Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted.
Part
Cost
Quantity Total Cost
Crotch Strap/Buckle $4.99 X ____ = $ ____________
Harness Strap ............ $2.00 X ____ = $ ____________
Pad Set ...................... $42.00 X ____ = $ ____________
Chest Clip .................. $1.50 X ____ = $ ____________
Locking Clip ............... $2.50 X ____ = $ ____________
Tether Kit .................. $9.99 X ____ = $ ____________
... $17.99 X ____ = $ ____________
Lower Anchor Kit
Instructions ................ $0.00 X ____ = $ ____________
Merchandise Total
Shipping and handling:
Up to $25.00 ......................$5.95
$25.01 to $50.00 ................$6.95
$50.01 to $75.00 ................$8.95
$75.01 to $100.00 .............$9.95
$100.01 to $150.00 ...........$10.95
Sales Tax
(Indiana, California, Arkansas, and Massachusetts residents add applicable
sales tax.)
Grand Total
No shipping and handling on instructions for quantities under 6. Add $.50 for
each instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
q Visa
qMastercard
Card Exp. Date: _____________________________
Cardholder's Name: _________________________
Card Number: _______________________________
Signature ___________________________________
56
$ _____________
$ ___________
$150.01 to $200.00 ...........$11.95
$200.01 and up ..................$13.95
Outside Continental USA $10.00
$ _____________
$ ____________
Alpha Omega
All in One
Instruction Manual
www.djgusa.com
Read all instructions BEFORE USING
this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
WARNING
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
4358-7075
rear-facing child
restraint
5-35 lbs (2.3-16 kg)
19-36 in. (48-91 cm)
forward-facing child
restraint
22-50 lbs (10.1-22.6 kg)
29-45 in. (73.6-114.3cm)
and at least 1 Year Old
belt-positioning booster
40-80 lbs (18.1-36.3 kg)
43-52 in. (110.1-132.1
cm) and at least 4 years
Old

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alpha Omega and is the answer not in the manual?

Questions and answers

Related Manuals for Djgusa Alpha Omega

Summary of Contents for Djgusa Alpha Omega

  • Page 1 Replacement Parts List 4358-7075 NOTE: If requested color is not available, similar color will be substituted. Alpha Omega Part Cost Quantity Total Cost Crotch Strap/Buckle $4.99 X ____ = $ ____________ All in One Harness Strap .... $2.00 X ____ = $ ____________ Pad Set ......

  • Page 2: Table Of Contents

    Department at: Securing Your Child in Child Restraint ........10 Dorel Juvenile Group, Inc. Removing Child from Child Restraint ........12 Website: www.djgusa.com Reclining the Child Restraint ............13 Mailing Address: Dorel Juvenile Group, Inc. Attn: Consumer Care P.O. Box 2609 Choosing Lower Anchor Belt or Vehicle Belts ......

  • Page 3: Warnings

    WARNING Rear-Facing Use................21 Rear-Facing Installation ..............22 Never place a child rear-facing in a seating position with an active Vehicle Belt ................23 frontal airbag. Lower Anchor Belt ............... 28 Check the vehicle owner’s manual for more information about air bag/child restraint use. Forward-Facing Use ..............

  • Page 4: General And Warm Weather Use

    Do not use any car seat accessory except Attn: Consumer Care those approved by Dorel Juvenile Group. or register online at www.djgusa.com/registration/ Never allow any child to play with this child carseat/us or call 1-800-544-1108 restraint; it is not a toy.

  • Page 5: Child Restraint Parts

    Child Restraint Parts Front Back Buckle Harness/Headrest Adjuster Harness Release Top Anchorage Cup Holder Pillow Lever (Tether) Strap & (on select models) (under flap) (on select models) Hook Shoulder Belt Level To Ground Recline Lever Splitter Plate Positioning Guide Lines Harness Adjustable Instructions...

  • Page 6: Preparing Child Restraint To Fit Your Child

    Preparing Child Restraint to Fit Choosing Restraint and Position Your Child Your child’s height, weight, and age determine how your child You MUST make these adjustments with your child restraint should be placed in the vehicle. before you install the child restraint in the vehicle. Children up to 1 year of age must ride rear facing.

  • Page 7: Check Harness/Headrest Height

    Check Harness/Headrest Height Accessories (on select models) Rear-Facing Position: Harness guide must be Harness Infant Pillow (on select or slightly below Guide models): shoulders. The pillow provides extra If the harness guide is comfort for your child. above the child’s shoulders To remove the pillow, with the headrest in the from the back of the...

  • Page 8: Securing Your Child In Child Restraint

    Position the chest clip at mid- Securing Your Child in the Child chest (even with armpits), away from the child’s neck. Restraint Position harness straps over the child’s shoulders. Try to pinch the harness at the shoulders. If you can pinch the harness strap, tighten more.

  • Page 9: Reclining The Child Restraint

    Removing Your Child from the Reclining the Child Restraint Child Restraint This child restraint has 3 Loosen harness by pushing positions: down on the harness Rear-facing - Fully release lever that is under Recline. For children 5-22 the flap while pulling out lbs (2.3-10 kg), recline on the harness.

  • Page 10: Choosing Lower Anchor Belt Or Vehicle Belts

    Choosing Lower Anchor Belt or Vehicle Belts Your vehicle’s features may be considerably different than Your vehicle’s features may be considerably different than those pictured here. those pictured here. Lower Anchor Bars Seat Bight The LATCH System Vehicle Belts The lower anchors of LATCH (Lower Anchors and Tethers for CHildren) If lower anchors are not an option, you must use the vehicle seat is a universal system for installing child restraints without using vehicle belt system to install the child restraint.

  • Page 11: Knowing Your Vehicle Belts

    Knowing Your Vehicle Belts Types of Retractors Not all vehicle belts and seating positions will work with child restraints. Please follow the following steps to under- Switchable Retractor stand how to lock a child restraint with a vehicle belt. (most vehicles have this type) You MUST Review Your This retractor can be switched to a locking mode.

  • Page 12: Locking Clip

    Locking Clip Check the Latch Plates You will rarely need to use a locking clip except in some older Latch plates are the part of vehicles. Built in child restraint locking systems have been the seat belt that goes into the required in vehicles since 1996, and many vehicles had these features even earlier.

  • Page 13: Rear-Facing Use

    Thread both vehicle lap and shoulder belts through Rear-Facing Use the slot (as shown) and out other side. Buckle. Pull up on shoulder belt until all slack is out and lap belt is tight. Grasp both vehicle belts together just behind the buckle plate and unbuckle.

  • Page 14: Rear-Facing Installation

    Rear-Facing Installation Rear-Facing Installation with Vehicle Belt: After deciding whether to use your vehicle belts or lower anchor belt, be sure to read the warnings below With child restraint as they pertain to both systems. in the most reclined When lower anchor is not position, place child available, fasten belt hooks restraint rear-facing in...
  • Page 15 NOTE: In some cases, you may Check if your vehicle belts will need to pull the pad off the front work with this child restraint corner and expose the belt path. This is very important because Tighten belt through belt path all vehicle belts will work with child slot.

  • Page 16: Lower Anchor Belt

    Push lower anchor hook Rear-Facing Installation with through the rear-facing Lower Anchor: Install Lower Anchor belt path slot. Belt Do not use the lower anchor belt along with the adult lap or lap/ shoulder belt. To thread lower anchor belt: Pull other end of lower anchor hook between Pull the seat pad off the...
  • Page 17 For children 22-35 lbs (10.1- Rear-Facing Installation with 16 kg) and can sit up unassisted, Lower Anchor: Install in Vehicle rotate the child restraint between the 2 level to ground lines. Start by making the bottom level to ground line level, then WARNINGS: Do not use the lower anchor belt rotate seat up.

  • Page 18: Forward-Facing Use

    With weakest hand at belt Forward-Facing Use path, tilt and push the child restraint from side to side. Refer to the “Choosing Restraint and Position” section to make sure your child is at the proper weight and It should not move more than 1 height to face forward.
  • Page 19 Forward-Facing Installation Forward-Facing Installation with Vehicle Belts: After deciding whether to use your vehicle belts or lower anchor belt, be sure to read the warning below as Check if your vehicle they pertain to both systems. belts will work with this child restraint When lower anchor belt is This is very important because...
  • Page 20 Attach hook to anchor Forward-Facing Installation with in vehicle. Push down Lower Anchor Belt: Install Lower firmly and tighten top Anchor Belts anchorage strap. To adjust top anchorage WARNING strap: See “Adjusting Top Anchorage Strap” section. Do not use the lower anchors of the child restraint NOTE: If your vehicle does not have an anchor anchorage system (LATCH system) to attach this child...
  • Page 21 With weakest hand at Place child restraint flush belt path, tilt and push against the back of the the child restraint from vehicle seat forward- side to side. facing in the back seat. The semi-recline position It should not move more is to be used only to than 1 in.

  • Page 22: Adjusting The Tether Strap

    Storing Tether Strap Adjusting the Top Anchorage Strap When installing rear facing, using as a booster, or when not in use, the top anchorage strap and hook MUST always attach, adjust, and secure the top should be attached to the bottom anchorage (tether) strap when installing the child restraint of the base as shown.

  • Page 23: Belt-Positioning Booster Use

    Belt-Positioning Booster Use Removal of Harness Refer to the “Choosing Harness must be removed for use as a Restraint and Position” belt-positioning booster. section to make sure your child is at the proper From the back of the weight and height to seat, unfasten harness use the belt-positioning straps from splitter plate.

  • Page 24: Belt-Positioning Booster Installation

    Fully recline the child Belt-Positioning Booster restaint. Reach under the seat between base and Installation shell. Locate the buckle’s metal retainer. The top anchorage strap and hook is not used for belt-positioning booster use. Attach the tether hook to the bottom of the base as shown.
  • Page 25 WARNING The lap belt should lay snugly across the child’s For vehicles with an air bag, but without upper thighs and not on the a back seat, refer to your vehicle owner’s stomach. manual. The shoulder belt should Do Not Use only the lay snugly across the center lap belt when using this of the child’s shoulder and...

  • Page 26: Reinstall Harness

    With the sewn end of the Reinstall Harness harness strap facing the buckle, thread the harness Fit the buckle strap down through the slot on down through the slot the left side of shell. in the seat. Make sure buckle faces out. From the bottom of seat, pull buckle’s metal clip completely through pad...

  • Page 27: Removing Seat Pad For Cleaning

    From the back, pull Removing Seat Pad for Cleaning harness through the back. Make sure the harness Remove harness as described in the “Belt-Positioning goes OVER the metal Booster” section. bar. WARNING Do not use this child restraint without the seat pad.
  • Page 28 Depending on your model, Push harness guide lip to remove the headrest toward outside of shell pad, pull pad off of the with one hand while pulling headrest tab located by harness guide from the the harness/headrest front with the other. adjuster, then pull pad off of headrest.

  • Page 29: Troubleshooting

    Troubleshooting Warranty Dorel Juvenile Group, Inc. (DJG) warrants this product to the original retail purchaser as follows: Locate a Child Safety Seat Inspection Station for hands on This product is warranted against defective materials or training on how to use your child restraint: Visit your local Child workmanship for one year from the date of original purchase.

  • Page 30: Replacement Parts Order Form

    Replacement Parts Order Form Complete the form below. Your model number with color code and manufacturer date code MUST be included on the form to ensure proper replacement parts. Your model number with color code and the date code can be found on a sticker on the side of child restraint.
