SERVICE MANUAL

MODEL
COMMANDER DEST.
KV-EX29M61
RM-964
CHASSIS NO.
Singapore
SCC-U37B-A
DRC-MF
1
2
3
4
5
6
7
8
9
0
JUMP
SOUND
MODE
SURROUND
FAVORITE
MENU
PIC MODE
ENTER
PROGR
RESET
AG-3E
MODEL
COMMANDER DEST. CHASSIS NO.
TRINITRON
CHASSIS
COLOR TV
®

Advertisement

Table of Contents
loading

Related Manuals for Sony KV-EX29M61

Summary of Contents for Sony KV-EX29M61

  • Page 1: Service Manual

    SERVICE MANUAL AG-3E CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-EX29M61 RM-964 Singapore SCC-U37B-A DRC-MF JUMP SOUND MODE SURROUND FAVORITE MENU PIC MODE ENTER PROGR RESET TRINITRON COLOR TV ®...
  • Page 2 OR CARBON PAINTED ON THE CRT, AFTER REMOVING THE THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. ANODE. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KV-EX29M61 RM-964 TABLE OF CONTENTS Section Title Page Section Title Page SELF DIAGNOSTIC FUNCTION ......4 8. DIAGRAMS 8-1. Block Diagram ............53 1. GENERAL ..............7 8-2. Schematic Diagrams ..........60 (1) Schematic Diagrams of F1, J and VM Boards ..61 2.

  • Page 4: Self Diagnostic Function

    KV-EX29M61 RM-964 SELF DIAGNOSTIC FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automati- cally begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/ TIMER lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 5 KV-EX29M61 RM-964 2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT Diagnostic Item Flash Count* 2 times +B overcurrent 2 times +B overvoltage 3 times 3 times V deflection stop 4 times White balance failure 5 times Lamp ON 0.3 sec. Horizontal Deflection Failure 6 times Lamp OFF 3 sec.
  • Page 6 KV-EX29M61 RM-964 5. HANDLING OF SELF-DIAGNOSTIC SCREEN DISPLAY Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen during repairs. When you have completed the repairs, clear the result display to “0”. Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after completion of the repairs.
  • Page 8 L(MONO) ENTER SELECT AUTO MENU PROGR PROGR AUDIO VIDEO VIDEO IN VIDEO OUT...
  • Page 9 L(MONO) ENTER SELECT MENU AUTO PROGR PROGR 3D WOOFER...
  • Page 10 LINE OUT R-AUDIO-L VIDEO COMPONENT VIDEO OUT LINE OUT S VIDEO OUT R-AUDIO-L VIDEO...
  • Page 11 DRC-MF JUMP SOUND MODE SURROUND FAVORITE L(MONO) ENTER SELECT AUTO PIC MODE MENU MENU PROGR PROGR ENTER PROGR ENTER SELECT AUTO PROGR MENU PROGR RESET...
  • Page 12 DRC-MF JUMP SOUND MODE SURROUND FAVORITE MENU L(MONO) ENTER SELECT PIC MODE MENU AUTO PROGR PROGR ENTER ENTER SELECT AUTO MENU PROGR PROGR RESET...
  • Page 13 SOUND MODE SURROUND FAVORITE MENU PIC MODE ENTER RESET...
  • Page 14 DRC-MF DRC-MF JUMP JUMP SOUND MODE SURROUND FAVORITE SOUND MODE SURROUND FAVORITE PIC MODE MENU MENU PIC MODE ENTER ENTER RESET...
  • Page 15 SOUND SOUND MODE SURROUND FAVORITE FAVORITE MODE SURROUND PIC MODE MENU MENU PIC MODE ENTER ENTER RESET RESET L(MONO) ENTER SELECT MENU AUTO PROGR PROGR...
  • Page 16 DRC-MF JUMP SOUND SURROUND FAVORITE MODE MENU PIC MODE ENTER RESET P166 SECTEXT FR1 MAR 03:59:09 From Singapore Dep/Arr Flight Alrcraft To PARIS 220/0588 SQ28 2130/1225 PA115 2115/1330 SQ26 To OSAKA 1000/1715 0930/2015 CX522 To ROMA 2130/0745 SQ24 2300/0915 AZ487 To SYDNEY 2210/0610 SQ21A...
  • Page 18 SOUND MODE SURROUND FAVORITE P I C T URE DRC - MF : DRC 1 2 5 0 MENU PIC MODE P I C T URE MO DE : DYNAM I WI DE MODE : OF F GAME MODEN : OF F T P I C : OF F ENTER CH PRE S E T...
  • Page 19 SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 20 SOUND MODE SURROUND FAVORITE MENU PIC MODE ENTER...
  • Page 21 JUMP SOUND MODE SURROUND FAVORITE MENU PIC MODE ENTER...
  • Page 22 JUMP SOUND MODE SURROUND FAVORITE PIC MODE MENU ENTER...
  • Page 23 L(MONO) ENTER SELECT MENU AUTO PROGR PROGR...
  • Page 24 P166 SECTEXT FR1 MAR 03:59:09 Fom Singapore Dep/Arr Flight Alrcraft To PARIS 220/0588 SQ28 2130/1225 PA115 2115/1330 SQ26 To OSAKA 1000/1715 0930/2015 CX522 To ROMA 2130/0745 SQ24 2300/0915 AZ487 To SYDNEY 2210/0610 SQ21A 2100/0835 SQ21A...
  • Page 25 PIC MODE MENU ENTER RESET...
  • Page 27 DRC-MF SOUND MODE SURROUND FAVORITE L(MONO) ENTER SELECT AUTO MENU PROGR PROGR PIC MODE MENU ENTER L(MONO) ENTER SELECT AUTO MENU PROGR PROGR RESET...

  • Page 31: Service Jig

    KV-EX29M61 RM-964 SECTION 3 SERVICE JIG 3-1. JIGS REQUIRED FOR SERVICING REF NO. DESCRIPTION PART NO. REMARK TOOL (20P), SERVICE 3-702-763-01 For A to V2 board extension TOOL (40P), SERVICE 3-702-764-01 For B3 to A board extension TOOL (30P), SERVICE...

  • Page 32: Advance Operation

    KV-EX29M61 RM-964 SECTION 5 ADVANCE OPERATION 5-1. "RESET" FUNCTION 1. Purpose If a customer faces some setting problem that cannot be solved, using the "RESET" function some items will be reset to its original setting (shipping condition). 2. How to Operate There are 2 ways to access to the "RESET"...

  • Page 33: Set-Up Adjustments

    KV-EX29M61 RM-964 SECTION 6 SET-UP ADJUSTMENTS • The following adjustments should be made when a Perform the adjustments in the following order : complete realignment is required or a new picture tube is 1. Beam Landing installed. 2. Convergence •...

  • Page 34: Convergence Adjustment

    KV-EX29M61 RM-964 V. STAT 6-2. CONVERGENCE ADJUSTMENT Preparation : • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Set the PICTURE 70% and BRIGHTNESS 0%. • Cross hatch / Dot pattern. (1) Horizontal and Vertical Static Convergence H.
  • Page 35 KV-EX29M61 RM-964 (2) Dynamic Convergence Adjustment BMC (Hexapole) Magnet. Preparation: If the red, green and blue dots are not balanced or aligned, • Before starting this adjustment, adjust the horizontal static then use the BMC magnet to adjust in the manner convergence and the vertical static convergence described below.

  • Page 36: Focus Adjustment

    KV-EX29M61 RM-964 (3) Screen-corner Convergence 6-3. FOCUS ADJUSTMENT Note Focus adjustment should be completed before W/B adjustment. (1) Receive digital monoscope pattern. a-d : screen-corner (2) Set "A/V CONTROL" to "STANDARD". misconvergence (3) Adjust FOCUS VR so that the center of the screen becomes just focus.

  • Page 37: G2 (Screen) And White Balance Adjustments

    KV-EX29M61 RM-964 6-5. G2 (SCREEN) AND WHITE BALANCE ADJUSTMENTS 1. G2 (SCREEN) ADJUSTMENT 1) Set the PICTURE and BRIGHTNESS to normal. 2) Put to VIDEO input mode without signals. 3) Connect R, G and B of the C board cathode to the oscilloscope.

  • Page 38: Circuit Adjustments

    KV-EX29M61 RM-964 SECTION 7 CIRCUIT ADJUSTMENTS 7-1. ADJUSTMENTS WITH COMMANDER 7-2. ADJUSTMENT METHOD Service adjustments to this model can be performed using the Item Number 00 of device GEO supplied Remote Commander RM-964. This explanation uses V-size as an example.
  • Page 48 KV-EX29M61 RM-964 Abbreviation = V-Compressed Mode = Non-compressed Mode ECO = Eco Mode Sur = Surround = Noise Reduction NOTE • shaded items are fixed data. • no data. • Standard data listed on the Adjustment Item Table are reference values, therefore it may be different for each model and for each mode.

  • Page 49: Picture Quality Adjustments

    KV-EX29M61 RM-964 7-3. PICTURE QUALITY ADJUSTMENTS (ii) Copy SCT data to NTSC (RF MODE) PICTURE ADJUSTMENT 1. Set to service mode. 2. Set A/V control to HI-FINE. 3. Set the following condition. Adjustment condition VR1 - VR2 = VR = 2.35 ± 0.07 (Vp-p)

  • Page 50: Deflection Adjustments

    KV-EX29M61 RM-964 7-4. DEFLECTION ADJUSTMENTS Adjust the following items. FOR DRC 1250 (50Hz) MODE Service Item Set to Service Mode. GEO : 02 V LINEARITY Input a Pal cross hatch/dot signal. S CORRECTION Set the following condition. H POSITION Picture Mode to [DYNAMIC], Picture Rotation to [+/–0] PIN AMP and Eco Mode to OFF.

  • Page 51: Picture Distortion Adjustment

    KV-EX29M61 RM-964 7-6. PICTURE DISTORTION ADJUSTMENT (1) PICTURE DISTORTION ADJUSTMENT (2) Item Number 00 – 0B H-TRAPEZOID (DAC 4 HTR) GEO 0 VSZ (V SIZE) GEO 1 VPS (V POSITION) GEO 2 VLN (V LINEARITY) GEO 3 SCO (VERTICAL S-Correction)
  • Page 52 KV-EX29M61 RM-964 MEMO ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...

  • Page 53: Diagrams

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 SECTION 8 DIAGRAMS 8-1. BLOCK DIAGRAM Q8351 BUFFER IC8309 Q8352 CN4500 Q8337 EXTRA-PARA R_OUT R OUT 6 Y IN Y OUT HS_IN G_OUT G OUT Q8333 BUFFER IC8306 8 –U IN –U OUT Q8356 MAIN COLOR DECODER...
  • Page 54 KV-EX29M61 KV-EX29M61 RM-964 RM-964 FROM AV SW CN1193 1 L SP R-SW L-SW TO SPEAKER R SP L HP TO H1 BOARD CN1932 R HP Lout Lch in Lch out OUT2 Rout Rch in Rch out OUT1 IN1 -R IN2 -L...
  • Page 55 KV-EX29M61 KV-EX29M61 RM-964 RM-964 CN6803 V PROT VPROT Q6811, Q6819 Q6820, Q6821 D6605 AC IN MAIN FOCUS CN6604 D6801 RECT DOUBLER PUMP UP Q6801 RY6603 RELAY RY6602 V SAW– RELAY H-OUT DRIVE PIN OUT V SAW+ Q6806 T6804 Q6808 T6602...

  • Page 56: Schematic Diagrams

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 8-2. SCHEMATIC DIAGRAMS Note: • All capacitors are in µF unless otherwise noted. • All electrolytic capacitors are rated at 50V unless otherwise noted. • All resistors are in ohms. kΩ = 1000Ω, MΩ = 1000kΩ...

  • Page 57: Schematic Diagrams Of F1, J And Vm Boards

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (1) Schematic Diagrams of F1, J and VM Boards JW1602 JW1606 CN1603 VDR161 CN2410 :TAB ERZV14D621 JW1605 JW1601 F1601 CN1601 FB1601 :S-MICRO T5A(EX29) 1.1UH J2410 250V TO A BOARD R1602 D2410 R2421 C2410 HZS9.1NB2 CN8302 AC IN...

  • Page 58: Schematic Diagram Of A Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (2) Schematic Diagram of A Board CN1193 CN1190 CN4500 CN1138 :S-MICRO CN1161 :S-MICRO :S-MICRO TO DH BOARD TO H BOARD CN3802 TO H1 BOARD TO CR:CN9001 TO D BOARD CN1932 CN1905 CN6605 C1232 +7V STANDBY +7V STANBY...
  • Page 59 KV-EX29M61 KV-EX29M61 RM-964 RM-964 MAIN MICON,TUVIF,AUDIO AMP R8333 RGB OUT,YCT,COMB FILTER 100:CHIP R8321 VIDEO/AUDIO-IN/OUT C8372 C8386 FL8303 C8369 :CHIP CN8301 R8468 B:CHIP B:CHIP :CHIP :S-MICRO R8300 C8330 R8467 R8469 TO H1 BOARD R8351 :CHIP CN1934 F:CHIP 4.7k :CHIP C8375 :CHIP...

  • Page 60: Schematic Diagram Of D Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (3) Schematic Diagram of D Board CN6607 R6102 C6102 C6100 0.0047 0.0047 TH6100 FB6103 :FPRD 500V THERMISTOR NTC 500V T6100 1-433-844-11 D6100 R6108 C6108 D2SB60A-F04 0.0047 JW6601 FB6101 STBY AC RECT 500V C6107 JW(7.5MM) 0.01 D6105...

  • Page 61: Schematic Diagram Of D1 Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (4) Schematic Diagram of D1 Board CN6104 CN6103 :S-MICRO :S-MICRO TO VM BOARD 6.5V CN6100 C6352 R6119 R6120 :BTOB 135V 3.9k TO D BOARD :RN-CP :RN-CP D6105 R6135 CN6802 D6111 M-PIN RD2.7ES-B2 R6121 135V DC SHIFT...

  • Page 62: Schematic Diagram Of B3 Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (5) Schematic Dia gram of B3 Boar d 3.3V Q601 2SC1623-L5L6 3.3V C639 L604 C638 BUFFER 0.01 10UH 0.01 FL601 Q602 B:CHIP :CHIP B:CHIP CKD510JB1A105ST R687 2SC1623-L5L6 C601 ADTB L605 R688 R689 BUFFER IC605 10UH :CHIP 3.3k...

  • Page 63: Schematic Diagram Of C Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (6) Schematic Dia gram of C Board CN9007 TO D BOARD CN6810 C9034 R9055 820k 1/2W RV9002 2.2M 1/2W R9058 NL9002 820k C9031 1/2W 0.0047 L9001 J9001 R9056 C9032 2.2UH 680p SOCKET CRT 200V R9089 IC9001...

  • Page 64: Schematic Diagram Of V2 Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (7) Schematic Dia gram of V2 Boar d (TELETEXT) D5802 D5801 DAP202K-T-146 C5825 IC5801 PROTECT SAA5261 TEXT DECODER R5831 C5828 0 :CHIP L5800 EAST/WEST 100UH R5830 0 :CHIP :LHL08 8/30 R5829 100 :CHIP R5828 100 :CHIP...

  • Page 65: Schematic Diagram Of H1 Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (8) Schematic Dia gram of H1 Board CN1905 CN1652 CN1651 CN1932 CN1934 :S-MICRO :S-MICRO :S-MICRO TO A BOARD TO A BOARD TO A BOARD CN1190 & CN1195 TO D BOARD TO F1 BOARD CN1193 CN8301 CN6604...

  • Page 66: Schematic Diagram Of Dh Board

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 (9) Schematic Dia gram of DH Board IC3807 C3801 X OUT IC3805 N/S DRIVE R3846 C3805 Q3811 BUFFER R3805 R3847 CN3804 R3807 TO LCC R3856 D3809 R3853 Q3810 R3804 N/S(B) R3848 R3857 R3828 R3825 BUFFER N/S(E)

  • Page 67: Voltage Measurements

    KV-EX29M61 RM-964 8-3. VOLTAGE MEASUREMENTS A(1/4) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC001 IC003 IC1204 27.5 <(0.6)>[3.5] 13.6 1.4[3.5]<(0.9)> [(✽)] <2.2> IC004 28.3 13.2 <[4.9]>(0) [(0.6)]<1.6> 13.4 [(0.5)]<1.6> IC1205 [0]<(4.9)> IC100 IC1200 [(0.5)]<1.6> <(0.2)>[0] <(4.5)>[4.9]...
  • Page 68 KV-EX29M61 RM-964 A(2/4) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC2300 [0]<(4.4)> [0]<(6.6)> [0]<(9.1)> [0]<(3.8)> [(3.6)]<0> [(0)]<4.9> [0]<(4.3)> IC2600 13.0 IC8305 13.1 IC2601 [0]<(4.6)> IC8306 <[0]>(2.2) [0.1]<(1.9)> IC2603 IC8302 [0]<(1.6)> IC2604 [0]<(4.5)> IC4301 [0]<(4.2)> <[3.4]>(0) [0]<(9.1)>...
  • Page 69 KV-EX29M61 RM-964 A(3/4) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC8309 Q1203 Q4308 (0.2)<[0]> Q1204 Q4310 [0]<(3.1)> Q1205 [(0)]<5.5> Q4311 [(0)]<9.0> IC8310 [0]<(4.9)> Q1206 Q4312 <5.5>[(0)] <(2.3)>[0] ✻ Q1207 28.0 Q4313 ✻ ✻ 18.1 Q1208 Q4314 13.2...
  • Page 70 KV-EX29M61 RM-964 A(4/4) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] Q8308 Q8330 Q8352 Q8309 Q8331 Q8358 Q8310 Q8332 Q8359 <(0.1)>[0] Q8333 Q8360 Q8319 [0]<(1.8)> [(7.1)]<6.7> Q8320 Q8334 Q8361 Q8321 Q8335 Q8362 <7.1>[(6.7)] Q8326 Q8336 Q8363...
  • Page 71 KV-EX29M61 RM-964 D1(1/2) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] -3.3 IC4800 -15.0 -3.5 IC6108 -3.0 -4.0 -4.1 11.7 Q4800 IC4801 Q4801 Q4802 IC4802 Q4803 Q4804 Q4805 IC6101 Q4806 IC6201 Q4807 -21.7 Q4808 IC6102 Q4809 2.17...
  • Page 72 KV-EX29M61 RM-964 D1(2/2) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] Q4821 Q6108 Q6202 -0.6 Q4822 Q6118 Q6203 -6.0 -2.3 -6.6 Q6103 30.2 Q6124 Q6350 Q6125 Q6356 Q6104 Q6105 Q6126 Q6405 -0.6 -4.5 Q6106 Q6128 Q6455 -3.3...
  • Page 73 KV-EX29M61 RM-964 B3(1/3) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC501 IC504 IC505 IC603 IC506 IC602 IC604 – 87 –...
  • Page 74 KV-EX29M61 RM-964 B3(2/3) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] IC601 – 88 –...
  • Page 75 KV-EX29M61 RM-964 B3(3/3) BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] Q501 Q521 Q902 Q502 Q522 Q903 Q503 Q523 Q907 Q601 Q908 Q516 Q517 Q602 Q909 Q518 Q901 C BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No.
  • Page 76 KV-EX29M61 RM-964 D BOARD VOLTAGE LIST Pin No. Voltage[v] Pin No. Voltage[v] Pin No. Voltage[v] ✻ IC6600 IC6806 Q6804 ✻ ✻ ✻ Q6805 -0.3 Q6100 Q6806 -0.3 17.8 Q6102 0.01 10.4 Q6809 20.0 Q6600 ✻ Q6810 Q6601 -0.02 Q6811 ✻...

  • Page 77: Waveforms

    KV-EX29M61 RM-964 8-4. WAVEFORMS A BOARD WAVEFORMS 5.5Vp-p 4.2Vp-p 0.4Vp-p 0.4Vp-p 0.3Vp-p 1.5Vp-p 1.6Vp-p 4.4Vp-p 2.8Vp-p 1.4Vp-p NTSC 0.9Vp-p 2.6Vp-p 1.2Vp-p 1.6Vp-p 5.2Vp-p 1.1Vp-p 1.4Vp-p 0.6Vp-p 0.1Vp-p D BOARD WAVEFORMS SECAM/NTSC 0.7Vp-p 30.8Vp-p 0.9Vp-p 1.9Vp-p 53Vp-p 2.9Vp-p 242Vp-p 378Vp-p 76.8Vp-p 3.6Vp-p...
  • Page 78 KV-EX29M61 RM-964 B3 BOARD WAVEFORMS 0.8Vp-p 0.9Vp-p 1.0Vp-p 1.6Vp-p 1.4Vp-p 1.4Vp-p 6.8Vp-p C BOARD WAVEFORMS NTSC SECAM NTSC 120Vp-p 0.6Vp-p 122Vp-p 5.0Vp-p 3.0Vp-p NTSC NTSC NTSC 120Vp-p 114Vp-p 106Vp-p 0.1Vp-p 106Vp-p SECAM/NTSC NTSC 4.0Vp-p 0.3Vp-p 4.1Vp-p 2.2Vp-p 4.0Vp-p NTSC NTSC 4.6Vp-p...

  • Page 79: Printed Wiring Boards And Parts Location

    KV-EX29M61 KV-EX29M61 RM-964 RM-964 8-5. PRINTED WIRING BOARDS AND PARTS LOCATION PRINTED WIRING BOARDS [MAIN MICON, TUVIF, AUDIO AMPLIFIER, RGB OUT, YCT, COMB FILTER, VIDEO/AUDIO IN/OUT] – A Board – (Component Side) A BOARD (Componet Side) IC001 C-13 IC002 C-11...
  • Page 80 KV-EX29M61 KV-EX29M61 RM-964 RM-964 [MAIN MICON, TUVIF, AUDIO AMPLIFIER, RGB OUT, YCT, COMB FILTER, VIDEO/AUDIO IN/OUT] A BOARD (Conductor Side) – A Board – (Conductor Side) Q8320 D-9 Q8321 D-10 IC001 F-10 Q8325 C-11 IC1200 G-3 Q8326 D-8 IC1201 H-4...
  • Page 81 KV-EX29M61 KV-EX29M61 RM-964 RM-964 PRINTED WIRING BOARDS N O T E : The circuit indicated at left contains high voltage of over 1220 Vp-p. Please pay attention when inspecting or re- [POWER SUPPLY, DEFLECTION HV] pairing it to prevent an electric shock.
  • Page 82 KV-EX29M61 KV-EX29M61 RM-964 RM-964 PRINTED WIRING BOARDS [DYNAMIC FOCUS, DYNAMIC QUAD POLE [AC SW, AV INPUT, PRESET KEY, [MAGNETIC FIELD CORRECTION] [COMPONENT IN] DRIVE, HORIZONTAL DRIVE GENERATOR] PHONE OUT,LED, SIRCS RECEIVER] – D1 Board – – DH Board – – J Board –...
  • Page 83 KV-EX29M61 RM-964 PRINTED WIRING BOARD [DIGITAL REALITY CREATION] – B3 Board – (Component Side) B3 BOARD (Component Side) R668 C556 R659 IC501 R653 IC504 IC505 IC601 R600 IC505 R699 IC601 C611 IC602 D601 IC603 FL511 C524 TRANSISTOR C525 RB025 RB026...
  • Page 84 KV-EX29M61 RM-964 PRINTED WIRING BOARDS [VIDEO AMPLIFIER] [AC LINE FILTER] – C Board – – F1 Board – – 102 –...
  • Page 85 KV-EX29M61 RM-964 PRINTED WIRING BOARDS [VELOCITY MODULATION] [TELETEXT] – V2 Board – – VM Board – – 103 –...

  • Page 86: Semiconductors

    KV-EX29M61 RM-964 8-6 SEMICONDUCTORS TRANSISTOR 2SK2663 2SC5480-01 2SA1776TV2Q 2SB733-34 2SK2251-01-F19 IRF720-LF49 2SD774-34 DIODE LETTER SIDE DTC144ESA 2SC2500-B 2SA2005 DTC144EKA DTC114EK D10SC4M DTC114ESA 2SA1037AK-T146R 2SC5511 2SB709A-QRS 2SA1175-HFE 2SA1162-YG DTC143TKA-T146 2SC3840(3) 2SC2785-HFE 2SC1623-L5L6 IRF1830G-LF49 2SC2712-YG IRFIB7N50A 2SD601A-Q BA12T DTC114TKA-T146 BA09T UN2213 2SD2114K...
  • Page 87 KV-EX29M61 RM-964 DIODE CATHODE TOP VIEW Single In -line Package ANODE Pin 8~98 MMDL914T1 D1NS4 ERA38-06 BH3868BFS-E2 TC7SET08FU(TE85) DM-58 RD5.1ESB2 D1N20R CXA1211M TDA9178T/N1.118 RD2.2ESB2 RD18ES-B2 MB88141APF-ER TLC2932IPW RD10ESB2 RD18ESB MM1115XFBE TLC2933IPWR RD2.7ESB2 RD3.6ES-B1 MM1476AF(TP) UPC358C RD4.7ESB2 RD6.8ES-B1 M24C16-MN6T UPC4558G2 RD12ESB1 NJM2188M-TE2 RD7.5ES-B2...

  • Page 88: Exploded Views

    KV-EX29M61 RM-964 SECTION 9 EXPLODED VIEWS NOTE: • • Items marked " ∗ " are not stocked since Items with no part number and no The components identified by description are not stocked because they are seldom required for routine...

  • Page 89: Chassis

    KV-EX29M61 RM-964 9-2. CHASSIS r : 7-685-648-79 SCREW +BVTP 3 × 12 p : 7-685-663-71 SCREW +BVTP 4 × 16 REF. NO. PART NO. DESCRIPTION REMARK * A-1372-869-A H1 BOARD, MOUNTED * A-1299-657-A A BOARD, COMPLETE * A-1388-332-A J BOARD, MOUNTED...

  • Page 90: Picture Tube

    KV-EX29M61 RM-964 9-3. PICTURE TUBE r : 7-685-648-79 SCREW +BVTP 3 × 12 p : 7-685-663-71 SCREW +BVTP 4 × 16 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK X-4039-625-1 BEZNET ASSY 152-155 4-064-883-03 HOLDER, DGC...

  • Page 91: Electrical Parts List

    KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. SECTION 10 Replace only with part number specified. ELECTRICAL PARTS LIST REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK • Items marked " ∗ " are not stocked since •...
  • Page 92 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C1265 1-249-429-11 CARBON 1/4W C4301 1-164-004-11 CERAMIC CHIP 0.1UF...
  • Page 93 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C8307 1-163-133-00 CERAMIC CHIP 470PF 5.00% C8393 1-164-004-11 CERAMIC CHIP 0.1UF...
  • Page 94 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK D4312 8-719-914-43 DAN202K IC1205 8-759-711-10 NJU4066BM D4313 8-719-401-63...
  • Page 95 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <IC LINK> Q8352 8-729-026-49 2SA1037AK-T146-R Q8358 1-801-806-11 TR DTC144EKA...
  • Page 96 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R066 1-216-049-11 RES-CHIP 1/10W R1222 1-216-055-00 RES-CHIP 1.8K...
  • Page 97 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R4314 1-216-057-00 RES-CHIP 2.2K 1/10W R4392 1-216-089-91 RES-CHIP...
  • Page 98 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R8349 1-216-049-11 RES-CHIP 1/10W R8471 1-216-025-11 RES-CHIP 1/10W...
  • Page 99 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK * A-1136-132-A B3 BOARD COMPLETE C619 1-163-038-91 CERAMIC CHIP 0.1UF...
  • Page 100 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <IC> R520 1-208-776-11 METAL CHIP 0.5% 1/10W R521...
  • Page 101 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R631 1-216-295-91 SHORT R912 1-216-049-11 RES-CHIP 1/10W R634...
  • Page 102 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C9024 1-163-035-00 CERAMIC CHIP 0.047UF <TRANSISTOR> C9025 1-104-653-11...
  • Page 103 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C6658 1-104-330-91 CERAMIC 470PF 10.00% 1KV * A-1346-975-A D BOARD COMPLETE...
  • Page 104 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK C6858 1-102-228-00 CERAMIC 470PF 10.00% 500V D6105 8-719-948-45...
  • Page 105 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK IC6607 8-749-012-13 DM-58 Q6610 8-729-119-78 2SC2785-HFE IC6608 8-759-133-90...
  • Page 106 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R6620 1-208-846-11 METAL CHIP 470K 0.5% 1/10W R6696...
  • Page 107 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R6860 1-215-923-00 METAL OXIDE <THERMISTOR> R6861 1-216-295-91 SHORT...
  • Page 108 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK D4803 8-719-911-19 1SS119-25 C6118 1-107-909-11 ELECT 47UF 20.00% 16V...
  • Page 109 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK JR6112 1-216-295-91 SHORT R4410 1-216-057-00 RES-CHIP 2.2K 1/10W...
  • Page 110 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R6151 1-216-049-11 RES-CHIP 1/10W R4860 1-208-794-11 METAL CHIP 3.3K...
  • Page 111 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK R6361 1-216-097-11 RES-CHIP 100K 1/10W * A-1241-437-A F1 BOARD MOUNTED...
  • Page 112 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK <SWITCH> <CONNECTOR> CN1651 * 1-580-844-11 PIN, CONNECTOR (POWER)
  • Page 113 KV-EX29M61 RM-964 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK * A-1347-165-A V2 BOARD COMPLETE <RESISTOR> ********************* R5800...
  • Page 114 1-249-415-11 CARBON 1/4W 9-933-895-11 BATTERY COVER REMOTE COMMANDER R5403 1-247-739-11 CARBON 1/2W R5404 1-249-418-11 CARBON 1.2K 1/4W R5406 1-249-425-11 CARBON 4.7K 1/4W Sony Corporation Sony Technology Malaysia Sdn. Bhd. English  9-872-267-01 Visual Products General Area 2001.9 – 132 –...
