Instructions, Maintenance and Service Manual ULTRAFREEZER Series INDEX GENERAL _____________________________________________________________________________ 2 TRANSPORT ___________________________________________________________________________ 3 SPECIFICATIONS ________________________________________________________________________ 3 Freezer _____________________________________________________________________________ 3 Controller ___________________________________________________________________________ 4 Basic print __________________________________________________________________________ 5 WATER COOLED CONDENSER (optional) ____________________________________________________ 6 INSTALLATION INSTRUCTIONS ____________________________________________________________ 7 INSTALLATION _________________________________________________________________________ 8 ULTRAFREEZER FUNCTIONING ____________________________________________________________ 9 7.1. -
Page 3: General
Instructions, Maintenance and Service Manual ULTRAFREEZER Series 1. GENERAL The ULTRAFREEZER series Ultra Low Temperature freezers have a storage freezing system with a temperature range from -50°C up to -86 °C. Cooling is realized by means of a cascade system, where in the highest stage (first) R507 is used as refrigerant and in the lowest stage (second) a mix of R508b and R170. -
Page 4: Transport
2. TRANSPORT The Fiocchetti ULTRAFREEZERS must be transported vertically (especially for the compressors which need to be upright under all circumstances!). This prevents that oil comes out of the carter (from the compressors and the oil separator), which would affect the cooling system seriously. -
Page 5: Controller
Instructions, Maintenance and Service Manual ULTRAFREEZER Series Controller Type SL9002 – Slimline, version 1.04 Case Aluminium built-in profile Dimensions 200 * 72 * 30 mm (lxhxd) Hole in the panel min. 173 * 66 mm (bxh) Front Polycarbonate (IP-44) Display... -
Page 6: Basic Print
Instructions, Maintenance and Service Manual ULTRAFREEZER Series Basic print Voltage 100-240 Vac; 50/60 Hz. Power 10 VA External emergency power 24 Vdc, 5 VA External battery 12 Vdc, max. 15 Ah Print size 280 * 140 mm Range 100/+25°C TEMP-1 = Control sensor, PT1000-2 sensor,... -
Page 7: Water Cooled Condenser (Optional)
Instructions, Maintenance and Service Manual ULTRAFREEZER Series 4. WATER COOLED CONDENSER (optional) Inlet (4) Outlet (1) Condenser (6) Water pressure valve Water valve (3) (5)(5) valvedruk Water-cooled condenser system ventiel (5) Inlet (4) Uitlet (1) Pressure pressostat (2) Water in- & outlet (1) -
Page 8: Installation Instructions
Instructions, Maintenance and Service Manual ULTRAFREEZER Series Explanation At the back of the freezer you’ll find the connections for the water inlet (4) and the water outlet (1). PT1000 sensor (temperature value sensor shown in the display) activate the cooling only when necessary. -
Page 9: Installation
We advise to keep the door open as short as possible to avoid freezing and temperature leaps. If the ultrafreezer is kept on stock fo a long while, the battery may be out of power. So, loading the battery can take some time. -
Page 10: Ultrafreezer Functioning
Switching ON/OFF Plug in the ultrafreezer. The ULTRAFREEZER is switched on by pressing the ‘POWER ON/OFF’ button, if the access code is correct (led above code button is switched on). Once switched on the freezer the controller will display the temperature detected by the temperature sensor and the temperature alarm relay will be activated. -
Page 11: Changing The Setpoint
Instructions, Maintenance and Service Manual ULTRAFREEZER Series After releasing the ‘BATT.’ button, the actual temperature will appear again in the display. Settings can be changed as mentioned in the paragraphs 7.5, 7.6 and 7.7 (the controller is set on the factory settings). -
Page 12: Alarm Test Function
Remember to take note of the password! The freezer cannot be switched off or the parameters can not be changed or visualized on the display without it. When you forgot the code, Fiocchetti can supply you a master code. With this master code, all parameters including the access code can be adjusted. -
Page 13: Resetting Alarm/Buzzer
Instructions, Maintenance and Service Manual ULTRAFREEZER Series 7.10. Resetting alarm/buzzer If there is an alarm, a message appears on the display and a LED light on (with the exception of the alarm temperature relay). At the same time, the potential free contact and the buzzer is activated. - Page 14 Instructions, Maintenance and Service Manual ULTRAFREEZER Series Click on the Fiocchetti logo, left above and CHOOSE LANGUAGE. Select the language you wish. Press button load and below dialog screen appears to select the map with the log data. Press OK and the data will be read in and appears in the program.
-
Page 15: Alarms
Check frequently the vacuum release (left side upright freezers), if it’s ice-free. The vacuum release can easily be removed. Important When unexpected problems occur during working with the ULTRAFREEZER, which can be dangerous for yourself and/or your surrounding, remove the plug immediately from the outlet. -
Page 16: Trouble Shooting
Instructions, Maintenance and Service Manual ULTRAFREEZER Series 10. TROUBLE SHOOTING 10.1 TROUBLE SHOOTING AIRCOOLED CONDENSER Doesn't reach set temperature. Cold Control Wrong Change settings. Back up -60 Wrong Warm Check settings of the temperature- controller. Check both compressors Wrong Total failure of Check power Check fuse. -
Page 17: Extra, Trouble Shooting Watercooled Condenser
Instructions, Maintenance and Service Manual ULTRAFREEZER Series 10.2 EXTRA, TROUBLE SHOOTING WATERCOOLED CONDENSER Compressor 1 stage commutes (on-off-on-off), compressor 2 stage off & ventilator functions: Magnet switch for water is defect; Constipation warmth exchanger; Water temperature too high; Water pressure too low;... - Page 18 Instructions, Maintenance and Service Manual ULTRAFREEZER Series...
