Hisense
Customer Service Manual
WFN9012
WFN9012S
Series number:G75201300201

Advertisement

loading
Need help?

Need help?

Do you have a question about the WFN9012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense WFN9012

  • Page 1 Hisense Customer Service Manual WFN9012 WFN9012S Content Safety Specification Control Panel Structure Perspective Fault Codes and Test Procedure Parts Specification Wiring Diagram Series number:G75201300201...
  • Page 2 Customer Service 1. Safety: • Only use genuine spare parts during any repairs. If non-genuine parts are used the manufacturer’s guarantee will be void. The manufacturer will not accept any liability if a non-genuine spare parts is fitted, and subsequently fails, causing damage or injury. •...
  • Page 3 Customer Service Specification: Model Numbers WFN9012 WFN9012S The maximum spin speed 1200rpm The maximum wash volume 9.0kg 95° Temperature range Colour White H 850 x W 595 x D 620 Dimensions (cms) Net weight 74KG Voltage 220-240V Frequency 50Hz Fuse...
  • Page 5: Inlet System

    Customer Service 4. Structure Perspective: Door frame assembly. 4.2 Inlet system Main wash fill Main wash fill Detergent dispenser Prewash fill valve. valve. Pr ew as h f ill v alv e. valve. assembly. ispe Dispenser to Dispenser to tub hose. Dispe tub hose.
  • Page 6 Customer Service 4.3Tub 4.4 Drain system Drain hose. Dr ain pump Pump to tub hose. 4.5 Door assembly...
  • Page 7 Customer Service 5. Fault Codes and Test Procedure:...
  • Page 8 Customer Service If, before the spin, the control detects a potentially out of balanced load, during its pre spin cycle at 93 rpm, it will slow down to 45 rpm and rotate both clockwise and anti-clockwise, in an effort to redistribute the load.
  • Page 9 Customer Service Test Program. How to start the test program: Power on the washer by pressing "Power" button, select 'Spin' program, then press "Option" button twice and "Start/Pause" button twice successively within 5 sec. Display Description of the Program Flow Door lock function test.
  • Page 10 Customer Service 6 .Main part parameter: Motor 1200rpm UM Motor 220v Askoll 46l Motor type Part Number WW10542580 13.3 I Belt-ratio Nominal Voltage 220V Resistance ( at 20°C ) Stator ( full field ) 1.7750 ohms ±7% Stator ( tapped filed ) 0.8670ohms ±7% Rotor 1.9 0 ohms ±7%...
  • Page 11 Customer Service Door lock Part Number WW10371567 Nominal Voltage 230V+10%/-15% Max.6" at 20 °C Time for locking Time for unlocking Max.120" at 20 °C Drain pump Part Number WW10575776 Flow 14L/min +/-2L/min at 1.25m Input Power 220-240V Nominal Voltage Resistance 160 ohms...
  • Page 12 Customer Service Double valve Part Number WW10282207 230V AC (+6% -15%), Nominal Voltage 50Hz Nominal Power Resistance 3820 Ohm +/-10% 8 L/min ±5 % (from 1.5 Flow to 5) Pressure switch Part Number WW10612793 55 / 25mm (± Water Level 5mm) 300mm (±...
  • Page 13 Customer Service RFI-Filter Part Number W46197042378 Nominal Capacities 680µFx1+2x22µFY+20% Nominal Inductances 2x1 Mh-30+50% Nominal Discharging resistance 470K0+5%0.5W Heater Part Number WW10448715 Nominal Power 1900W Heat conductor resistance R20=25.50+5% Temperature Resistance 35.975k 9.786k 6.653k 4.608k 3.243k 2.332k 1.093k Resistance ±5.8% ±3.7% ±3.1% ±2.6% ±2.0%...

This manual is also suitable for:

Wfn9012s
