  • Page 1 ALL-MC301P2WIRE-T ALL-MC301P2WIRE-R QUICK INSTALLATION GUIDE...

  • Page 2: Package Content

    Package Content  1x ALL-MC301P2WIRE Converter  1x 2 Pin Terminal Block (WJ15EDGK)  1x 2 Pin Terminal Block (WJ2EDG)  Quick Start Guide Hardware Description Transmitter Receiver © ALLNET GmbH Computersysteme 2016 – All rights reserved Errors and changes reserved...

  • Page 3: Connecting To Power

    Connect the Ethernet cable from your Ethernet switch or similar equipment to the Ethernet port (10/100) of the receiver. If the cable is properly connected, the SPD/ACT LED of the Ethernet port of the receiver will be lit. © ALLNET GmbH Computersysteme 2016 – All rights reserved Errors and changes reserved...
  • Page 4 © ALLNET GmbH Computersysteme 2016 – All rights reserved Errors and changes reserved...

  • Page 5: Power Connector

    The power supply should be able to deliver a minimum of 50W with a voltage of 48~57VDC. A compatible power supply would be ALLNET Art. 119067 (55V / 2A). For more options please consult your dealer. © ALLNET GmbH Computersysteme 2016 – All rights reserved...
  • Page 6 Dimensions Drawing of the Product (Unit: mm) © ALLNET GmbH Computersysteme 2016 – All rights reserved Errors and changes reserved...

  • Page 7: Functional Description

     Data Rate up to: 90Mbps (Downlink), 90Mbps (Uplink)  Max.Distance: 400m over Twisted pair cable (26AWG)  Accept 48VDC external power input or PoE power input from RJ45 port (Receiver side) © ALLNET GmbH Computersysteme 2016 – All rights reserved Errors and changes reserved...

  • Page 8: Safety Warnings

     Do not obstruct the ventilation slots on the device. ALLNET GmbH Computersysteme declares that the devices ALL-MC301P2WIRE-T and ALL-MC301P2WIRE-R are in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC or 2014/30/EU. The Declaration of conformity can be found under this link: www.allnet.de/downloads.html...
