VRS SCH-200 Imaging Unit
2 Megapixel Network Box Camera Series
Quick Installation Guide
Version 1.0
June 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VRS SCH-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for HTS VRS SCH-200

  • Page 1 VRS SCH-200 Imaging Unit 2 Megapixel Network Box Camera Series Quick Installation Guide Version 1.0 June 2013...
  • Page 2: Table Of Contents

    SCH-200 Imaging Unit Series│ Quick Installation Guide Table of Contents CHAPTER 1 SAFETY AND CERTIFICATIONS ............3 Safety Instructions ..................3 Disposal of Equipment ..................4 FCC Compliance Statement ................5 CE Statement ....................5 CHAPTER 2 PRODUCT DESCRIPTION ..............6 Overview ......................6 Specifications ....................6 CHAPTER 3 INSTALLATION PREPARATION ............
  • Page 3: Chapter 1 Safety And Certifications

    SCH-200 Imaging Unit Series│ Quick Installation Guide Chapter 1 Safety and Certifications NOTICE Please read this guide thoroughly and save it for future use before attempting to connect or operate this unit. Safety Instructions HAZARD: Please follow the safety instructions below. Failure to adhere to the instructions could result in personal injury to the user.
  • Page 4: Disposal Of Equipment

    SCH-200 Imaging Unit Series│ Quick Installation Guide Disposal of Equipment WEEE (Waste Electrical and Electronic Equipment). Correct disposal of this product (applicable in the European Union and other European countries with separate collection systems). This product should be disposed of, at the end of its useful life, as per applicable local laws, regulations, and procedures.
  • Page 5: Fcc Compliance Statement

    SCH-200 Imaging Unit Series│ Quick Installation Guide FCC Compliance Statement Information to the user: This unit has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15B of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 6: Chapter 2 Product Description

    SCH-200 Imaging Unit Series│ Quick Installation Guide Chapter 2 Product Description Overview The SCH-200 is a state-of-the-art, 2 megapixel imaging unit. It is supplied with the following interfaces:  2 shielded copper pairs:  One pair for powering  One pair for synchronizing with an external illumination unit ...
  • Page 7 SCH-200 Imaging Unit Series│ Quick Installation Guide Weight 3280 grams (including mounting bracket) Casing Die-Cast Aluminum Alloy Protection Level IP66 Operating Temperature Range -10⁰C to +50⁰ C Adjustment Angles 3 (up/down, right/left, rotation) Mounting bracket Full cable management Electrical 24 VDC, 2 amperes Heating Contains heater with thermostat control Illumination...
  • Page 8: Chapter 3 Installation Preparation

    The protective materials used for the packaging should be able to protect the unit from most forms of damage during transportation. NOTE Please contact HTS if the item or any of its accessories is damaged. Page 8...
  • Page 9: Wall Mount Bracket

    SCH-200 Imaging Unit Series│ Quick Installation Guide Wall Mount Bracket The wall mount bracket supplied with the SCH-200 is depicted in Figure 1 below. Figure 1: Bracket Drawing and Dimensions Pole Mount Adaptor The pole mount bracket is not supplied with the SCH-200. It is optional to order the adaptor for Pole mounting.
  • Page 10: Chapter 4 Installation

    SCH-200 Imaging Unit Series│ Quick Installation Guide Chapter 4 Installation Installation Tools The following tools may be necessary to complete the installation:  Electric drill  Screwdrivers  Wire cutters  Set of hex keys (Allen wrenches) Mounting the SCH-200 on a Wall Mount the imaging unit on a wall or ceiling using the bracket as illustrated in Figure 3 below.
  • Page 11 SCH-200 Imaging Unit Series│ Quick Installation Guide Adjust the position and angle of the imaging unit as shown in Figure 4 below. Figure 4: Adjusting the Imaging Unit NOTE Depending on the mounting surface’s material, different screws and anchors than those supplied may be required.
  • Page 12: Mounting The Sch-200 On A Pole

    SCH-200 Imaging Unit Series│ Quick Installation Guide Mounting the SCH-200 on a Pole Attach the pole adapter to the pole using one of the straps. Tighten the strap (see Figure 2 above). Connect the bracket base of SCH-200 to the pole adapter board. Use the three screws and nuts provided in the BR-20 pole adapter kit.
  • Page 13: Connecting The External Wiring

    SCH-200 Imaging Unit Series│ Quick Installation Guide Connecting the External Wiring HAZARD: All imaging unit installations should comply with your local electrical safety rules. The SCH-200 Imaging Unit is supplied with two 1-meter long cables:  CAT-6 Ethernet cable with RJ-45 female to female connector ...
  • Page 14 SCH-200 Imaging Unit Series│ Quick Installation Guide  To connect the external wiring: Connect the powering pair (red/black) to 24 VDC power supply. If required, connect the synchronization pair (green/white) to the external illumination source. Connect RJ-45 male connector of the imaging unit to the Lane Controller by using of female to female RJ-45 network interface connector.
  • Page 15: Network Topology

    SCH-200 Imaging Unit Series│ Quick Installation Guide Network Topology The SCH-200 Imaging Unit delivers video images in real time over the Internet and your Intranet. Using its Ethernet RJ-45 network interface, it connects to a Lane Controller (LC-2000 or similar). ...
  • Page 16: Chapter 5 Ip Configuration

    Figure 9: IP Configurator Icon 5.2.2 Running IP Configurator on the Internet The IP Configurator utility is available on the HTS web site, at: http://htsol.com/Support Log in to the support portal, and select Download >> Tools and Utilities >> IP Configurator Utility.
  • Page 17: Setting A New Ip Address

    SCH-200 Imaging Unit Series│ Quick Installation Guide Setting a New IP Address  To set a new IP address: Make sure the Imaging Unit and your Lane Controller are in the same subnet. Connect the SCH-200’s Ethernet connector directly to the Lane Controller, or via a switch.
  • Page 18 SCH-200 Imaging Unit Series│ Quick Installation Guide Login to the configurator with the default username and password:  Username: admin  Password: 1234 Press the discover button. The window displays a list of units currently in operation on the network, as depicted in Figure 11 below.
  • Page 19 SCH-200 Imaging Unit Series│ Quick Installation Guide Select the unit with the Imaging Unit model SCH-200. The following Information appears in the camera configuration window. Figure 12: Configuring a New IP Address Enter the new IP address in the field designated in Figure 12 above. Click Save to activate the settings.
