Sanyo PLV-Z1 Service Manual
Hide thumbs
Also See for PLV-Z1:
- Service manual (67 pages) ,
- Brochure & specs (3 pages) ,
- Owner's manual (52 pages)
Table of Contents
Advertisement
Quick Links
SERVICE MANUAL
NOTE: PLV-Z1 (Chassis No. M4J-Z101) and PLV-Z1BL (Chassis No. M4J-Z1BL00) are
basically the same as original model PLV-Z1 (Chassis No. M4J-Z100).
Any information not contained in this manual will be found in the original model's
service manual SM5110416-00 issued in November 2002.
FILE WITH ORIGINAL SERVICE MANUAL SM5110416
PRODUCT CODE
112211540 PLV-Z1 (M4JAB)
112211640 PLV-Z1 (P4JAB)
112211642 PLV-Z1 (P4JCB)
112211560 PLV-Z1BL (M4JAC)
112211660 PLV-Z1BL (P4JAC)
112211662 PLV-Z1BL (P4JCC)
Multimedia Projector
Differences ------------------------------------------------------------------------------ 2
1. Owner's Manual ----------------------------------------------------------------- 2
2. Board (ASSY, PWB) ------------------------------------------------------------ 2
3. Cabinet Parts (for PLV-Z1BL) ------------------------------------------------ 2
Service Notice -------------------------------------------------------------------------- 2
1. Inserting Socket of Lead Wire ----------------------------------------------- 2
2. Correction of Service Manual (SM5110416-00) ------------------------ 2
Electrical Parts List -------------------------------------------------------------- 3 - 13
1. Assy, PWB, AV -------------------------------------------------------------- 3 - 4
2. Assy, PWB, Main --------------------------------------------------------- 5 - 13
Mechanical Parts List (PLV-Z1BL) ----------------------------------------- 14 - 15
Schematic Diagrams ---------------------------------------------------------- A1 - A6
FILE NO.
Model No. PLV-Z1
PLV-Z1BL
(U.S.A., Canada, Europe
Asia, Africa, U.K. )
ORIGINAL VERSION
Chassis No. M4J-Z101
(PLV-Z1)
M4J-Z1BL00
(PLV-Z1BL)
NOTE: Match the Chassis No. on the
unit's back cover with the Chassis
No. in the Service Manual.
If the Original Version Service
Manual Chassis No. does not
match the unit's, additional
Service Literature is required. You
must refer to "Notices" to the
Original Service Manual prior to
servicing the unit.
CONTENTS
REFERENCE NO.
Pages
SS
5110430-00
Advertisement
Table of Contents
Related Manuals for Sanyo PLV-Z1
Summary of Contents for Sanyo PLV-Z1
-
Page 1: Service Manual
Original Service Manual prior to servicing the unit. NOTE: PLV-Z1 (Chassis No. M4J-Z101) and PLV-Z1BL (Chassis No. M4J-Z1BL00) are basically the same as original model PLV-Z1 (Chassis No. M4J-Z100). Any information not contained in this manual will be found in the original model’s service manual SM5110416-00 issued in November 2002. -
Page 2: Board (Assy, Pwb)
Refer to the Electrical Parts List and the Schematic Diagrams for detail. 3. Cabinet Parts (for PLV-Z1BL) There are differences of the cabinet parts between PLV-Z1 and PLV-Z1BL. Refer to the Mechanical Parts LIst of PLV-Z1BL for detail. ■ Service Notice 1. -
Page 3: Integrated Circuit
■ Electrical Parts List Key No. Part No. Description Key No. Part No. Description INTEGRATED CIRCUIT 610 304 7775 ASSY,PWB,AV M4JAB 1AA0B10C412AA IC1051 409 526 5306 IC BD7600FV IC2031 409 252 3102 IC NJM2284M-TE2 TRANSISTOR IC5201 409 530 7204 IC AN5870SB Q1007 405 014 4509 TR 2SC2412K T146 R... - Page 4 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R2011 401 260 4102 MT-GLAZE 75 JA 1/3W L5271 401 035 9004 MT-GLAZE 18 JA 1/8W R2013 401 105 2904 MT-GLAZE 22K JA 1/16W L5272 401 035 4108 MT-GLAZE 0.000 ZA 1/8W...
- Page 5 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description Q361 405 045 8705 TR 2SK536-TB Q362 405 045 8705 TR 2SK536-TB 610 304 7751 ASSY,PWB,MAIN M4JAB 1AA0B10C423BA Q4501 405 014 4509 TR 2SC2412K T146 R 405 014 4608 TR 2SC2412K T146 S TRANSISTOR...
- Page 6 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 163 1701 TR 2SC2812N-L7-TB0 405 015 8902 TR 2SC2812-L7-TB Q6332 405 134 5905 TR 2SA1037AK-T146-R 405 163 1602 TR 2SC2812N-L6-TB0 405 147 2205 TR 2SA1037AK-S-T146 405 163 1701 TR 2SC2812N-L7-TB0 405 002 0308...
- Page 7 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description IC7252 409 433 4201 IC MN13821-H-TX C303 403 164 0204 CERAMIC 0.1U Z IC7801 409 428 9600 IC M62399FP C304 403 322 7809 ELECT 220U M 6.3V IC7821 409 461 7809...
- Page 8 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description C503 403 304 1801 ELECT 100U M 6.3V C567 403 149 9208 CERAMIC 0.01U Z 403 373 7704 ELECT 100U M 6.3V C5671 403 164 0204 CERAMIC 0.1U Z C504...
- Page 9 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description C7832 403 164 0204 CERAMIC 0.1U Z 645 037 0823 R-NETWORK 22X4 1/32W C7833 403 164 0204 CERAMIC 0.1U Z RB409 645 034 5050 R-NETWORK 22X4 1/32W C7842 403 164 0204 CERAMIC...
- Page 10 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description R116 401 105 0306 MT-GLAZE 10 JA 1/16W R1823 401 105 2508 MT-GLAZE 20K JA 1/16W R121 401 105 0405 MT-GLAZE 100 JA 1/16W R1824 401 105 0603 MT-GLAZE 10K JA 1/16W R122...
- Page 11 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description R3576 401 105 0306 MT-GLAZE 10 JA 1/16W R457 401 105 3901 MT-GLAZE 33 JA 1/16W R3577 401 105 0306 MT-GLAZE 10 JA 1/16W R4572 401 105 0504 MT-GLAZE 1K JA 1/16W R3578...
- Page 12 MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description R5621 401 247 0509 MT-GLAZE 6.8 JA 1/3W R6361 401 105 0504 MT-GLAZE 1K JA 1/16W R563 401 105 1105 MT-GLAZE 12K JA 1/16W R6362 401 105 0504 MT-GLAZE 1K JA 1/16W R5631...
-
Page 13: Electrical Parts List
MAIN Electrical Parts List Key No. Part No. Description Key No. Part No. Description R7843 401 105 0504 MT-GLAZE 1K JA 1/16W L5601 645 038 4578 INDUCTOR,33U M R7844 401 105 6605 MT-GLAZE 6.8K JA 1/16W L561 645 020 1776 INDUCTOR,3.3U M R7846 401 105 7909... -
Page 14: Mechanical Parts List (Plv-Z1Bl)
■ Mechanical Parts List (PLV-Z1BL) -14-... -
Page 15: Cabinet Parts
DEC INLAY LED-M4JA 610 302 5612 DEC SHEET-M4JA 610 304 0783 DEC AV SHEET-M4JAA 610 304 0790 PANEL LMP-M4JAA 610 293 9972 SPACER LEG-MA8A 610 302 7647 STOPPER LID-M4JA 645 038 3601 BADGE,SANYO*26.2X5.7L26.0 (1, 12, 13, 17, 18: Common with PLV-Z1) -15-... - Page 16 DEC / 2002 Printed in Japan SANYO Electric Co., Ltd.
