PORTABLE CAR CANOPY
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
please call 1-888-866-5797 as soon as possible.
©
©
Copyright
2015 by Harbor Freight Tools
Copyright
2015 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Keep this manual for the safety warnings and precautions, assembly, operating,
Vehicle not included.
Visit our website at: http://www.harborfreight.com
®
®
. All rights reserved.
. All rights reserved.
10 FT. x 20 FT.
Read this material before using this product.
Read this material before using this product.
Failure to do so can result in serious injury.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
SAVE THIS MANUAL.
REV 15i
ITEM 62858
Advertisement
Related Manuals for Harbor Freight Tools 62858
Summary of Contents for Harbor Freight Tools 62858
- Page 1 Failure to do so can result in serious injury. Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. any shape or form without the express written consent of Harbor Freight Tools.
-
Page 2: Table Of Contents
Addresses practices not related to personal injury. WARNING marking concerning Risk Double Insulated of Eye Injury. Wear ANSI-approved safety goggles with side shields. Canadian Standards Association Read the manual before set-up and/or use. Underwriters Laboratories, Inc. Page 2 For technical questions, please call 1-888-866-5797. Item 62858... -
Page 3: Specifications
4. This product is not a toy. Do not allow 7. Maintain product labels and nameplates. children to play with or near this item. These carry important safety information. If unreadable or missing, contact Harbor Freight Tools for a replacement. SAVE THESE INSTRUCTIONS. Specifications Center Height 9′ 6″... -
Page 4: Assembly
Connect 4x Swaged Tubes (2), 2x Straight Cross Tubes (4), 2x 3-Way Connectors (5), and 1x 4-Way Connector (6) together, then attach that assembly to the ends of the Rafter Tubes (3). Page 4 For technical questions, please call 1-888-866-5797. Item 62858... - Page 5 Note: The warning label is on one of the Straight Tubes (1). Turn that Tube so that the Warning label can be read easily. Attach a Swaged Tube (2) to the bottom of each Straight Tube. Item 62858 For technical questions, please call 1-888-866-5797. Page 5...
- Page 6 7. Place a Foot Plate (8) over the bottom of each Swaged Tube (2). Use two Base Fastening Stakes (7) through each Foot Plate to anchor the Canopy. Note: Verify that there are no utility lines nearby before driving anchors. Page 6 For technical questions, please call 1-888-866-5797. Item 62858...
- Page 7 Tie a Rope (13) around the 3-Way Connector (5) at each corner of the Canopy, then attach it to the Stake (12). Note: Verify that there are no utility lines nearby before driving anchors. Item 62858 For technical questions, please call 1-888-866-5797.
-
Page 8: Maintenance
• loose ratchet tie downs, anchors, tube connections, and rail clamps (tighten as needed), • torn or frayed covers, ropes, or cables, • cracked, bent, or broken parts, and • any other condition that may affect its safe operation. Page 8 For technical questions, please call 1-888-866-5797. Item 62858... - Page 9 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 62858 For technical questions, please call 1-888-866-5797. Page 9...
-
Page 10: Parts List And Diagram
24″ Rafter Tube 40 5/8″ Straight Cross Tube 3-Way Connector 4-Way Connector Base Fastening Stake Foot Plate Roof Tarp Ball Tie-down Tarp Corner Rope and Hook Rope Fastening Stake Rope Page 10 For technical questions, please call 1-888-866-5797. Item 62858... -
Page 11: Item
Assembly Diagram Item 62858 For technical questions, please call 1-888-866-5797. Page 11... -
Page 12: Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
