- Page 1 Go Power! Manual GP-1750 Inverter GP-3000 Inverter...
- Page 2 Go Power! Modified Sine Wave Inverter Owner’s Manual 1.0 Introduction The Go Power! Inverter series provides mobile power for dependable operation of standard appliances wherever you travel. Silent, lightweight, and simple to use, Go Power! Inverters can be used in a wide range of applications including RVs, boats, and light and heavy duty truck applications.
-
Page 3: Specifications
Go Power! Modified Sine Wave Inverter Owner’s Manual 2.0 Specifications GP-1750 Inverter Specification Values Continuous Output Power 1500 W Surge Rating 2100 W Output Waveform Modified Sine Wave Output Voltage±10% 115 VAC RMS Output Frequency±1% 60Hz Input Voltage 10.5 to 15 V DC ≥87%... - Page 4 Go Power! Modified Sine Wave Inverter Owner’s Manual GP-3000 Inverter Specification Values Continuous Output Power 3000 W Surge Rating 6000 W Output Waveform Modified Sine Wave Output Voltage±10% 115 VAC RMS Output Frequency±1% 60Hz Input Voltage 10.5 to 15 V DC ≥87% Maximum Efficiency ≥82%...
- Page 5 Go Power! Modified Sine Wave Inverter Owner’s Manual 3.0 Features Front view – GP-1750 AC outlet: Outlet sockets available: North America Bar graph meters: Displays the battery voltage and current. Current should be in the green zone for continuous operation. The inverter will operate for several minutes when the current is in the yellow zone.
- Page 6 Go Power! Modified Sine Wave Inverter Owner’s Manual Rear view – GP-1750 Cooling fan: Do not obstruct, allow at least 1 inch (2.54 cm) for air flow. DC Power input terminal: Black: Negative DC Power input terminal: Red: Positive Chassis ground lug: Connect the chassis ground to an earth ground or to vehicle chassis using #8 AWG wire.
- Page 7 Go Power! Modified Sine Wave Inverter Owner’s Manual Front view – GP-3000 Figure of front view of the GP-3000. Remote control connection: Bar graph meters: Displays the battery voltage and current. Current should be in the green zone for continuous operation. The inverter will operate for several minutes when the current is in the yellow zone.
- Page 8 Go Power! Modified Sine Wave Inverter Owner’s Manual Rear view – GP-3000 Figure of rear view of the GP-3000. DC Power input terminal: Red: Positive. Suggested Hardware: 5/16” DC Power input terminal: Black: Negative. Suggested Hardware: 5/16” Cooling fan: Do not obstruct, allow at least 1 inch (2.54 cm) for air flow. Chassis ground lug: Connect the chassis ground to an earth ground or to vehicle chassis using #8 AWG wire.
-
Page 9: Installation
The inverter should be located within 10 ft (3 m) of the batteries. Connecting and testing The following section describes how to connect and test the GP-1750 and GP-3000 inverters. A reverse polarity connection will permanently damage the inverter. -
Page 10: Dc Install Kits
RMS meter must be used for accurate readings. DC Install Kits Go Power! DC Installation Kits include everything you will need to properly connect your Go Power! Inverter to the batteries. GP-1750 – GP Install Kit 3 GP-3000 – GP Install Kit 5... -
Page 11: Inverter Fuse
*It is recommended that the cable length not exceed 10 ft (3 m). Inverter Fuse A class “T” inverter fuse should be included in all installations. GP-1750 – 200 A fuse GP-3000 – 400 A fuse Grounding Do not install the power inverter in a positive ground DC system. A positive ground DC system has the positive terminal of the battery connected to the chassis of the vehicle or to a grounding point. - Page 12 Go Power! Modified Sine Wave Inverter Owner’s Manual *Installation using two 12 V batteries in parallel. 12 V 12 V GP Inverter Fuse Fuse * Installation using two 6 V batteries in series. GP Inverter * Installation using two 6 V batteries.
-
Page 13: Operation
Go Power! Modified Sine Wave Inverter Owner’s Manual 5.0 Operation To operate the power inverter, turn it on using the ON/OFF switch on the front panel. The power inverter is now ready to deliver AC power to your loads. If you are operating several loads from the power inverter, turn them on separately, one after another. -
Page 14: Input Voltage
Go Power! Modified Sine Wave Inverter Owner’s Manual Input voltage The Power Inverter will operate from input voltage ranging 10.5 V – 15 V. If the voltage drops below 10.7 V, an audible low battery warning will sound and the voltage indicator will be in the lower red zone. -
Page 15: Common Problems
Go Power! Modified Sine Wave Inverter Owner’s Manual 6.0 Troubleshooting Common problems Buzz in audio systems Some inexpensive stereo systems will emit a buzzing noise from their loudspeakers when operated from the power inverter. This is due to the power supply in the device does not adequately filter the modified sine wave produced by the power inverter. -
Page 16: Maintenance
Go Power! Modified Sine Wave Inverter Owner’s Manual Problem and Symptoms Possible Cause Solution No output voltage, Error indicator Thermal shutdown. Allow inverter to cool off. Reduce on, load in excess of: load if continuous operation required. 2500 W: 210 A 1750 W: 145 A Very High Power load Remove or lessen load... - Page 17 RV Power Cord 12 V Batteries Inverter Installing the GP-1750, GP-3000, with an automatic transfer switch Battery inter-connects should be a minimum of 4 gauge. Ensure converter is turned Off when inverter is operating. To avoid hidden loads turn inverter off when power is not required.
