Summary of Contents for Nvidia Inno3D
-
Page 2: Table Of Contents
Hardware installation iii. Connect external power supply to graphics card 5. Assemble your Inno3D SLI PC 5. Assemble your Inno3D SLI PC (CONT.) 6. Upgrading Your DirectX 7. Inno3D Geforce Graphics Card Driver Installation 8. Using TV Out, nView Multi-Display and HDTV Out A. -
Page 3: Welcome
Minimum of 400-450W Power Supply with a minimum of +12V @ 22A for all PC components. * Note: The NVIDIA SLI connector is not used with some mainstream graphics card models such as the GeForce 6600 and GeForce 7300 series. Page 1 of 16... -
Page 4: Inno3D Geforce Graphics Card Installation
8. Connect the monitor cable to the card and switch on the computer and monitor. iii. Connect external power supply to graphics card For Inno3D GeForce AGP graphics card, connect 4-pin hard disk drive power connector when applicable. For GeForce PCI-Express graphics card, connect PCI-Express power connector when applicable. -
Page 5: Assemble Your Inno3D Sli Pc
5. Assemble your Inno3D SLI PC Building your SLI system 1. Install the NVIDIA SLI-Ready Motherboard (per instructions in the accompanying manual) 2. Install both of the NVIDIA SLI-Ready graphics cards 3. Connect the PCI Express supplementary power connectors to each of the graphic... -
Page 6: Assemble Your Inno3D Sli Pc (Cont.)
Inno3D GeForce Graphics Card User Manual 5. Assemble your Inno3D SLI PC (CONT.) 4. Install the NVIDIA SLI connector to connect the two graphics cards (The NVIDIA SLI connector is not used with some mainstream graphics card models such as the GeForce 6600 and Geforce 7300 series.) -
Page 7: Upgrading Your Directx
New Hardware screen is displayed. Click Cancel to exit so that you can install the graphics card from Setup CD in next step. 3. Insert the Inno3D Universal Drivers CD to CD-Rom Drive, autorun window show up automatically. [Note: If the program does not start, open “CDRomDrive:\Setup.exe” to start it manually.]... - Page 8 Inno3D GeForce Graphics Card User Manual 5. Installation of graphics card driver is started, click Next to continue. 6. The graphics card will be detected. If Windows warns you that the driver has not passed Windows Logo testing, ignore the warning and click Continue Anyway to continue the installation.
- Page 9 Inno3D GeForce Graphics Card User Manual 8. As part of the NVIDIA Unified Driver Architecture, NVIDIA drivers include a full set of controls for SLI systems. Once you have installed the NVIDIA SLI components and booted up your system, you will see an SLI Capable System message.
-
Page 10: Using Tv Out, Nview Multi-Display And Hdtv Out
Inno3D GeForce Graphics Card User Manual 8. Using TV Out, nView Multi-Display and HDTV Out A. Using TV Out 1. Right click on desktop and open NVIDIA Control Panel 2. Enter Display category 3. Select Change Display Configuration option [Note: The option of nView Display Mode is only available when TV or second monitor has been connected to graphics card.]... -
Page 11: Advanced Setting For Tv Out
B. Advanced Setting for TV out ! Adjust the size and position of the screen on TV 1. Right click on desktop and open NVIDIA Control Panel 2. Enter Video & Television category 3. select Adjust Screen Size and Position option... -
Page 12: Set Video Format
When your TV is connected to computer, but it remains undetected. You can try the following. 1. Right click on desktop and open NVIDIA Control Panel 2. Enter DISPLAY category and select Change Display Configuration and choose “My display is not shown in the list”. -
Page 13: Nview Multi-Display
Inno3D GeForce Graphics Card User Manual C. nView Multi-Display With NVIDIA nView Technology, you can display computer screen over two displays at the same time and control the desktop displays across two output devices. And there are different modes available. [Note: Depending on the type of your display device, the options... -
Page 14: Hdtv Mode
But as the mouse cursor gets close to these desktop elements, the NVIDIA driver intelligently shifts the desktop to little in order to move those elements into view. -
Page 15: Native
1. From the menu of installation program in Universal CD Drivers, select INSTALL DRIVERS → → → → Video In Drivers. 2. The installation of Nvidia WDM Capture Drivers is started, click Next to continue. If Windows warns that driver has not passed Windows Logo testing, click Continue Anyway to continue the installation. - Page 16 Inno3D GeForce Graphics Card User Manual 4. After restarting your system, Windows detects new devices and displays the “Found New Hardware” Wizard. You are going to go through 4 Found New Hardware screen for 4 WDM drivers that include WDM Video Capture, WDM TVTuner, WDM TVAudio Crossbar and WDM A/V Crossbar.
-
Page 17: Customer Service And Support
13. Software License Agreement This Inno3D software, and the bundled software (the “Software”) is copyrighted by InnoVISION Multimedia Limited and or third parties companies. All rights are reserved. -
Page 18: Fcc Statement
15. Copyright Notice Copyright © 1999-2005, InnoVISION Multimedia Limited. All rights reserved. The Inno3D, Inno3D logo are the registered trademarks of InnoVISION Multimedia Ltd. in Asia, Europe and/or other countries. NVIDIA, the nVidia logo, GeForce are trademarks and/or registered trademarks of NVIDIA Corporation. IBM is a registered trademark of International Business Machines, Inc.
