MANUAL DEL USUARIO / USER'S MANUAL
HARD series: AX-212-3V
Manufactured by TSA. / Polígono Alcodar / Carrer Dels musics nº 3 / 46701 Gandia– Valencia (Spain)
Tl: (34) 96 286 8985 / http://www.tsa-sound.com / E.mail: info@tsa-sound.com
1
TSA. Subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AX-212-3V and is the answer not in the manual?

Questions and answers

Related Manuals for TSA AX-212-3V

Summary of Contents for TSA AX-212-3V

  • Page 1 MANUAL DEL USUARIO / USER’S MANUAL HARD series: AX-212-3V Manufactured by TSA. / Polígono Alcodar / Carrer Dels musics nº 3 / 46701 Gandia– Valencia (Spain) Tl: (34) 96 286 8985 / http://www.tsa-sound.com / E.mail: info@tsa-sound.com TSA. Subject to change without notice.
  • Page 2 MANUAL DEL USUARIO / USER’S MANUAL HARD series: AX-212-3V Manufactured by TSA. / Polígono Alcodar / Carrer Dels musics nº 3 / 46701 Gandia– Valencia (Spain) Tl: (34) 96 286 8985 / http://www.tsa-sound.com / E.mail: info@tsa-sound.com Introducción Introduction El AX-212/3V, es un sistema Line Array de curvatura variable, la...
  • Page 3 MANUAL DEL USUARIO / USER’S MANUAL HARD series: AX-212-3V Ficha Técnica / Data sheet AX-212-3V System Description: 3 Way system variable curvature Frequency Response (+3dB -10dB ). From 50 to 20,000Hz. Horizontal Coverage (-6dB). 100º Vertical Coverage (-6dB). Depends on configuration...
  • Page 4 10 mm, (Ver figura 4). 5. The adjustment hardware of the units (AX-212-3V) 5. El aparejo de reglaje de las unidades (AX-212-3V), es is retractable. Once the rod is disconnected from the retráctil, al desconectar la biela de la caja superior (Mediante top unit (by removing the two pins), it automatically extracción...
  • Page 5 You can now go ahead and fly both of Este procedimiento se puede repetir, para el ensamble de the clusters (See figure 5) un tercer cluster. This procedure can be repeated if you wish to mount a further third cluster. TSA. Subject to change without notice.
  • Page 6 5. Tornillos de sujeción del aparejo. 5. Fixing screws of the unit. 6. Pasador que ejerce la función de bisagra de la propia 6. Pin that acts as a hinge. biela. 7. Handle. 7. Asa de sujeción. TSA. Subject to change without notice.
  • Page 7 5. Once these operations are completed, the cluster 5. Una vez finalizadas estas operaciones, el cluster quedará will be correctly assembled, (see Detail 5). perfectamente ensamblado, (Ver detalle 5). 0º 1,25º 2,5º 5º 10º Step 1 Step 2 TSA. Subject to change without notice.
  • Page 8 MANUAL DEL USUARIO / USER’S MANUAL HARD series: AX-212-3V Configuración / Configuration AX-212-3V + SB-218 Pin +1 Pin - 1 Pin +2 Pin - 2 3 $ 5 $ / / ( / 3000W. / 2 oh. 3000W. / 2 oh.
  • Page 9 Flying system Sistema de voladura The AX-212-3V speakers are equipped with Las cajas AX-212-3V están dotadas de un sistema de flying system hardware as indicated on page 4 of voladura, tal como se indica en la página nº 4 de este this manual.
