- Page 1 BEM-100Q ® Industrial ECX Embedded SBC with Intel Atom N270 User’s Guide...
-
Page 2: Table Of Contents
Content Content ........................2 Figures ........................4 Tables ......................... 5 Safety Instructions ...................... 7 Before You Begin ..................7 When Working Inside a Computer ............7 Preventing Electrostatic Discharge ............8 Preface ........................10 How to Use This Guide ................10 ... - Page 3 Exit Menu ....................44 Chapter 5 Driver Installation .................. 46 Appendix A DIO (Digital I/O) Sample Code .............. 47 Appendix B WatchDog Timer Sample Code ............49...
-
Page 4: Figures
Figures Figures Figure 1 Block Diagram ................16 Figure 2 Mechanical Dimensions ............... 18 Figure 3 Jumper Connector ............... 19 Figure 4 Jumper and Connector Locations ..........21 Figure 5 Align the SO-DIMM Memory Module with the onboard socket ..31 Figure 6 Press down on the SO-DIMM Memory Module to lock it in place 31... -
Page 5: Tables
Table 30 FAN1: FAN Wafer ................ 28 Table 31 COM2~4 RS-232 Port B Wafer ........... 29 Table 32 LAN1, 2: 10/100/1000 Ethernet RJ-45 Connector (BEM-100Q) .. 29 Table 33 USB1, USB2 2-Stack USB 2.0 Type A Connector ....... 29 Table 34 COM1 RS-232/422/485 DB-9 Male Connector ......30... - Page 6 Tables Table 35 VGA DV-15 Connector ..............30 Table 36 BIOS Main Menu ................. 34 Table 37 IDE Device Setting Menu ............34 Table 38 System Information ..............35 Table 39 Advanced Menu ................35 Table 40 Onboard I/O Configuration ............36 Table 41 OnBoard Peripherals Configuration Settings .......
-
Page 7: Safety Instructions
Safety Instructions Safety Instructions Before You Begin Before handling the product, read the instructions and safety guidelines on the following pages to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section in the Preface for advisory conventions used in this user’s guide, including the distinction between Warnings, Cautions, Important Notes, and Notes. -
Page 8: Preventing Electrostatic Discharge
Safety Instructions Follow the guidelines provided in “Preventing Electrostatic Discharge” on the following page. Disconnect any telephone or telecommunications lines from the computer. In addition, take note of these safety guidelines when appropriate: To help avoid possible damage to system boards, wait five seconds after turning off the computer before removing a component, removing a system board, or disconnecting a peripheral device from the computer. - Page 9 Safety Instructions or packaging. Handle all sensitive components at an ESD workstation. If possible, use antistatic floor pads and workbench pads. Handle components and boards with care. Don’t touch the components or contacts on a board. Hold a board by its edges or by its metal mounting bracket. Do not handle or store system boards near strong electrostatic, electromagnetic, magnetic, or radioactive fields.
-
Page 10: Preface
Preface Preface How to Use This Guide This guide is designed to be used as step-by-step instructions for installation, and as a reference for operation, troubleshooting, and upgrades. Unpacking When unpacking, follow these steps: After opening the box, save it and the packing material for possible future shipment. -
Page 11: Maintaining Your Computer
Preface their own expense. Changes or modifications not expressly approved by us could void the user's authority to operate the equipment. NOTE The assembler of a personal computer system may be required to test the system and/or make necessary modifications if a system is found to cause harmful interference or to be noncompliant with the appropriate standards for its intended use. - Page 12 Preface the operating and storage humidity specifications. Altitude Operating a system at a high altitude (low pressure) reduces the efficiency of the cooling fans to cool the system. This can cause electrical problems related to arcing and corona effects. This condition can also cause sealed components with internal pressure, such as electrolytic capacitors, to fail or perform at reduced efficiency.
- Page 13 Preface longer period of time when AC power is lost. UPS systems that provide only 5 minutes of battery power let you conduct an orderly shutdown of the system, but are not intended to provide continued operation. Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved.
-
Page 14: Chapter 1 Introduction
Chapter 1 Chapter 1 Introduction Overview The BEM-100Q is an ECX Form Factor embedded single board computer (SBC) ® that combines the high performance and low power consumption of the Intel ® Atom™ processor with Intel 945GSE/ ICH7-M chipset and supports DDR2 400/533 SODIMM up to 2GB. -
Page 15: Product Specifications
Chapter 1 Product Specifications Model Name BEM-100Q Form Factor ECX (146mm x 105mm) Layer 8 layers with green color ® Processor Intel Atom N270 processor Memory 1x SO-DIMM for DDR2 supported Chipset Intel945GSE + ICH7-M Integrated on 945GSE chipset 1x DB-15 connector for VGA output on rear I/O... -
Page 16: System Block Diagram
Power AT/ATX supported Operation Temp. 0ºC – 60ºC Storage Temp. -10ºC – 85ºC Humidity 0% – 90% Certifications CE, FCC Class A Table BEM-100Q Specification System Block Diagram BLOCK DIAGRAM Single DC Vcore Vcore 12Vin Intel Atom Processor N270 SYSTEM... -
Page 17: Mechanical Dimensions
Chapter 1 Mechanical Dimensions... -
Page 18: Figure 2 Mechanical Dimensions
Chapter 1 Figure 2 Mechanical Dimensions... -
Page 19: Chapter 2 Hardware Settings
Chapter 2 Chapter 2 Hardware Settings Overview This chapter provides the definitions and locations of jumpers, headers, and connectors. Jumpers The product has several jumpers which must be properly configured to ensure correct operation. Figure 3 Jumper Connector For a three-pin jumper (see figure above), the jumper setting is designated “1-2” when the jumper connects pins 1 and 2. -
Page 20: Jumper Settings And Pin Definitions
Chapter 2 Jumper Settings and Pin Definitions For jumper and connector locations, please refer to the diagrams below. -
Page 21: Jumper Settings
Chapter 2 Figure 4 Jumper and Connector Locations Jumper Settings To ensure correct system configuration, the following section describes how to set the jumpers to enable/disable or change functions. For jumper descriptions, please refer to the table below Table 2 Jumper List Label Function Clear CMOS Selection... -
Page 22: Jumper Setting
Chapter 2 AMP_R1 Audio AMP Right Output Wafer AMP_L1 Audio AMP Left Output Wafer IrDA Pin Header FAN1 System FAN Wafer COM2,3,4 RS-232 Wafer Table 4 Rear Panel Connector List Label Function LAN1 10/100/1000 Ethernet RJ-45 Connector LAN2 10/100/1000 Ethernet RJ-45 Connector USB1 USB2.0 Port 2 , 3 Type A Connector COM1... -
Page 23: Connector Pin Assignment
Chapter 2 Table 8 JP7: Power Mode Selection Jumper Status Open ATX Mode Short AT Mode Pitch: 2.54mm [YIMTEX 3321*02SAGR (6T)] Table 9 JP8: Mini-PCIE Revision Selection Jumper Status V1.1 V1.2 Pitch: 2.0mm [YIMTEX 3291*03SAGR (6T)] Connector Pin Assignment Table 10 ATX1: +12V Power Input Connector Signal Name +12V +12V... -
Page 24: Table 13 Cn2: Digital Input / Output Pin Header
Chapter 2 Table 13 CN2: Digital Input / Output Pin Header Signal Signal Digital Output 0 Digital Input 0 Digital Output 1 Digital Input 1 Digital Output 2 Digital Input 2 Digital Output 3 Digital Input 3 DIP 10P 2R MALE STRAIGHT TYPE Pitch: 2.54mm [YIMTEX 3322*05SAGR (6T)] Table 14 CN3 VGA BOX HEADER Signal Signal... -
Page 25: Table 17 Fp1: Front Panel 1 Pin Header
Chapter 2 Table 17 FP1: Front Panel 1 Pin Header Signal Signal Reset Button + Speaker + RSTBTN SPKR Reset Button - HLED HDD LED + HDD LED - Speaker - Pitch: 2.54mm [YIMTEX 3322*04SAGR (6T)] Table 18 FP2: Front Panel 2 Pin Header Signal Signal Power LED +... -
Page 26: Table 21 Mpcie1, Mpcie2:Mini Pcie Slots
Chapter 2 Table 21 MPCIE1, MPCIE2:Mini PCIE slots Signal Name Signal Name PCIE_WAKE# +3.3VSB +1.5V *UIM_PWR/NC *UIM_DATA/NC CLK100_MPCIE1#/2 *UIM_CLK/NC CLK100_MPCIE1/2 13 *UIM_RESET/NC *UIM_VPP/NC MPCIE1/2_EN RST_PCIE# PCIE_RX2-/3- +3.3VSB PCIE_RX2+/3+ +1.5V SB_SMB_CLK PCIE_TX2-/3- SB_SMB_DAT PCIE_TX2+/3+ USB6N/7N USB6P/7P +3.3VSB +3.3VSB LED_WLAN# LED_WLAN# LED_WLAN# +1.5v +3.3VSB SMD PCIE 52P 90D(F) MINI PCI-Express Connector [FOXCONN AS0B226-S56N-7F]... -
Page 27: Table 23 Usb2.0 Port 4, 5 Pin Header
Chapter 2 Table 23 USB2.0 Port 4, 5 Pin Header Signal Name Signal Name USB4- USB5- USB4+ USB5+ Pitch:2.54mm（Remove 9 pin of YIMTEX 3322*05SAGR(6T)）[YIMTEX 3322*05SAGR(6T) -09] Table 24 CFD1: CF Type II Connector Signal Name Signal Name IDE Data 3 IDE Data 11 IDE Data 4 IDE Data 12... -
Page 28: Table 26 Sata2: Sata Connector
Chapter 2 Table 26 SATA2: SATA Connector Signal Name DIP 7P 180D SATA CONNECTOR BLUE [FOXCONN LD1807V-S52U] Table 27 AMP_R1: Audio AMP Right Output Wafer Signal Name Speaker+ Speaker- Pitch=2.0mm 2P 180° WAFER [YIMTEX 503PW1*02STR] Table 28 AMP_L1: Audio AMP Left Output Wafer Signal Name Speaker+ Speaker-... -
Page 29: Rear Panel Pin Assignment
GND, ground P-1.25mm WAFER [YIMTEX 501MW1*10STR] COM Port Cable 0C5019001000010L COM Port cable, 10-pin pitch=1.25mm to DB-9 connector, L=10cm Rear Panel Pin Assignment Table 32 LAN1, 2: 10/100/1000 Ethernet RJ-45 Connector (BEM-100Q) Signal Name Signal Name MDI 0+ MDI 0-... -
Page 30: Table 34 Com1 Rs-232/422/485 Db-9 Male Connector
Chapter 2 Table 34 COM1 RS-232/422/485 DB-9 Male Connector Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ 9Pin 90 degree Color：Green/for PC99 W/SCREW screw head=4.8mm，screw total length=9.5mm [Fen Ying SM1001P01012PN] Note 1：RS-232 / 422 / 485 can be selected in BIOS setup. Table 35 VGA DV-15 Connector Signal Name Signal Name... -
Page 31: Chapter 3 System Installation
Chapter 3 Chapter 3 System Installation Memory Module Installation Carefully follow the steps below in order to install the SO-DIMMs: To avoid generating static electricity and damaging the SO-DIMM, ground yourself by touching a grounded metal surface or use a ground strap before you touch the SO-DIMM. - Page 32 Chapter 3 Removing a SO-DIMM: To remove the SO-DIMM, use your fingers or a small screwdriver to carefully push away the tabs that secure either side of the SO-DIMM. Lift it out of the socket. Make sure you store the SO-DIMM in an anti-static bag. The socket must be populated with memory modules of the same size and manufacturer.
-
Page 33: Chapter 4 Ami Bios Setup
Chapter 4 Chapter 4 AMI BIOS Setup Overview This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact us. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 34: Main Menu
Chapter 4 Main Menu The BIOS Setup is accessed by pressing the DEL key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins. Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main Menu provides System Overview information and allows you to set the System Time and Date. -
Page 35: Advanced Menu
Chapter 4 LBA/ Large Mode Enables or disables the LBA (Logical Block Addressing)/ Large mode. Setting to Auto enables the LBA mode if the device supports this mode, and if the device was not previously formatted with LBA mode disabled. Options: Disabled, Auto DMA Mode Options: Auto only S.M.A.R.T... -
Page 36: Table 40 Onboard I/O Configuration
Chapter 4 Table 40 Onboard I/O Configuration BIOS SETUP UTILITY M a i n B o o t C h i p s e t P o w e r S e c u r i t y E x i t A d v a n c e d Allows BIOS to Select Serial Onboard I/O Configuration... -
Page 37: Table 41 Onboard Peripherals Configuration Settings
Chapter 4 Table 41 OnBoard Peripherals Configuration Settings BIOS SETUP UTILITY M a i n B o o t C h i p s e t P o w e r S e c u r i t y E x i t A d v a n c e d OnBoard Peripherals Configuration Settings Options... -
Page 38: Table 42 Hardware Health Configuration
Chapter 4 Table 42 Hardware Health Configuration BIOS SETUP UTILITY M a i n B o o t C h i p s e t P o w e r S e c u r i t y E x i t A d v a n c e d Hardware Health Configuration Options... -
Page 39: Boot Menu
Chapter 4 Boot Menu Table 43 Boot Menu BIOS SETUP UTILITY M a i n A d v a n c e d C h i p s e t P o w e r S e c u r i t y E x i t B o o t Boot Settings... -
Page 40: Chipset Menu
Chapter 4 Chipset Menu Table 44 Chipset Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t P o w e r S e c u r i t y E x i t C h i p s e t Select the amount of... -
Page 41: Video Function Configuration
DVMT Mode Select [DVMT Mode] Options: Fixed Mode, DVMT Mode, Combo Mode DVMT/FIXED Memory [128MB] Options: 64MB, 128MB, Maximum DVMT Boot Display Device [CRT] Options: CRT, LVDS, CRT+LVDS Panel Type [1024x768 24Bit 2C] (For BEM-100Q, 24-bit) Options: 1024x768 24Bit 1CH 1280x1024 24Bit 2CH... -
Page 42: Power Menu
Chapter 4 Power Menu Table 46 Power Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t C h i p s e t S e c u r i t y E x i t P o w e r Enable / Disable... -
Page 43: Security Menu
Chapter 4 Security Menu Table 47 Security Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t C h i p s e t P o w e r E x i t S e c u r i t y Security Settings Install or Change the password. -
Page 44: Exit Menu
Chapter 4 Exit Menu Table 48 Exit Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t C h i p s e t P o w e r S e c u r i t y E x i t Exit Options Exit System Setup... - Page 45 Chapter 4 provide the best performance settings for your system. The F9 key can be used for this operation. Load Failsafe Defaults Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings.
-
Page 46: Chapter 5 Driver Installation
ATX Power Switch and install the desired operating system. You can download the drivers for the BEM-100Q from our website and install as instructed there. For other operating systems, please contact us. -
Page 47: Appendix A Dio (Digital I/O) Sample Code
Appendix A Appendix A DIO (Digital I/O) Sample Code //============================================ //BEM-100Q DOS DIO sample program //Please compile with Turbo C 3.0 to utilized the program //============================================ int RetVal; //init the chipset RetVal=inp(0x4B0); RetVal=RetVal|0x02; outp(0x4B0,RetVal); RetVal=inp(0x481,RetVal); RetVal=RetVal|0xF0; outp(0x481,RetVal); RetVal=inp(0x480,RetVal); RetVal=RetVal|0xC0; outp(0x480,RetVal);... - Page 48 Appendix A RetVal=inp(0x48d,RetVal); RetVal=RetVal&0x0F; outp(0x48d,RetVal); //Output RetVal to Digital Output //Set all output to 1 outp(0x48d, 0xF0);//DO0 is bit 4 //DO1 is bit 5 //DO2 is bit 6 //DO3 is bit 7 //Set all output to 0 outp(0x48d, 0x00); //Reading Digital input RetVal=inp(0x48c);//DI0 is bit 6 //DI1 is bit 7 RetVal=inp(0x4B8);//DI2 is bit 6...
-
Page 49: Appendix B Watchdog Timer Sample Code
Appendix B Appendix B WatchDog Timer Sample Code //============================================ //BEM-100Q DOS Watchdog sample program //Please compile with Turbo C 3.0 to utilized the program //============================================ //Initialized the WDT program outp(0x2e,0x87); outp(0x2e,0x01); outp(0x2e,0x55); outp(0x2e,0x55); //Setting Logical Device Number to 0x07 outp(0x2e,0x07);...
