, No external power supply, batteries take care of batteries OK...
  • Page 21 Status feedback LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is in program No action required.
  • Page 22 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2017 by Mobeye, version CM2410EN170209...
