EN / CZone Touch 5 User & Installation Manual Copyright This document is copyright 2016 under the Creative Commons agreement. Rights are granted to research and reproduce elements of this document for non-commercial purposes on the condition that BEP Marine is credited as the source. Electronic re-distribution of the document in any format is restricted, to maintain quality and version control.
EN / CZone Touch 5 User & Installation Manual Table of Contents GENERAL INFORMATION ......................5 Description ..........................5 Overview ..........................5 1.2.1 Front Controls ........................5 1.2.2 Rear Connections......................5 1.2.3 In The Box ........................6 1.2.4 Card Reader ........................6 INSTALLATION ..........................
Page 4
EC DECLARATION OF CONFORMITY ..................28 Table of Figures Figure 1. Battery & Power Connections ....................7 Figure 2. Touch 5's Tab based Main Menu ................... 11 Figure 3. Home-page for the Monitoring Functional Group ..............11 Figure 4. Modes Configuration Example ....................13 Figure 5.
1 General Information Description The CZone Touch 5 is a 5” colour touch-screen, which operates as a Display Interface on any new or existing CZone network. It is designed for a wide range of applications, and can withstand the harsh marine and recreational vehicle environments.
EN / CZone Touch 5 User & Installation Manual 1.2.3 In The Box 1. Touch 5 2. Sun Cover 3. Panel mount gasket 4. Power/NMEA cable 5. Panel mount screws 1.2.4 Card Reader Used for attaching a microSD memory card. The memory card can be used for software updates. The card reader door is opened by pulling the rubber cover open.
EN / CZone Touch 5 User & Installation Manual 2 Installation Mounting Location Choose the mounting locations carefully before you drill or cut. The unit should be mounted so that the operator can easily use the controls and clearly see the screen. Be sure to leave a direct path for all of the cables.
EN / CZone Touch 5 User & Installation Manual 5. 12 V DC supply 6. NMEA 2000 cable and connector Connect Red to (+) DC using a 3 amp fuse. Connect Black to (-) DC. Power Control Connection The yellow Power Control wire in the power cable is an input that will turn on the unit when power is applied.
3 Getting Started First Power Up If connecting Touch 5 to an existing CZone network, ensure the display has been added to the CZone configuration file and assigned a dipswitch. Every CZone device on a network requires a unique dipswitch to operate correctly, and the Touch 5 has a virtual dipswitch. Refer to the CZone Configuration Tool manual for this process.
Page 10
5. Once dipswitch has been set the Modes page from the configured system will appear. 6. To ensure network connections are good and that the display can see the rest of the CZone devices go to the Settings > Network page and check configured modules are showing ‘Online’.
4. Settings - set CZone parameters, rather than other on-board equipment. This includes units of measurement, backlight settings, time zones, etc. Touch 5 offers a tab-based main menu, with a “home tab” for each of the above functional groups. (The menu is shown in Figure 2. Touch 5's Tab based Main Menu It is displayed along the bottom of the screen at all times except when a keypad is shown.)
EN / CZone Touch 5 User & Installation Manual Display panel. (This remains blank unless used by the current function) Sub-categories available for further selection. (In this example, clicking the Accept button will drill down further into the highlighted Favourites sub-category.) Tab-based main menu.
EN / CZone Touch 5 User & Installation Manual Modes are configured by the builder using the CZone Configuration Tool. Only one mode from a ‘mode group’ can be selected at a time; most systems have only one mode group.
The main menu’s Control tab accesses all configured circuits on the CZone network. Click Control on the main menu along the bottom of the screen Depending on which CZone modules are on the network, you may have one or more of the following four circuit types: ...
EN / CZone Touch 5 User & Installation Manual 4.2.2.1 DC Control and AC Control Circuits All DC Control and AC Control circuits behave in a similar way. An example is shown below: Click on the circuit you wish to control.
The main menu’s Monitoring tab accesses all configured metering on the CZone network. Click Monitoring on the main menu along the bottom of the screen Depending on which CZone modules are on the vessel, you may have one or more of the following five monitoring types: ...
Page 17
EN / CZone Touch 5 User & Installation Manual Click on the DC device that you wish to monitor. Highlighting shifts to the selected device and the display pane tracks its status An analogue gauge is mimicked to show the current draw...
EN / CZone Touch 5 User & Installation Manual 4.2.3.2 AC Monitoring All AC Monitoring meters behave in the same way. An example is shown below: Click to highlight the AC source that you wish to monitor. (In this example, only the...
EN / CZone Touch 5 User & Installation Manual 4.2.3.3 Tanks All Tank monitoring meters behave in the same way. An example is shown below: Click on the tank that you wish to monitor. (In this example, only the Fresh Water Tank is configured.) The selected tank is highlighted...
Alarms of a Selected Severity Click on the severity level that you wish to monitor (Severity levels are matched to coloured ‘bell’ icons on the right). Below is a list of the different CZone alarm severities and their behaviour: Alarm Bell Action on...
Page 21
EN / CZone Touch 5 User & Installation Manual Click the Acknowledge button to disable an alarm if its state is Enabled (Its entry will remain in the Alarm History). A list of active alarms appears, all with the selected severity level. More-recent alarms are listed first.
EN / CZone Touch 5 User & Installation Manual 4.2.3.4.2 Alarm History Selecting Alarm History from the Monitoring > Alarms page displays the most recent alarms (up to 100). Alarms are listed according to when they were raised, with the most recent first. Alarm history includes all alarms above Warning severity by default.
Updating Software via microSD 1. Copy the Touch 5 firmware file (extension .upd) on the root directory of a microSD card. 2. Insert the microSD card in the card reader slot of the Touch 5 (refer to chapter 1.2.4 for process).
EN / CZone Touch 5 User & Installation Manual Wireless Interface Setup To configure the Wireless Interface on the Touch 5 go to Settings > System > Server > Configure Select the Server Mode (Access Point, Client Mode or Disabled), then press the right arrow (refer to the Wireless Interface Setup Instructions for a definition of these server modes).
Connecting iPad to Touch 5 Follow the below steps to connect an iPad to the Touch 5 via WiFi. Before proceeding a WI package must be present on the Touch 5’s CZone server, this package contains the custom favourite page settings and images.
EN / CZone Touch 5 User & Installation Manual 7. The Wireless package will start downloading 8. Once the download is complete you will see the favourites page of the configured system. Figure 8. CZone iPad App Favourites Page Example...
EN / CZone Touch 5 User & Installation Manual 6 EC DECLARATION OF CONFORMITY Power Products LLC Mailing Address: BEP Marine LTD PO Box 101-739 NSMC Auckland 0632, New Zealand Street Address: 42 Apollo Drive Rosedale, Auckland, 0632, New Zealand Declare under our sole responsibility that the following product to which this declaration relates is in conformity with the requirements of EU directive 1999/5/EC R&TTE (Radio and Telecommunications...
