2.4 Digital Extension Indoor Monitor Settings
a) On the extension Indoor Monitor menu, from System->Project, you can input project password
(002236) to go to the project interface.
b) Set current Indoor Monitor as extension Indoor Monitor.
Step1 Press Product Info, See Figure 2-9
Step2 Press Master, Master icon becomes 'Extension' icon.
Step3 Set Room No. (i.e. 9901-1), input IP Address, Subnet Mask and Gateway.
Step4 In Master IP, input IP of the master Indoor Monitor.
c) Click Network on the right pane and then enable current function. See Figure 2-10.
d) Click to go to the next page to set extension Outdoor Station. Enable current function and then click OK.
Figure 2-9.
Figure 2-10
7
