SF-1000 MKII
fog machine
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-1000 MKII and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stairville SF-1000 MKII

Summary of Contents for Stairville SF-1000 MKII

  • Page 1 SF-1000 MKII fog machine user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 29.11.2016, ID: 377151 (V2)

  • Page 3: Table Of Contents

    1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 9 Features............................... 16 Installation..............................17 Connections and controls........................18 Operating..............................25 Technical specifications........................29 Troubleshooting............................30 Cleaning............................... 31 Protecting the environment......................33 SF-1000 MKII...

  • Page 4: General Information

    General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual.

  • Page 5: Further Information

    Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. SF-1000 MKII...

  • Page 6: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Cross-references References to other locations in this manual are identified by an arrow and the specified page number.
  • Page 7 NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. SF-1000 MKII...
  • Page 8 General information Warning signs Type of danger Warning – flammable substances. Warning – hot surface. Warning – suspended load. Warning – harmful or irritating substances. Warning – danger zone. fog machine...

  • Page 9: Safety Instructions

    Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. SF-1000 MKII...
  • Page 10 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged.
  • Page 11 The distance of persons and objects to the fog nozzle must be at least fifty centi‐ metre (1.6 feet). Do not touch the fog nozzle during and shortly after operation. It becomes very hot and may cause burns even several hours after switching off the device. SF-1000 MKII...
  • Page 12 Safety instructions WARNING! Risk of slipping caused by condensation Fog machines can produce condensation. Do not direct the fog to floors. Floors and surfaces can become slippery by condensed fog. Check at regular intervals whether it is possible to walk on the floors without a slipping hazard, and, if necessary, remove the condensation.
  • Page 13 Do not expose persons with health problems (such as allergic respiratory condi‐ tions, asthma) to artificial fog. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. SF-1000 MKII...
  • Page 14 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker.
  • Page 15 PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet. SF-1000 MKII...

  • Page 16: Features

    Features Features This fog machine is suitable for use in clubs, bars, discotheques and on stages. Special features of the device: remote control included suitable for mobile use large liquid container for the fog liquid fast heating-up timer and interval function fog machine...

  • Page 17: Installation

    You can install the device on the wall, ceiling or floor. The device must never be operated in a more than 15° tilted position. The device requires 20 cm clearance at the sides and above. SF-1000 MKII...

  • Page 18: Connections And Controls

    Connections and controls Connections and controls Front panel fog machine...
  • Page 19 Connections and controls 1 Fog nozzle. 2 Fog fluid container with screw-cap. 3 Carrying handle. SF-1000 MKII...
  • Page 20 Connections and controls Rear panel fog machine...
  • Page 21 6 Main switch. Turns the device on and off. 7 Fuse holder. 8 Mains cable for power supply. 9 Fog liquid level indicator. 10 Indicator LED. This LED lights red if no fog fluid is left in the liquid container. SF-1000 MKII...
  • Page 22 Connections and controls Remote control fog machine...
  • Page 23 16 The red LED lights up when the unit is operational after power up. 17 [CONTINUOUS] Use this button to generate a single fog blast. Blast duration and amount of fog can be adjusted with the [DURATION] and [VOLUME] controls. SF-1000 MKII...
  • Page 24 Connections and controls 18 The yellow LED indicates that the Timer function is turned on. 19 [TIMER ON | OFF] With this switch, you can turn the Timer function on or off. fog machine...

  • Page 25: Operating

    Open the screw-cap of the liquid container and fill in the fog fluid. Make sure that no fluid is spilled or gets into the device. The easiest way is using a funnel. The container capacity is 2 litre. Screw the cap firmly back on and start the device to reset the level sensor. SF-1000 MKII...
  • Page 26 Operating Turning the unit on NOTICE! Fire hazard Do not operate the machine unattended. Make sure that the remote control is connected. Connect the device to the power grid and turn it on with the main switch on the rear panel. The red LED on the remote will light up when the device is operational after a heating time of about 4 minutes.
  • Page 27 Now the function for singular fog emissions ([MANUAL]) is available again. Adjust the con‐ trols on the remote control as desired. If the device does emit fog, repeat the above mentioned steps. SF-1000 MKII...
  • Page 28 Operating Operating modes The device supports the following operating modes that you can select with the remote con‐ trol: Manual operation In this mode, the unit produces fog as long as you keep the pushbutton [MANUAL] pressed. The operating mode ‘Time-controlled operation’ is then suppressed. Time-controlled operation In this mode, the unit produces fog at the time intervals set by the [INTERVAL] control.

  • Page 29: Technical Specifications

    4 min Operating supply voltage 230 V 50 Hz Fuse 5 mm x 20 mm, 6 A, 250 V, fast blow Dimensions (W × H × D) 220 mm × 182 mm × 375 mm Weight 5 kg SF-1000 MKII...

  • Page 30: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy The unit does not work Check the mains connection and the main fuse. No fog output 1.

  • Page 31: Cleaning

    Insert the suction hose of the fog machine into the bottle with the fog machine cleaner. Connect the device to the mains and switch it on with the main switch. Wait until the unit has reached the required operating temperature. SF-1000 MKII...
  • Page 32 Cleaning Change to continuous operation and let the device produce fog for about 20 seconds. Insert the suction hose of the fog machine back into the fog fluid container and let the device again produce fog for about 20 seconds. This will rinse the lines. ð...

  • Page 33: Protecting The Environment

    Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. SF-1000 MKII...
  • Page 34 Notes fog machine...
  • Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
