  • Page 1 TFF 310 CI USER’S MANUAL...
  • Page 2 User’s manual · TFF 310 CI NOTE: This user’s guide is adapted to software version v.1.47of TFF 310 CI dated 09/04/2014. For future software updates, you can download the user’s guide from the following website: http://www.ftemaximal.com/ Chapter 1. Installation. 1.1. Safety Measures 1.- Never place the device next to hot sources.
  • Page 3 1.3. Description and connections The module TFF 310 CI is used for the reception of free channels that obey the DVB-T standards. Each module allows the reception of a complete multiplex in DVB-T (COFDM), and its subsequent regeneration in a new multiplex.
  • Page 4 Configuration of the channel and output parameters of a multiplex with a corrected error rate. 1.4. Programming TFF 310 CI has two ethernet connectors. In order to make the programming of the module you have to connect the corresponding programmer to PRO 201 connector.
  • Page 5 PRO 201 and PRO 300. mediaMAX EVO / mediaMAX MINI In order to start programming the TFF 310 CI regenerator, you will have to go to “Tools” option through the key 8 of your field strength meter and to select the “Transmodulator Prog.“ option.
  • Page 6 User’s manual · TFF 310 CI 2. Device Status In the option “Device Status” are specified the main parameters of the module at this moment. - Front End: It indicates whether the module is hooked or without signal. - Input bit rate: Transfers of data in the terrestrial tuner input.
  • Page 7 User’s manual · TFF 310 CI 5. Set Output channel In this option you can configure the different parameters of the cable signal. - Channel standard: It allows you to select the channelling of the cable signal standards. Options: BG, BG, PAL BG IT, LL, M NTSC, PAL M, PAL N, PAL DK , PAL I, BB_AU, DK PAL, L PAL.
  • Page 8 User’s manual · TFF 310 CI - Auto Alias: It allows configuring the name/alias of the modules automatically. Options: Channel, Frequency, Service, None. - Upgrade: - Send Firmware from USB: It allows carrying out the firmware update from the USB device.
  • Page 9 User’s manual · TFF 310 CI Adding services: 1. Select “Service to add” option 2. Select one of the multiplex 3. Once you have chosen the services you want to add. service, select the “Add/Rem” button to include the service in the multiplex.
  • Page 10 User’s manual · TFF 310 CI - Bandwidth limitation: It allows selecting the % of the capacity of the output channel. - Auto service addition: - On: It selects the services automatically when an input carrier is tuned and when the list of selected services is empty.
  • Page 11 User’s manual · TFF 310 CI - Both: Once the loss of decryption of the CAM is detected, the rights will be sent several times until the decryption gets back. In cases where it does not get back the module will make a reset of the CAM.
  • Page 12 User’s manual · TFF 310 CI Output configuration (Out TV) In these options you can configure the output parameters of the terrestrial signal. TFF310CI *Out TV - RF Channel (MHz): Output frequency of terrestrial modulation. In order to Mode: DVB-T introduce the frequency, press the “OK”...
  • Page 13 User’s manual · TFF 310 CI 3. Config In “Config” option the information concerning the regenerator is given. TFF 310 CI Global Update >Read LOG file Delete LOG file - Read log: It allows reading the registered events in the module.
  • Page 14 User’s manual · TFF 310 CI Note: It is not recommended to exceed the 85% of the maximum capacity of the multiplex due to the possible variability of the bits rate of the inputs services. - Output service name: This option allows editing the services name and changing it. By means the bottoms “Left / Right”...
  • Page 15 User’s manual · TFF 310 CI Terrestrial modulation (Out Terr) These options allow configuring the DVB-T/DVB-H modulator of the device. Out ter - Modulation: Output modulation format: 4 QAM, 16 QAM, 64 QAM. - Invert (Spectrum inversion): Activate or deactivate the spectrum reverse in 1.Modulation...
  • Page 16 User’s manual · TFF 310 CI - Adding Services: Output services Output services Output services 1.Add services PID :00500 ANTENA 3 2.Delete services 1.Add Operation finish BW usage 000% BW usage TFF 310 CI Mux 0 TFF 310 CI Mux 0...
  • Page 17 User’s manual · TFF 310 CI Network Option: This option allows adjusting the identification parameters of multiplex. -Network name: Associated name to the network. - TSID: Identification value of Transport Stream. Give a different value of TSID Network options for each output multiplex configured is recommended.
  • Page 18 User’s manual · TFF 310 CI 3. SD Backup This option allows saving and loading the configuration of the module in the PRO 300 programmer. - Read from module: It stores the current configuration of the module in the memory of the programmer. The steps to...
  • Page 19 User’s manual · TFF 310 CI - Addingservices Decrypt services Decrypt services Decrypt services 1.Add services PID :00500 NEOX 1.Slot 0 2.Delete services 1.Add 2.Slot 1 2.All TFF 310 CI TFF 310 CI Mux 0 TFF 310 CI 1. Select the option “Add services”...
  • Page 20 User’s manual · TFF 310 CI 1.5. Accessories and example of installation Weak signal Installation where we get a bad signal and high error rates in the output of the antenna. This signal is injected in the headend formed by 6 TFF...

  • Page 21: Technical Features

    User’s manual · TFF 310 CI Chapter 2. Technical features Ref. TFF 310 CI Code 2003552 Input frequency margin 170-230 / 470-862 MHz Input modulation COFDM Input level 38-88 dBuV Imput impedance Bandwidth (MHz) DVB-T (6 - 7- 8) Guard Interval...
  • Page 22 User’s manual · TFF 310 CI ATACHMENT I Depending on the configured parameters we are going to obtain one particular channel capacity (output useful bit rate). In order to make an estimation of this output bits rate, we have to take into account the following parameters:...
  • Page 23 User’s manual · TFF 310 CI Useful channel capacity (8 MHz) Guard Interval Modulation FEC codification 1/16 1/32 4.976 5.529 5.855 6.032 6.635 7.373 7.806 8.043 QPSK 7.465 8.294 8.782 9.048 8.294 9.216 9.758 10.053 8.709 9.676 10.246 10.556 9.953 11.059...
