Master Lock 2955AT Owner's Manual

12-volt dc utility and atv winch
Hide thumbs
Table of Contents

Advertisement

Quick Links

2955AT
12 VOLT dc 1500Lb ELEcTRIc UTILITY
ANd ATV SPORT WINcH OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Master Lock 2955AT

Summary of Contents for Master Lock 2955AT

  • Page 1 2955AT 12 VOLT dc 1500Lb ELEcTRIc UTILITY ANd ATV SPORT WINcH OWNER'S MANUAL...

  • Page 2: Table Of Contents

    MOUNTING INSTRUCTIONS ......4 Introduction Thank you for purchasing the Master Lock electric utility and ATV of your winch, it is extremely important that you read and understand ®...

  • Page 3: Included Accessories

    Included Accessories 1. Power cord fitted with water sealed plug for safe operation 2. Remote control with water Power Cord 64" sealed plug for safe operation Remote Control 3. 35' (34' working length) galvanized steel Cable 42" cable with attached winch hook and Handsaver strap 35' Galvanized Steel Cable 4.

  • Page 4: General Safety Information

    General Safety Information WARNING: FAILURE TO READ AND FOLLOW THE SAFETY INSTRUCTIONS IN THIS OWNER’S MANUAL BEFORE INSTALLING OR USING YOUR ELECTRIC WINCH COULD RESULT IN DAMAGE TO YOUR WINCH AND SERIOUS OR FATAL INJURY!! WARNING: Never operate your winch when under the influence of WARNING: Never apply a load to your winch with the cable fully drugs, alcohol or medication.

  • Page 5: Mounting Instructions

    Mounting Instructions Your winch is designed to be mounted permanently. No Hardware Included. Permanent 3. Attach the winch to the Mounting desired location using bolts, nuts, washers, 1. Select a mounting and lock washers. site on the front or Do not use any bolts rear of your ATV weaker than ISO grade 5.

  • Page 6: Operating Instructions

    Operating Instructions The following operating instructions are intended to provide you with a basic understanding of your electric winch and to teach you the basics of proper winching techniques. Users must understand that every winching situation has the potential for personal injury. In order to minimize the risk to you and others in the area, it is important for you to read and understand this Owner’s Manual, familiarize yourself with the operation of your winch prior to having to use it, carefully analyze each particular situation you are putting the winch to use, and constantly be aware of the importance of safety.

  • Page 7: Using Your Winch

    Using Your Winch 1. Put on heavy gloves and safety glasses. Take your time, analyze WARNING: Never attach cable, rope, chains or other objects to your situation, and plan your pull carefully. the winch hook to increase the length of a pull. WARNING: Never operate or install a winch without reading and 6.
  • Page 8 Using Your Winch (continued) WARNING: Avoid shock loading the winch cable by using the 8. Re-engage the clutch knob by rotating it 90˚ so the pin snaps back into slot when winch is not operating. This will engage the remote control switch intermittently to take up cable slack. Shock winch and lock the winch drum.

  • Page 9: Troubleshooting

    Troubleshooting Symptoms Possible Cause(s) Corrective Action Motor will not operate or only in one direction 1. Switch inoperative 1. Replace switch 2. broken wires or bad connection 2. Check for poor connections 3. Damaged motor 3. Replace or repair motor Motor runs extremely hot 1.

  • Page 10: Warranty

    1 Year Limited Warranty Master Lock Company warrants to the original buyer (“you” or “your”) all component parts of your winch except the winch cable for a period of one (1) year from the provable date of purchase. If your winch fails due to a defect in materials or workmanship during the 1 year warranty, Master Lock Company will replace it free of charge.
