- Page 1 BUILDING PROJECTOR AEDI WASH GLOBUS 16 MC User Manual Please read the instructions carefully before use Version 1.0...
-
Page 2: Table Of Contents
CONTENTS 1. SAFETY INSTRUCTION ..................2 3. TECHNICAL SPECIFICATIONS ................ 4 4. ACCESSORIES ....................... 5 5. HOW TO SET THE FIXTURE ................5 5.1 CONTROL PANEL ..................5 5.2 MAIN FUNCTIONS ..................6 6. HOW TO CONTROL THE UNIT ............... 10 6.1 DMX controller .................... -
Page 3: Safety Instruction
1. SAFETY INSTRUCTION Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Caution: ... - Page 4 DO NOT operate in dirty and dusty environment, also cleaning fixtures regularly. DO NOT allow children to operate the fixture. DO NOT touch any wire during operation as there might be a hazard of electric shock. Avoid power wires together around other cables. ...
-
Page 5: Technical Specifications
3. TECHNICAL SPECIFICATIONS Features: IP66 rated LED Spotlight with a saturated color mixing effect via lens specially designed to provide outstanding light output. Proper thermal management with active cooling system and heavy duty design to ensure reliable performance under harsh environment. Featuring 4pcs×10W CREE LEDs for excellent color mixing. -
Page 6: Accessories
4. ACCESSORIES - Power Extension Cable 1, 2, 5, 10 m. - DMX Extension Cable 1, 2, 5, 10 m. 5. HOW TO SET THE FIXTURE 5.1 CONTROL PANEL... -
Page 7: Main Functions
1. DISPLAY: To show the various menus and the selected functions 2. BUTTON: 2. MENU To select the programming functions To go backward the selected functions 3. DOWN 4. UP To go forward in the selected functions 5. ENTER To confirm the selected functions 3. - Page 9 DMX 512 Address Setting Select the , press the ENTER button and the display will blink. Use the DOWN and UP button to adjust the DMX512 address between 1 and 512. Once the address has been selected, press the ENTER button to save or automatically exit menu mode without any change after one minute. Back to the previous functions without any change press the MENU button.
- Page 10 go back to the functions without any change press the MENU button. Manual Mode Press the MENU button up to when the is shown on the display. Press the ENTER button （Red）, and the display will blink. Use the DOWN and UP button to select the （Green), （Blue）, （White）,...
-
Page 11: How To Control The Unit
LED Display Select the , press the ENTER button and the display will blink. Use the DOWN and UP （LED display on）or （LED display off 20 seconds after exit button to select menu） . Once select, press ENTER button to setup or exit menu mode without any change after one minute. - Page 12 and the display will blink. Use DOWN and UP button to change the DMX512 address. Once the address has been selected, press and keep ENTER button pressed up to when the display stops blinking or storing automatically 8 seconds later. To go back to the functions without any change press the MENU button again Please refer to the following diagram to address your DMX512 channel for the first 4 units：...
-
Page 13: Dmx 512 Configuration
6.3 DMX 512 Configuration 4/5/7 Channels Mode:... - Page 14 7. DMX512 CONNECTIONS 1. If you use a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2. Connect the unit together in a `daisy chain` by XLR plug from the output of the unit to the input of the next unit.
-
Page 15: Troubleshooting
used. 8. TROUBLESHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: Problem Possible Cause Action Check the connection of power. The unit does not work, no light. Incorrect power cable connection. -
Page 16: Fixture Cleaning And Maintance
9.FIXTURE CLEANING AND MAINTANCE The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: moist, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture. ... - Page 17 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. &...
- Page 18 WWW.SLEPROJECTS.COM © 2014. All specifications subject to change without notice...
