INSTRUCTION MANUAL

SQ9715
Sequential Power Switcher
amperes
Thank you
for choosing SQ9715, which has been a reliable product since its availability.
It is an important equipment which is suitable not only for PA system but Audio Visual installations as well. Powering of array
of equipment had been made simpler and safer, prolonging the life span of the delicate equipment such as projectors,
amplifiers etc.
Again, thank you for trusting another appliance from Amperes and experience the countless features we have to offer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SQ9715 and is the answer not in the manual?

Questions and answers

Related Manuals for Amperes SQ9715

Summary of Contents for Amperes SQ9715

  • Page 1: Instruction Manual

    It is an important equipment which is suitable not only for PA system but Audio Visual installations as well. Powering of array of equipment had been made simpler and safer, prolonging the life span of the delicate equipment such as projectors, amplifiers etc. Again, thank you for trusting another appliance from Amperes and experience the countless features we have to offer.

  • Page 2: Parts Identifications

    (noiseless) and terminate it to the port. Refer details 9. CASCADING LINK In the event 2 units of SQ9715 is used in a system, link them with this port. DIP has to be set to identify which unit is either Master or Slave. Refer Details.

  • Page 3: Application Schematic

    Repeat the same procedure to unlock. To power down, press the ON/OFF switch and system is shutting down from CH7 to CH1 in steps. Always switch off the mains if the system is not in used. Page 3 SQ9715 SEQUENTIAL POWER SWITCHER...
  • Page 4 CH.4 VISUALISER DIP SETTING CH.5 UNUSED CH.6 UNUSED CH.7 ( DELAY ACTIVE ) 1 2 3 4 5 6 7 8 9 10 LCD PROJECTOR LCD Projector connected to channel 7 with delay active Page 4 SQ9715 SEQUENTIAL POWER SWITCHER...
  • Page 5 Cascading SQ9715 2 units of SQ9715 can be linked to form a 14 channel power distribution setup. Setting has to 1~7 : CH 1 ~ CH 7 MASTER UNIT C C ASC : CH 7 DELAY be made to make one of them as Master ( Ch 1...

  • Page 6: Summary Of Features

    Channel 7 via DIP switch Delay off timer 2 minutes Switch lock Via front switch Indicators AC mains, Ch. on, Lock Dimensions (WxHxD) 482 x 44 x 180 mm Weight 2.7 kg excl. accessories Page 6 SQ9715 SEQUENTIAL POWER SWITCHER...

  • Page 7: Important Safety Instructions

    Do not allow the product to rest on or to be installed over power cords of any type. Improper installations of this type create the possibility of fire hazard and / or personal injury. SQ9715 SEQUENTIAL POWER SWITCHER Page 7...

  • Page 8: Warranty Conditions

    Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized master distributor, TNT Links Sdn Bhd / MyPA Systems Sdn Bhd.
