Chapter 2
Hardware
2.1 General Overview
♦ USB 2.0 Interface and 802.11 n chipset-on-board design.
♦ Antenna: 2 external Antennas on board
2.2 Hardware Architecture
Broadcom 43236 single chip USB2.0
2.3 Main Chipset Information
♦ BCM43236 is a dual band IEEE 802.11n-compliant MAC/PHY/Radio complete system
on a chip with 2.4Ghz and 5GHz internal PA
2.5 Net Weight : 13g
2.6 PCB dimension
PCB dimension : 16x52mm
WN8522D 7-JU
5
