4358-4462B US onBoard 35lb
1/5/11
Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted.
Part
Cost
Quantity Total Cost
Crotch Strap/Buckle $6.99 X ____= $ ____________
Full Wrap Seat Pad $27.50 X ____= $ ____________
(includes Head/Hip Roll and Canopy)
Chest Clip . . . . . . . .$1.50 X ____= $ ____________
Harness Strap . . . . .$2.00 X ____= $ ____________
Locking Clip . . . . . . .$2.50 X ____= $ ____________
Latch Kit . . . . . . . .$24.99 X ____= $ ____________
Base . . . . . . . . . . . .$34.99 X ____= $ ____________
Instructions . . . . . . .$0.00 X ____= $ ____________
Merchandise Total:
Shipping and Handling:
Up to $25.00 . . . . . . . . . .$5.95
$25.01 to $50.00 . . . . . . .$6.95
$50.01 to $75.00 . . . . . . .$8.95
$75.01 to $100.00 . . . . . .$9.95
Sales Tax
(Indiana, California, Arkansas, and Massachusetts residents add applicable
sales tax.)
Grand Total
No shipping and handling on instructions for quantities under 6. Add $.50 for
each instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
Visa
Card Exp. Date: ______________________________
Cardholder's Name: __________________________
Card Number: ______________________________
Signature: __________________________________
1:09 PM
Page 1
$ ____________
$ ____________
$100.01 to $150.00 . . . . .$10.95
$150.01 to $200.00 . . . . .$11.95
$200.01 and up . . . . . . . .$13.95
Outside Continental USA $10.00
$ ____________
$ ______________
Mastercard
54
onBoard
™
, SureFit
Infant Seat
Instruction Manual
www.djgusa.com
Read all instructions
BEFORE USING
this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
IMPORTANT!
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
Para recibir las instrucciones en español, llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Eng. 4358-4462B
™
This child
restraint is
designed for
use by children
whose:
Weight:
4-35 pounds
(1.8-15.9 kg)
Height:
32 inches (81.2 cm)
or less

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infant and is the answer not in the manual?

Questions and answers

Related Manuals for Djgusa Infant

Summary of Contents for Djgusa Infant

  • Page 1 ™ , SureFit ™ NOTE: If requested color is not available, similar color will be substituted. Infant Seat Part Cost Quantity Total Cost Crotch Strap/Buckle $6.99 X ____= $ ____________ Instruction Manual Full Wrap Seat Pad $27.50 X ____= $ ____________ (includes Head/Hip Roll and Canopy) www.djgusa.com...

  • Page 2: Table Of Contents

    Department at: Rear-Facing Installation LATCH And Base..............31-36 Dorel Juvenile Group, Inc. Vehicle Belt With Base ............37-41 Vehicle Belt Without Base ..........40-41 Website: www.djgusa.com Rear-Facing Use Without Base ............42 Fax: 1-800-207-8182 Rear-Facing Installation Mailing Address: Dorel Juvenile Group, Inc. Vehicle Belt Without Base ..........43-44 P.O.

  • Page 3: Warnings

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 5 WARNING WARNING Failure to follow these warnings can result in The vehicle or LATCH belt must stay the serious injury or death of your child. To tight at the belt path. If it’s not, your child help you recognize those instructions which could be injured or killed.

  • Page 4: Aircraft Installation

    1-800-544-1108 or register online at the lap belt can be tightened securely.This child restraint www.djgusa.com/registration/carseat/us. Please do is installed in an aircraft seat the same way it is installed not send in your registration card if you registered your in a vehicle.

  • Page 5: Understanding Your Vehicle

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 9 Understanding Your Vehicle Your vehicle’s features may be considerably different than those pictured here. Consult your vehicle owner’s manual to help identify your vehicle’s specific features. A.Anchor Bracket D.Airbag For Top Anchorage Strap (Consult your vehicle (Forward-Facing Only) owner’s manual for all airbag...

  • Page 6: Child Restraint Parts

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 11 Child Restraint Parts Front Back Handle Harness Angle Indicator Canopy Chest Clip Adjustment Strap Removable Base Head/Hip Roll Harness Straps Base Release Lever (on select models) Buckle Release Base Adjustment Handle Adjustment Button Lever Lever...
  • Page 7 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 13 Base Bottom of Carrier Base Release Lever Instruction Book Base Belt Path LATCH Storage Storage Opening Door Harness Slots Harness Belt Lock Off Base Adjustment Harness Straps Adjustment Strap Plates Lever Locking Clip Belt Lock Off Plates Base Attachment...

  • Page 8: Canopy Installation And Use

    Snap each plastic For Small Infants: strip end to each canopy If your infant is small for post. its age, place the head roll on the outside of the pillows. This will provide a snug fit for your infant.

  • Page 9: Carrier Use

    NEVER leave child unattended. Always keep position, the lock indicator child within arm’s reach. will be green. Make sure Suffocation Hazard: Infant carrier can roll both handle adjuster levers over on soft surfaces and suffocate child. are in the locked position.

  • Page 10: Choosing Restraint And Position

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 19 Choosing Restraint and Position Preparing Child Restraint to Fit Your Child Rear-Facing You MUST make these adjustments with your 4-35 lbs (1.8-15.9 kg) 32” (81.2 cm) tall or less. child before you install the child restraint in the vehicle.

  • Page 11: Harness Height

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 21 Press red button on To change harness buckle to release the location: buckle plates. Pull buckle With harness loose, from plates out. Place harness the back, remove harness straps over sides of child from the splitter plate.
  • Page 12 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 23 To change buckle Buckle placement for location: small infants: Determine which of the Choose the slot closest three available buckle to the back of the slots is both comfortable restraint. Push metal clip and snug for your child.

  • Page 13: Securing Your Child In The Child Restraint

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 25 Pull on the harness Securing Your Child in the Child adjustment strap to Restraint tighten harness snugly. Position harness straps NOTE: A snug strap over the child’s shoulders. should not allow any slack. It lies in a relatively straight line without sagging.

  • Page 14: Choosing Latch Or Vehicle Belts

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 27 Removing Your Child from the Choosing LATCH or Vehicle Belts Child Restraint The LATCH System Loosen harness by pushing The LATCH system can ONLY be used when installing down on the harness this child restraint rear-facing WITH the base.

  • Page 15: Knowing Your Vehicle Belts

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 29 Manual Belts Knowing Your Vehicle Belts Manual lap belts are Not all vehicle belts will work with this child restraint. You common in the center must determine if your vehicles belts are compatible with rear seat and can allow this child restraint.

  • Page 16: Locking Clip

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 31 Position locking clip about Locking Clip 1 in. (2.5 cm) from vehicle belt’s buckle plate. Use the locking clip ONLY when installing the child restraint with out the base. The base has a built in lock off system and will not require the use of the locking clip.

  • Page 17: Rear-Facing Use With Base

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 33 Rear-Facing Use With Base Rear-Facing Installation with LATCH and Base Belt lock off MUST be used when using this base. Child and child restraint with base face the back of the vehicle and child restraint is correctly installed in a back seat.
  • Page 18 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 35 Lift up belt lock off plate Thread the LATCH hook marked “B”. and adjuster through the right side belt path opening as shown. NOTE: Make sure LATCH belt is not twisted. Fasten one LATCH belt hook to one vehicle LATCH anchor, then...
  • Page 19 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 37 Close both “A” and “B” Check the angle indicator. lock off plates and lock. The ball should be between the two marks on the indicator that matches the weight of your child. Adjust base if needed.

  • Page 20: Vehicle Belt With Base

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 39 To release LATCH: Push Rear-Facing Installation with in on release button and pull Vehicle Belt With Base: LATCH adjuster away from child restraint to loosen. Belt lock off MUST be used when using this base. Unhook LATCH hooks.
  • Page 21 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 41 Lift up on the belt lock off Push down FIRMLY on lock. the base and pull up on the loop to tighten belt. Tips: To help in tightening, pull the loop end up through the belt path, then tighten.
  • Page 22 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 43 Align notches in the front To Adjust Base: of carrier with the bars Loosen vehicle belt and on the base. Push down pull out on the base firmly to lock into place. adjustment lever and You will hear a “click”...

  • Page 23: Vehicle Belt Without Base

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 45 Rear-Facing Use Without Base Rear-Facing Installation with Vehicle Belt - Without Base: Place carrier rear-facing in the back seat. Check the angle indicator. The ball should be between the two marks on the indicator that matches the weight of your child.

  • Page 24: Storing The Latch System

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 47 Check the angle indicator. Storing the LATCH System The ball should be between the two marks on To store LATCH system: the indicator that matches Open the LATCH storage the weight of your child. door and attach the LATCH Adjust base if needed.

  • Page 25: Removing Seat Pad For Cleaning

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 49 Remove the pad: Removing Seat Pad for Cleaning Release the six pad tabs on the side of the carrier. WARNING Do not use this child restraint without the To release the tab, pull seat pad.
  • Page 26 4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 51 Replace seat pad by From the front, make reversing order. harness ends even with Pulling buckle through each other. pad, wrap pad around Thread harness straps bottom and top of carrier. through each buckle Reattach the tabs to sides tongue (1), thread through...

  • Page 27: Troubleshooting

    If the buckle the consumer. plate will not lock securely, go to www.djgusa.com or Warranty Limitations: call 1-800-544-1108 for assistance. This warranty does not include damages which arise from If your harness twists or ropes: misuse or abuse of this product.

  • Page 28: Replacement Parts Order Form

    4358-4462B US onBoard 35lb 1/5/11 1:09 PM Page 55 Replacement Parts Order Form Complete the form below. Your model number with color code and manufacturer date code MUST be included on the form to ensure proper replacement parts. Your model number with color code and the date code can be found on a sticker on the side of child restraint.
