MR218085085180 PUSH SWITCH PS-8.5x8.5-180G W/
MR219924115506 SLIDE SW. SS24E01G6 2P4T DUAL
MR221035005009 FERRITE BEAD 3.5X9-237-T
MR221045030014 FERRITE BEAD 4.5x3x1.4mm (10T)
MR225162050186 SHAFT VOLUME A50K R1615G13A1-A
MR231822150159 FUSE 1.5A/125V 20S
MR233021200020 HEADER 2 PINS "JST" 2.0mm R
MR233031200020 HEADER 3 PINS "JST" 2.0mm R
MR233040200025 HEADER 4 PINS "JST" 2.5mm V
MR233101200012 HEADER 10 PINS "JST" 2.0mm R
MR240003528902 ST. PHONE JACK/CK-35-28A
MR240035200902 STEREO EARPHONE JACK MSJ2000
MR244052205180 HSG 5 PINS "JST" 2.5mm 180mm
MR244052205250 HSG 5PINS "JST" 2.5mm 250mm
MR244052600300 HSG 5PINS "JST" 2.0 PITCH
MR244A05260250 HSG 5PINS "JST" 2.0mm #26
MR248D59502147 P.C.B MCD-DV595 AUDIO BD.
MR302231038250 SMT C. CAP 0.01 UF/50V +80% -2
MR408410220040 HEAT SINK 41x22x0.4 mm
TAPE PWB ASSY
REF
PART NO.
NO.
84 MRD59513800-08 ASSY PWB TAPE
MR004254752250 ELECT CAP 4.7 UF/50V +-20%
MR004161062216 ELECT CAP 10 UF/16V +-20%
MR004171072210 ELECT CAP 100 UF/10V +-20%
MR004172272210 ELECT CAP 220 UF/10V +-20%
MR005021021199 MYLAR CAP 0.001 UF/100V +-10%
MR005022221199 MYLAR CAP 0.0022 UF/100V +-10
MR005023321199 MYLAR CAP 0.0033 UF/100V +-10%
MR005031031199 MYLAR CAP 0.01 UF/100V +-10%
MR005032231199 MYLAR CAP 0.022 UF/100V +-10%
MR005033331199 MYLAR CAP 0.033 UF/100V +-10
MR203081010202 ELECT CAP 1000 UF/10V +-20%
MR207008050030 TRANSISTOR 8050C/D ALL MODEL
MR209223630010 I.F.T. AC BIAS 3630 BLACK 10mm
MR210003308100 I.C. BA-3308 P/R HWCAT
MR218662205097 RECORDING SW. PS-62D01-S(SH)
MR226110000000 INDUCTOR 100uH RL4055-101K
MR233021200020 HEADER 2 PINS "JST" 2.0mm R
MR234350803300 HSG 3 PINS "JST" 2.0mm UL1007
MR234570804150 HSG 4 PINS"JST"2.0mm 150mm
MR237260120028 JUMPER WIRE #26 120mm BROWN
MR244032050022 HSG 1 PINS 22# BLK L=50mm
DESCRIPTION
- 0 -
1 SW501
1 SW301
1 L610
6 L301,L302,L303,L606,L607,L608
1 VR301
1 FS401
1 CN401
1 CN404
1 CN301
1 CN502
1 JK601
1 JK301
1 AUDIO CN403 TO REC.CN1101
1 AUDIO CN402 TO DVD J1
1 AUDIO CN503 TO TUNER CN101
1 AUDIO CN505 TO DVD J2
1
4 C323-C326
1 FOR IC301
QTY
REMARK
1
2 C204,C207
2 C205,C220
2 C203,C206
1 C805
2 C202,C212
4 C201,C208,C209,C211
1 C803
1 C806
1 C804
2 C210,C213
1 C215
1 Q802
1 T801
1 IC201
1 SW201
1 MOTOR(+) TO MOTOR(-)L401
1 CN203
1
TAPE CN404 TO CASS DECK MOTOR
1 TAPE CN201 TO CASS DECK HEAD
1 MOTOR(+) TO LEAF SW.
1 CASS DECK
