TH-L32C10S 1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
TH-L32C10S 2 Prevention Electro Static Discharge (ESD) Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field- effect transistors and semiconductor “chip”...
TH-L32C10S 3 About Lead Free Solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead Solder and PbF will refer to Lead Free Solder. The Lead Free Solder (PbF) used in our manufacturing process and discussed below is (Sn+Ag+Cu).
TH-L32C10S 4 Power LED Blinking Timing 1. Subject Information of LED Flashing timing. 2. Contents When an abonormality has occurred in the unit, the protection circuit operates and resets to standby mode. At this time, the defective block can be identified by the number of blinking of the Power LED on the front panel of the unit as follow:...
TH-L32C10S 5 Chassis Board 5.1. Chassis Installation 1. Stick FELT to SIDE AV BRACKET. - Stick the SIDE AV INDI. SHEET on the SIDE AV BRACKET. - Insert the SIDE AV BRACKET from the side position of the A-PCB.
TH-L32C10S 7 Disassembly and Assembly Instructions 7.1. AC Cord Installation 1. Put on the AC CORD BRACKET on the CABINET. 2. Fix the AC CORD BRACKET with SCREW. 3. AC CORD BARRIER setting. 4. Insert AC CORD connector into P-PCB connector.
TH-L32C10S 7.2. VESA Metal Assembly 1. Assemble LCD TOP MTG(L,R) , VESA METAL(upper) and fix them with screw. Please use jig for vesa metal assembly preparation.
TH-L32C10S 7.5. LED Panel Installation & Fitting 1. Put LED SHADE RIB on CABINET. 2. Fix LED PANEL on CABINET. 3. Wire connecting. (V10) 4. Put V-PCB on CABINET. 5. Fix them with SCREW. 6. Insert the CLAMPER.
TH-L32C10S 7.6. Control Panel Assembly 1. Wire connecting. (K1) 2. Assemble POWER BUTTON to the K-PRINT. 3. Assemble K-PRINT, CONTROL BUTTON, CONTROL PANEL BRACKET. 4. Fix them with SCREWS. 5. Stick the FELT.
TH-L32C10S 7.7. A-PB-MTG & Control Button Fixing 1. Stick P-PCB BARRIER and put all METAL part follow to the picture. Fix all metal part with screw. 2. Put CONTROL PANEL ASSY on the CABINET. Fix the CONTROL PANEL with SCREWS.
TH-L32C10S 7.9. Speaker Installation 1. Stick the SPONGE. Follow the spec. below. 2. SP BRACKET slot at CABINET. 3. Insert the SP RUBBER BUSH into the SP UNIT. 4. Insert the SP UNIT to SP BRACKET. 5. Fix them with SCREWS.
TH-L32C10S 7.10. LCD Panel 1. Remove dust of terminal of LVDS. (by ion blow) 2. Remove dust of terminal of T-con connector. (by ion blow) 3. Insert LVDS into T-con connector. 4. Stick the tape to fix LVDS. 5. Stick the SPONGE at left and right lcd panel.
TH-L32C10S 7.11. LCD Mouting Fixing Step 1 1. LCD SIDE MTG on the CABINET. 2. LCD BTM MTG on the CABINET. 3. LCD BOTTOM CORNER MTG on the CABINET. 4. Fix them with SCREW. Step 2 1. Assemble LCD TOP MTG (L, R), VESA METAL (upper) and fix them with SCREWS.
TH-L32C10S 7.13. EMI Spec (LVDS) 1. When insert LVDS wire to T-con conector,make sure must center position follow bellow picture. 2. After fixing LVDS wire please bent again follow the picture.
TH-L32C10S 8 Service Mode Adjustment Set timer to 30min, press the “RECALL” button on the remote control and press “-” vol button on the LCD panel. • Press button R and G for adjustment. 8.1. Self Check Mode 1. Press the “MENU” button (on the remote control ) and the “DOWN” button on the LCD panel.
TH-L32C10S 9 Measurements and Adjustments 9.1. Voltage Chart of A Board Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table. Specification (V) Power Supply Name Measurement Point TNP4G460 / TNP4G461 SUB1.2V TP5602 1.22 - 1.32...
TH-L32C10S 11 Schematic Diagram 11.1. Schematic Diagram Notes Notes : 1. Resistor Unit of resistance is OHM [Ω] (K = 1 000, M = 1 000 000). 2. Capacitor Unit of capacitance is μF unless otherwise noted. 3. Coil Unit of inductance is μF unless otherwise noted.
TH-L32C10S 12 Exploded View and Replacement Parts List 12.1. Exploded View and Mechanical Replacement Parts List Please click the radio button for “Diagrams ll/Parts List” on the menu bar. 12.2. Electrical Replacement Parts List 12.2.1. Replacement Parts List Notes Important Safety Notice Components identified by mark have special characteristics important for safety.
TH-L32C10S 12.2.2. Electrical Replacement Parts List Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C2266 F1G1H101A731 CHIP RESISTOR C2301 F1G1C104A116 CERAMIC CAPACITOR CAPACITORS C2302 F1G1C104A116 CERAMIC CAPACITOR C1009 F1G1A105A047 CAPACITOR...
Page 113
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C3007 F1G1H561A730 CHIP CAPACITOR C4617 F1J1A475A039 CERAMIC CAPACITOR C3008 F1G1H561A730 CHIP CAPACITOR C4624 F1G1C104A116 CERAMIC CAPACITOR C3013 F1G1H561A730 CHIP CAPACITOR C4625...
Page 114
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C7104 F1A2E221A003 CERAMIC CAPACITOR C7863 F1J1H332A834 CERAMIC CAPACITOR C7107 ECKW3A103MEH CAPACITOR C7864 F1J1H103A834 CERAMIC CAPACITOR C7108 F0CAF224A066 PLASTIC FILM CAPACITOR C7865...
Page 115
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C8056 F1G1C104A116 CERAMIC CAPACITOR D5626 MAZ80470ML DIODE C8057 F1G1C104A116 CERAMIC CAPACITOR D5627 MA2J11100L DIODE C8058 F1J1A106A043 CERAMIC CAPACITOR D7101 D4EAC6210002 VARISTOR...
Page 116
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks D7824 MTZJ15B ZENER DIODE L3010 J0JCC0000287 COIL D7851 MA3X152E0L DIODE L3011 J0JCC0000287 COIL D7852 MA3X152E0L DIODE L3014 J0JCC0000287 COIL D7853 MA3X157A0L...
Page 117
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks Q4205 2SD0601A0L TRANSISTOR R0916 ERJ2GEJ472X RESISTOR Q4206 2SC39380QL TRANSISTOR R0917 ERJ2GEJ220X FIXED RESISTOR Q4500 B1ABCF000231 TRANSISTOR R0918 ERJ2GEJ220X FIXED RESISTOR Q4501...
Page 118
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R2003 ERJ2GEJ105X FIXED RESISTOR R2777 ERJ2GEJ103X FIXED RESISTOR R2006 ERJ2GEJ471X RESISTOR R2778 ERJ2GEJ103X FIXED RESISTOR R2007 ERJ2GEJ221X RESISTOR R2779 ERJ3GEYJ751 RESISTOR...
Page 119
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R3237 ERJ2GEJ680X RESISTOR R4616 ERJ2GE0R00X FIXED RESISTOR R3240 ERJ2GEJ221X RESISTOR R4620 ERJ2GEJ473X FIXED RESISTOR R3287 ERJ2GEJ473X FIXED RESISTOR R4623 ERJ2GE0R00X FIXED RESISTOR...
Page 120
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R5475 ERJ2GEJ103X FIXED RESISTOR R7302 ERJ12YJ474U RESISTOR R5476 ERJ2GEJ153X RESISTOR R7303 ERG3SJ470P M 47OHM,J,3W R5479 ERJ2GE0R00X FIXED RESISTOR R7304 ERX1SJR68P M 0.68OHM,J,1W...
Page 121
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R7729 ERJ6GEYJ100 M 10OHM,J,1/10W R7908 ERJ6ENF4702 M 47KOHM, 1/10W R7735 ERJ6GEYJ103 M 10KOHM,J,1/10W R7909 ERJ6ENF4702 M 47KOHM, 1/10W R7800 ERJ6GEY0R00 M 0OHM,J,1/10W...
Page 122
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R8108 ERJ2GEJ223X RESISTOR R8891 ERJ2GEJ680X RESISTOR R8412 ERJ2GEJ103X FIXED RESISTOR R8892 ERJ2GEJ680X RESISTOR R8471 ERJ2GEJ103X FIXED RESISTOR R8894 ERJ2GEJ680X RESISTOR R8472...
Page 123
TH-L32C10S Safety Ref. Part No. Part Name & Description Remarks RL7103 K6B1AYY00048 AC RELAY RM2500 B3RAD0000168 PHOTO DETECTOR SN2500 B3JB00000046 PHOTO DETECTOR SW2600 ESB33535XFD POWER SWITCH SW2601 K0H1BA000445 CONNECTOR SW2602 K0H1BA000445 CONNECTOR SW2603 K0H1BA000445 CONNECTOR SW2604 K0H1BA000445 CONNECTOR SW2605 K0H1BA000445 CONNECTOR...
Page 125
Model No. : TH-L32C10S Packing Exploded View...
Page 126
Model No. : TH-L32C10S Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks K2CQ2YY00036 AC CORD L0AA14B00002 SPEAKER L5EDD8Q00058 LCD PANEL N2QAYB000399 REMOTE CONTROL TBL4GA0028 PEDESTAL ASSY TBM4GA002 PANASONIC LOGO SHEET TBM4GC299 MODEL NAME PLATE TBM4GU032 HDMI SHEET TBM4GU045 SIDE AV INDI.
