Page 1: User Guide
BACnet Gateway (435) User Guide Doc. No.: D007501, issue 1 2017-03-30... - Page 2 Copyright © 2017 Helvar Ltd. All rights reserved. No part of this document may be reproduced in any form or by any means – graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems – without the written permission of the publisher.
-
Page 3: Table Of Contents
1.3.2. BACnet/IP network ..........................5 2. CONFIGURATION ..........................6 2.1. CONFIGURATION PAGES ......................6 2.2. CONNECT TO THE 435 BACNET GATEWAY ................7 2.3. CONFIGURE THE COMMS INTERFACE ..................7 2.3.1. Configure the IP config settings ......................8 2.3.2. Configure the comms settings ......................9 2.4. -
Page 5: Introduction
Introduction The 435 BACnet Gateway provides a simple interface to a Helvar router system and allows lighting system data to appear in a BACnet Building energy Management System (BeMS). Note: Typically, individual systems (energy control, lighting, boiler and air-conditioning systems, etc.) are measured separately for CO accountability. -
Page 6: Device Limits And Compatibility
The 435 BACnet Gateway has been specifically designed to expose the ‘router’, ‘group’ and ‘device’ parameters from Helvar routers in a designated workgroup through the TCP/IP network. The BACnet/IP BMS can use this information to control and monitor the lighting, energy and environmental conditions. -
Page 7: Front Panel Leds
Activity LED switches. The bank of DIP switches is not functional in this version. While the reset button does not erase any configuration, we recommend that you use it only if the software reboot fails. Helvar 435 BACnet Gateway: User Guide... -
Page 8: System Overview
The BACnet Gateway provides direct interface between Helvar routers, including the devices connected to them (such as ballasts, LED drivers, luminaires and sensors), and a BACnet/IP BMS. Thus, the BACnet/IP BeMS can access the values recorded in the Helvar 905, 910 and 920 routers and in the DALI devices. -
Page 9: Helvar Devices And Dali Networks
1.3.1. Helvar devices and DALI networks The Helvar 905, 910 and 920 routers use the Ethernet connection as a network backbone to combine DALI, SDIM and DMX networks. The DALI and SDIM networks appear as Helvar router subnets in the 435 browser interface. -
Page 10: Configuration
Admin: To configure the login security (password) of the unit, the firmware version and the • documentation. Map points: To link and assign the required Helvar router points detected by the unit, to a • predetermined ‘object type’ in this BACnet device. -
Page 11: Connect To The 435 Bacnet Gateway
2.2. Connect to the 435 BACnet Gateway Installation Leaflet After the BACnet Gateway has been correctly installed (see the supplied with Installation Guide each unit or the ), you need to configure the communication protocols and the required parameters. Each unit is supplied with a default IP address that identifies the unit on the IP network. You must replace this IP address with a unique IP address as required by the applicable local network policy. -
Page 12: Configure The Ip Config Settings
Use the Helvar search tool provided (available from the Homepage > Support page) to Note: detect the 435 Gateway(s) on the IP network. You can also use a BACnet Explorer to detect the unit on the BACnet/IP network. (LAN 1) Subnet 1 = IP address (LAN 2) Subnet 2 = IP address 10.254.1.2 to 10.254.1.63... -
Page 13: Configure The Comms Settings
(Ctrl+Shift+Del and the top four options enabled as a minimum) before login. 2.3.2. Configure the comms settings The comms settings allow you to configure the unit as a gateway from the Helvar routers using the Helvar proprietary communications protocol to the BACnet/IP network. Press... -
Page 14: Configure The Map Points
Last poll duration value. This value shows the number of seconds that it has taken to poll all the configured Helvar routers. Configure the BACnet device settings. These settings define the connection details for the unit to appear as a BACnet device on the BACnet/IP based control system. -
Page 15: Discover And Select Workgroups And Devices
Message area 2.4.1. Discover and select workgroups and devices Deselection Discovered and message workgroups When you first install 435 BACnet Gateway devices, you area must assign the following: An existing Helvar workgroup for Helvar routers • and Helvar routers subnet devices. -
Page 16: Configure The Mapping To Bacnet Object Types
Discover selected workgroup. If necessary, press Discover changes to detect changes to the selected workgroup. Press Select routers to show all Helvar routers in the selected workgroup. Select the routers with parameters that require mapping to the BACnet BMS. The maximum number that you can select is 20. - Page 17 Check the default BACnet configuration applied. To add subnet device parameters: Expand the applicable router subnet, select the required device, and then press to display the points that can be mapped to BACnet object types. Helvar 435 BACnet Gateway: User Guide...
-
Page 18: Edit The Bacnet Table
2.4.3. Edit the BACnet table The BACnet table allows you to view and edit the mapping configuration of the group, the Helvar router and the Helvar router subnet device parameters to the BACnet object instances. Each BACnet object instance includes a default set of properties that are displayed in the BACnet Explorer. - Page 19 Address/Number: Group number, Helvar router IP Address or Helvar router IP Address and subnet device address. Property: Parameter label. Object type: AV (analogue value – read/write), AO (analogue output – write only), AI (analogue input – read only) or BI (binary input– read only).
-
Page 20: Backup And Restore Settings
The Back up and Restore page provides functions that allows you to manage the configuration in the 435 BACnet Gateway. The functions generate a file that replicates the configuration contained in the unit. You can then use this file to restore the unit to an earlier state without losing data. The... -
Page 21: Restore: Backup Configuration Or Change Device Firmware
When first installed, the configuration pages are protected by a user name and a default password Installation Guide (see the ). You must type them before you can access the configuration of the device. After the device has been installed, change the default password to prevent unauthorised access. Helvar 435 BACnet Gateway: User Guide... - Page 22 Tip: A random combination of numbers and uppercase and lowercase letters provide a secure password setup. Press Save to apply the changes and return to the Login page. Helvar | Data is subject to change without notice.
-
Page 23: Order Codes
Order codes ORDER CODES DESCRIPTION BACnet Gateway AMR1 PSU 24 VDC 1 A power supply 435+AMR1 PSU Combined above 2 items sold as a pack Helvar 435 BACnet Gateway: User Guide... -
Page 24: Protocol Implementation Conformance (Pic) Statement
Protocol Implementation Conformance (PIC) Statement Helvar’s 435 BACnet Gateway is an OEM product from Synapsys Solutions Ltd and is a variant of the Synapsys SIP. The following Protocol Implementation Conformance (PIC) statement gives the full compliance by Synapsys for all variants of the SIP gateway. -
Page 25: Annex A - Protocol Implementation Conformance Statement (Normative)
BACnet Advanced Operator Workstation (B-AWS) BACnet Operator Display (B-OD) BACnet Building Controller (B-BC) BACnet Advanced Application Controller (B-AAC) BACnet Application Specific Controller (B-ASC) BACnet Smart Sensor (B-SS) BACnet Smart Actuator (B-SA) Helvar 435 BACnet Gateway: User Guide... - Page 26 Dynamically deletable: No Optional properties: Description, Reliability, COV_Increment Writable properties: Present_Value and Reliability when Out_Of_Service is TRUE, Out_Of_Service (These are saved in volatile memory; changes are lost after reboot) Conditionally writable properties: – Helvar | Data is subject to change without notice.
- Page 27 Writable properties: Present_Value, Reliability when Out_Of_Service is TRUE, Out_Of_Service (These are saved in volatile memory; changes are lost after reboot) – Conditionally writable properties: – Proprietary properties: – Property range restrictions: BINARY_INPUT Dynamically creatable: No Dynamically deletable: No Optional properties: Description, Reliability Helvar 435 BACnet Gateway: User Guide...
- Page 28 Writable properties: Present_Value, Reliability when Out_Of_Service is TRUE, Out_Of_Service (These are saved in volatile memory; changes are lost after reboot) – Conditionally writable properties: – Proprietary properties: – Property range restrictions: MULTISTATE_INPUT Dynamically creatable: No Helvar | Data is subject to change without notice.
- Page 29 Writable properties: Present_Value, Reliability when Out_Of_Service is TRUE, Out_Of_Service (These are saved in volatile memory; changes are lost after reboot) Conditionally writable properties: – Proprietary properties: – Property range restrictions: Max. 128 states, each state max. 19 characters Data Link Layer Options: Helvar 435 BACnet Gateway: User Guide...
- Page 30 Does the BBMD support network address translation? Network Security Options: Non-secure Device – capable of operating without BACnet Network Security Secure Device - is capable of using BACnet Network Security (NS-SD BIBB) Helvar | Data is subject to change without notice.
- Page 31 If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the gate-way supports: This product is a gateway. It typically exposes modbus, mbus but also other building protocols to BACnet IP. The non-BACnet equipment depends on product model. Helvar 435 BACnet Gateway: User Guide...
