- Page 1 SD-300 hazer user manual...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 18.12.2012...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 7 Features............................... 13 Installation..............................14 Connections and operating elements................... 15 Operation..............................21 Technical specifications........................24 Troubleshooting............................25 Cleaning............................... 26 Protecting the environment......................28 SD-300... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 NOTICE! This combination of symbol and signal word indicates a possible dangerous situation that can result in material and environmental damage if it is not avoided. SD-300...
- Page 6 General notes Warning signs Type of danger Warning – high-voltage. Warning – flammable substances. Warning – harmful or irritating substances. Warning – danger zone. hazer...
-
Page 7: Safety Instructions
Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. SD-300... - Page 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
- Page 9 Fog machines can produce condensation. Do not direct the fog to floors. Floors and surfaces can become slippery by condensed fog. Check at regular intervals whether it is possible to walk on the floors without a slipping hazard, and, if necessary, remove the condensation. SD-300...
- Page 10 Safety instructions WARNING! Health hazard caused by fog fluid handling Fog fluid does contain glycols complying with the regulations for foodstuffs. However, it may be harmful if swallowed. Do not induce vomiting. Seek medical advice immediately. Keep fog fluid in a safe place.
- Page 11 Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. SD-300...
- Page 12 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
-
Page 13: Features
Features Features This hazer is suitable for use in clubs, bars, discotheques and on stages. Special features of the device: Remote control included Suitable for mobile use Large fluid container SD-300... -
Page 14: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 15: Connections And Operating Elements
Connections and operating elements Connections and operating elements Front panel SD-300... - Page 16 Connections and operating elements 1 Haze output. 2 Fluid container with screw-cap. 3 Carrying handle. 4 Fog fluid feed line from fluid container to vaporiser. hazer...
- Page 17 Connections and operating elements Rear panel SD-300...
- Page 18 Connections and operating elements 2 Fluid container with screw-cap. 3 Carrying handle. 4 Fog fluid feed line from fluid container to vaporiser. 5 Liquid level indicator. 6 HEATING INDICATOR This LED indicates that the unit is warming up. 7 REMOTE CONTROL INPUT Connection for the remote control.
- Page 19 Connections and operating elements Remote control SD-300...
- Page 20 Connections and operating elements 10 Rotary control INTERVAL This control lets you adjust the time interval between two haze outputs in a range of 10 to 200 seconds. 11 Rotary control VOLUME With this control you can set the amount of haze per output to be produced (between 0 % and 100 %). 12 The green status LED indicates that the unit has reached the required operating temperature for haze generation.
-
Page 21: Operation
Open the screw-cap of the container and fill in the fog fluid. Make sure that no fluid is spilled or gets into the device. The easiest way is using a funnel. The container capacity is 1.0 litre. Screw the cap firmly back in. SD-300... - Page 22 Operation Turning the unit on NOTICE! Fire hazard Do not operate the machine unattended. Make sure that the remote control is connected. Connect the device to the power grid and turn it on with the main switch. The HEATING INDI‐ CATOR LED on the unit and the red LED on the remote control light up, thus indicating that the unit is heating up.
- Page 23 Turning the unit off Turn off the power using the main switch. Transport the device only when it is completely cooled down. To avoid leaking fog fluid during transport, you should transport the device only with empty fluid container. SD-300...
-
Page 24: Technical Specifications
Technical specifications Technical specifications Heater power 700 W Haze output approx. 56 m /min Fluid container capacity 1.0 l Warm-up time approx. 7…8 min Fuse 3.15 A / 250 V, fast-acting Dimensions (W × D × H) 208 mm × 525 mm × 235 mm Weight 8.9 kg hazer... -
Page 25: Troubleshooting
2. Check the connection to the remote control. 3. Switch the device off and check the hose that leads into the fluid container for flow. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. SD-300... -
Page 26: Cleaning
Cleaning Cleaning NOTICE! Possible damages caused by unsuitable cleaning agents Cleaners not approved by the manufacturer may permanently damage the unit. Only use the fog machine cleaners listed on www.thomann.de and follow their instructions for use. Clean the appliance after every 30 operating hours, or if it was not in use for a longer period of time. - Page 27 Use the CONT switch to switch the unit to continuous operation and wait until the fluid container is empty. The cleaning is completed. Turn the power off and wait until the unit is fully cooled down before you fill in fog fluid again. SD-300...
-
Page 28: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 29 Notes SD-300...
- Page 30 Notes hazer...
- Page 32 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
