KIDS LOCKER
KIDS LOCKER
Before you begin assembly, please read these instructions. See next page for important
warning statements on this product. After product is assembled make sure all bolts and
screws are securely tightened.
Note: Product may vary slightly from images shown.
LPA1 LLC
Important Information:
LPA200
LPA200
A
PRN: AIM-LPA200-LPN [16.08.11]
Advertisement
Related Manuals for Little Partners LPA200
Summary of Contents for Little Partners LPA200
- Page 1 Note: Product may vary slightly from images shown. LPA1 LLC Important Information: Before you begin assembly, please read these instructions. See next page for important warning statements on this product. After product is assembled make sure all bolts and screws are securely tightened. PRN: AIM-LPA200-LPN [16.08.11]...
- Page 2 KEEP INSTRUCTIONS FOR FUTURE USE NEVER use this product if there are any loose or missing fasteners, loose joints broken parts. Check after assembly and periodically during use at least once a week READ all instructions BEFORE assembly and USE of the product NEVER substitute parts CONTACT us for replacement parts.
- Page 3 USEFUL HINTS AND TIPS Assemble product on a soft surface like a carpet/rug or blanket to protect finish. While one person can assemble this item two people are recommended DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT. USE OF POWER TOOLS WILL INVALIDATE ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 4 PARTS LIST (LPA200-X-1) x1 (LPA200-X-2) x1 (LPA200-X-3) x1 (LPA200-X-4) x1 (LPA200-X-10) x1 Anti-tip Label PPI Label Product Packaging Information LPA1 LLC. Model : # 501 South 9th Street Reading, PA 19602 Color: Toll Free: 1-800-704-9058 Shipment Ref. #: customercare@rbollc.com MADE IN CHINA...
- Page 5 HARDWARE Assembly Hardware supplied (actual size) mm 10 Ref. Name Head M3.5 x 14mm Screw M4 x 25mm Screw M5 x 50mm Allen Head Screw 1.5 x 18mm Nail 8 x 30mm Wood Dowel 8 x 50mm Wood Dowel 15mm Cam Lock Cam Stud "...
- Page 6 ASSEMBLY INSTRUCTIONS Insert all wood dowels, and cam locks. Screw in all cam studs Cam Stud [x13] 8 x 30mm Wood Dowel [x28] 8 x 50mm Wood Dowel [x4] 15mm Cam Lock [x13] Make sure arrow is pointing towards end of wood INSTALLING CAM STUD Tighten with a rubber hammer until no...
- Page 7 ASSEMBLY INSTRUCTIONS Assembly of Hooks M3.5 x 14mm Screw [x8] TURN OVER Hook [x4] Make sure there is NO space between panel 8 and 9 when assembled. M5 x 50mm Allen Head Screw [x2]...
- Page 8 ASSEMBLY INSTRUCTIONS TIGHTENING CAM LOCKS Use screw driver to turn to tighten clock wise( at least past the half way point). Screw driver ARROW ARROW...
- Page 9 ASSEMBLY INSTRUCTIONS M5 x 50mm Allen Head Screw [x1]...
- Page 10 ASSEMBLY INSTRUCTIONS Line up wood dowels and cam bolts with holes first, then use a rubber hammer to GENTLY join part 2 with body of locker to ensure NO GAPS before tightening cam locks. TIGHTENING CAM LOCKS Use screw driver to turn to tighten clock wise( at least past the half way point). Screw driver ARROW ARROW...
- Page 11 ASSEMBLY INSTRUCTIONS M5 x 50mm Allen Head Screw [x2] Line up wood dowels and cam bolts with holes first, then use a rubber hammer to GENTLY join part 1 with body of locker to ensure NO GAPS before tightening cam locks.
- Page 12 ASSEMBLY INSTRUCTIONS TIGHTENING CAM LOCKS Use screw driver to turn to tighten clock wise( at least past the half way point). Screw driver ARROW ARROW M5 x 50mm Allen Head Screw [x2]...
- Page 13 ASSEMBLY INSTRUCTIONS THERE ARE 2 OPTIONS FOR ASSEMBLING THE TOP. SEE BOTH OPTIONS BELOW TO PROCEED TOP overhangs TOP overhangs on front on back BASEBOARD Side view Side view OPTION A - WALL WITHOUT BASE BOARD OPTION B - WALL WITH BASE BOARD ASSEMBLY FOR OPTION A TOP overhangs on front...
- Page 14 ASSEMBLY INSTRUCTIONS ASSEMBLY FOR OPTION B TOP overhangs on back Insert nail into pre-drilled guild hole for easier assembly. Make sure you are careful to line up nails into center of each 1.5 x 18mm Nail [x30] piece of wood. Assembly complete.
- Page 15 ATTACHING YOUR UNIT TO THE WALL DANGER Furniture that is not secured to a wall could tip over and cause an injury. This unit includes an anti-tip kit. BEFORE use, ensure kit is installed correctly and secured safely to the wall. See instructions for further information. OPTION A - WALL STUD M4 x 40mm Screw [x1] 200 x 25mm Starp (not to scale) [x1]...
- Page 16 ATTACHING YOUR UNIT TO THE WALL M3.5 x 14mm Screw [x1] FRONT VIEW 12 x 2mm Plastic Washer [x1] FRONT VIEW Back Side of Unit Push the unit up Ÿ against the wall lining Attach the end of the wall strap Ÿ...
- Page 17 PRODUCT LIMITED WARRANTY Who is covered by this warranty? This warranty extends to the original purchaser only and will need proof of purchase. Time period of this warranty. The 1 year term of this warranty shall commence on the date of the original purchase.
