Ordering Code
Basic build
Model number Function
2416 CC
Function
CC Controller/8-seg
Programmer
CP Single 16-segment
Programmer
P4 Four Program 16-
segment
VC Valve positioner (VP)
/8 segment Prog.
VP VP/Single Prog. 16-
segment
V4 VP/Four Program.
16-segment
Supply voltage
VH 100 to 230Vac
VL 20 to 29Vac/dc
Comms
XX None
EIA-485 ( 2 wire )
Y2 Fitted unconfigured
YM Modbus protocol
YE EI Bisynch protocol
EIA-232
A2 Fitted unconfigured
AM Modbus protocol
AE EI Bisynch protocol
EIA-485 ( 4 wire )
F2 Fitted unconfigured
FM Modbus protocol
FE EI Bisynch protocol
PDSIO input
M6 Fitted unconfigured
RS Setpoint input
PDSIO output
M7 Fitted unconfigured
PT PV retransmission
TS Setpoint retrans
OT Output retrans
The Hardware code is followed by the Configuration code listed in the following page.
A-2
Plug-in modules
Supply voltage Module 1
VH
Module 1
XX None
Relay: 2-pin
R2 Fitted unconfigured
RH PID heating
RU Valve raise output
Or Alarm 1: select from table A
Logic non-isolated
L2 Fitted unconfigured
LH PID heating
(1)
M1 PDSIO mode 1
(1)
M2 PDSIO mode 2
Triac
T2 Fitted unconfigured
TH PID heating
TU Valve raise output
DC control non-isolated
D2 Unconfigured
H1 0-20mA heating
H2 4-20mA heating
H3 0-5Vdc heating
H4 1-5Vdc heating
H5 0-10Vdc heating
Manual
XXX No manual
ENG English
FRA French
GER German
ITA Italian
Module 2 Module 3
LH RC
Module 2
XX None
Relay: 2-pin
R2 Fitted unconfigured
RC PID cooling
RW Valve lower output
PO Program event output 1
Or Alarm 2: select from table A
Logic non- isolated
L2 Fitted unconfigured
LC PID cooling
Triac
T2 Fitted unconfigured
TC PID cooling
TW Valve lower output
DC control non-isolated
D2 Unconfigured
C1 0-20mA cooling
C2 4-20mA cooling
C3 0-5Vdc cooling
C4 1-5Vdc cooling
C5 0-10Vdc cooling
Table A : Alarm relay functions
FH High alarm
FL Low alarm
DB Deviation band
DL Low dev. alarm
DH High dev alarm
Installation and Operation Handbook
Comms Manual
RH MB ENG
Module 3
XX None
Relay: 2-pin
R2 Fitted unconfigured
PO Program event 2
LF PDSIO load failure
HF PDSIO heater failure
SF PDSIO SSR failure
Or Alarm 4 select from table A
Other modules
L2 Logic unconfigured
non-isolated
T2 Triac unconfigured
D2 DC unconfigured
non- Isolated
First character
PV retransmission
V−
Setpoint retransmission
S−
Output retransmission
O−
Error retransmission
Z−
Second character
−1
0 to 20mA
−2
4 to 20mA
−3
0 to 5V
−4
1 to 5V
−5
0 to 10V
HA025041 issue 12 Aug 14
