Summary of Contents for Master Lock 2953AT
- Page 1 2953AT Winch 12 Volt ElEctric Winch oWnEr’s Manual...
-
Page 2: Table Of Contents
GENERAL SAFETY INFORMATION ......3 Introduction Thank you for purchasing a Master Lock electric winch. We hope you of your winch, it is extremely important that you read and understand ®... -
Page 3: Included Accessories
Included Accessories 1. Power cord, fitted with water sealed plug for safe operation. 4. Mounting plate for trailer hitch. 2. Remote control with water sealed plug, for safe operation. 5. Hand crank and adjustable clutch. 3. 30’ steel cable with attached hook. 30’... -
Page 4: General Safety Information
General Safety Information WARNING: FAILURE TO READ AND FOLLOW THE SAFETY INSTRUCTIONS IN THIS OWNER’S MANUAL BEFORE INSTALLING OR USING YOUR ELECTRIC WINCH COULD RESULT IN DAMAGE TO YOUR WINCH AND SERIOUS OR FATAL INJURY!! WARNING: Never operate your winch when under the influence of WARNING: Never apply a load to your winch with the cable fully drugs, alcohol or medication. -
Page 5: Mounting Instructions
Mounting Instructions Your winch is designed to be mounted permanently or temporarily. No Hardware Included. Permanent Mounting 3. Attach the winch to the desired location using four bolts, nuts, washers, and lock washers. Be sure that the winch is positioned 1. -
Page 6: Operating Instructions
Operating Instructions The following operating instructions are intended to provide you with a basic understanding of your electric winch and to teach you the basics of proper winching techniques. Users must understand that every winching situation has the potential for personal injury. In order to minimize the risk to you and others in the area, it is important for you to read and understand this Owner’s Manual, familiarize yourself with the operation of your winch prior to having to use it, carefully analyze each particular situation you are putting the winch to use, and constantly be aware of the importance of safety. - Page 7 Using Your Winch 1. Put on heavy gloves and safety glasses. Take your time, analyze 5. Pull the winch cable to the object to be pulled or moved. Be sure to your situation, and plan your pull carefully. keep tension on the winch cable to prevent it from becoming twisted or over-wrapped when slackened and potentially damaged.
- Page 8 Using Your Winch (continued) 8. Re-tighten the clutch knob by rotating it clockwise when winch is WARNING: Avoid shock loading the winch cable by using the not operating. This will engage the winch and lock the winch drum. remote control switch intermittently to take up cable slack. Shock loads can momentarily far exceed the winch and winch cable load WARNING: Always make sure clutch is fully engaged.
-
Page 9: Using The Hand Crank
the Hand Crank Using 1. The hand crank provided with your winch is for emergency use only 4. Rotate the handle in a clockwise direction to retract the winch cable. (i.e., in the event of a power failure). Always, remove the electrical Continue to turn until the cable has been completely retracted. -
Page 10: Warranty
1 Year Limited Warranty Master Lock Company warrants to the original buyer (“you” or “your”) all component parts of your winch except the winch cable for a period of one (1) year from the provable date of purchase. If your winch fails due to a defect in materials or workmanship during the 1 year warranty, Master Lock Company will replace it free of charge.
