Advantages & Features
1. Fashion hand free design, large keyboard;
2. Large LCD display current time, temperature, and alarm info;
3. GSM/SMS/GPRS/3G Transmission, no distance limitation;
4. Bedtime monitoring, if not get up in time can generate alarm;
5. Away/back home time monitoring;
6. Daily action monitoring;
7. 32 wireless zones support variety wireless detectors: fall detector, CO, smoke, water
and Gas detectors, etc;
8. Equips 4 quick dial numbers;
9. Alarm clocks for reminding elderly to take medicine or other activities.
10. Backup rechargeable battery.
11. Wireless transmit the Blood Pressure Meter out to server or apps.
12. Setting by Android APP (Search Senior Helper T4 on Google Play store)or SMS
commands remotely.
13. Ademco Contact ID protocol over GPRS data supported.
Specifications
Quad-band 850/900/1800/1900 MHz
GSM Frequency
32
Wireless Zones
433.92MHz for sensors
Radio Frequency
9~24V DC/1A
Rated Power Supply
12V input Max. 270mA, Standby 30mA
Power Consumption
Support 3V SIM Card
SIM Card
50 Ω SMA Antenna interface
Antenna
-20~+60 °C
Temperature Range
Relative humidity 90% (condensing free)
Humidity Range
3.7V/900mAH Li-ion rechargeable
Backup Battery
GSM/3G Elderly Health Care
Alarm System
T4
All rights reserved. www.GsmAlarmSystem.com
Advertisement
Table of Contents
Related Manuals for King Pigeon T4
Summary of Contents for King Pigeon T4
- Page 1 10. Backup rechargeable battery. 11. Wireless transmit the Blood Pressure Meter out to server or apps. 12. Setting by Android APP (Search Senior Helper T4 on Google Play store)or SMS commands remotely. 13. Ademco Contact ID protocol over GPRS data supported.
- Page 2 Bottom View 7x24 house safety guard When smoke, gas, CO or water flood detected,T4 will make audible alarm, send alert SMS text and call to the alarm receivers/CMS. Audio volume can be adjust by Volume + and –...
- Page 3 Alarm audio can be stopped by end button If the measurement error, T4 unit make two di di sound, LCD will display E1 or S1 and the LED beneath the button will keep red light, then please do it again.
- Page 4 T4 will get mobile operator's date and time according to the phone number, LCD will correct and display the real date & time after few minutes when setting done. If T4 can't get right date & time automatically, please try to remove or add the You can manage numbers of T4 on APP,...
- Page 5 … 1234B10 Default Zone alarm SMS content: 00: SOS Alarm! ---For the SOS button on T4 unit. The 1st number can receive all alarm SMS, call, and temperature, AC power lost, 01: Has not Get Up! ---For monitoring sensor. back up battery low power, wireless sensor low power alarm SMS in default.
- Page 6 1234A Delete: 1234A1 1234A2 1234A3 1234A4 Blood Pressure Name You can operate T4 by this main page. SMS Command: 1234U# female name male name Make Call: Call to the T4 for two way talk. SMS Command and detail: For example, 1234U#...
- Page 7 1234C5time detector outside of the bedroom, setting time period at 05:20~08:30am,if the PIR sensor Inquiry: not triggered during that time,T4 sends alert 1234C SMS to receivers say “Has not Get Up!”. Also you can just install one door sensor on...
- Page 8 Add Wireless Sensors Safety Directions Safe Startup Do not use the alarm system when GSM/3G equipment is prohibited or might bring disturbance or danger. Interference Key Buttons All wireless equipment might interfere network signals of the alarm system and influence its performance. Avoid Use at Gas Station “E”—n A A A A A o sensor added on this zone A “d”—t A A here have s A A A A ensor on this zone already A...
