OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
DRYWALL/DECK SCREWDRIVER
VISSEUSE POUR CLOISONS SÈChES
PLACOPLâTRE
DOUBLE ISOLATION
DESTORNILLADOR PARA PANELES O
ENTABLONADOS
AISLAMIENTO DOBLE
DG100
Your screwdriver has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE ThIS MANUAL FOR FUTURE REFERENCE
Cette visseuse pour placoplâtre été conçu et fabriqué conformément
à nos strictes normes de fiabilité, simplicité d'emploi et sécurité
d'utilisation. Correctement entretenu, cet outil vous donnera des
années de fonctionnement robuste et sans problème.
AVERTISSEMENT :
blessures, l'utilisateur doit lire et veiller à bien comprendre le
manuel d'utilisation avant d'employer ce produit.
Merci de votre achat.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Pour réduire les risques de
Su destornillador ha sido diseñado y fabricado de conformidad
con nuestras estrictas normas para brindar fiabilidad, facilidad
de uso y seguridad para el operador. Con el debido cuidado, le
brindará muchos años de sólido funcionamiento y sin problemas.
ADVERTENCIA:
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
Para reducir el riesgo de lesiones,
