Summary of Contents for Lezyne MINI
- Page 2 However, there is no guarantee that interference will not occur in a particular Lezyne is a trademark of Lezyne USA, Inc. and registered both in the United States and installation. If this equipment does cause harmful interference to radio or television...
- Page 3 In no event shall Lezyne be liable for incidental or consequential damages for any traffic fines or citations, relating to or resulting from the use of this product or any of its parts. Lezyne assumes no liability for any accident, injury, death, loss, or other claim related to or resulting from the use of this product.
-
Page 4: Table Of Contents
– Reset Odo (Odometer) – Mapping • Info page.38 – Strava and Strava Live Segments – Device – Lezyne Track – Firmware • Sensor Pairing page.27 – – Heart Rate Monitor Set up – Sats – Speed Monitor Set up •... -
Page 5: Getting Started Page.5
Getting Started Buttons Press for Back button function Hold for 2 seconds to turn ON/OFF the device Press to Scroll left through pages ENTER Press to ENTER a selection in the menu screen Press to turn Backlight ON/OFF MENU Hold to access the MENU screen Press to move UP in the menu screen Press to Scroll right through pages Press to start a ride... -
Page 6: Screen Icons
Getting Started Menu and Pause Screen Button Functions Back Press Hold Select Down Screen Icons Lezyne Track GPS Status Battery Status Power Sensor Phone Connection Heart Rate Sensor Sensor Status Cadence Sensor Speed Sensor Shifting Sensor... - Page 7 Getting Started Charging Before using your Lezyne GPS device for the first time, fully charge battery and it is also recommended to visit lezyne.com/gpsroot and update your GPS device to the latest software. 1. Remove exterior moisture. 2. Open USB cover.
-
Page 8: Turning On Gps
Getting Started Turning on the GPS Turn on your GPS by holding the left button. Press and hold for 2 seconds to turn on GPS Satellite Signal Before a ride can start there must be status of a GPS signal present. This can take 30 to 90 seconds. -
Page 9: Starting A Ride
Getting Started Starting a Ride 1. Wait for a GPS signal. 2. Start recording by pressing the bottom right button. 3. Ride data is recorded when the timer is running. A recording indicator will blink in the upper right corner 4. -
Page 10: Uploading A Ride To Your Computer
2. Connect your Power or Super GPS to a computer via Micro USB cable. 3. The GPS will read like a USB drive with included folders. 4. Within the Lezyne GPS folder find your .Fit ride files in the Activities folder to upload and share at www.lezyne.com/gpsroot... -
Page 11: Menu Options
Menu Options Menu Screen Hold the top right button to enter the MENU screen Menu options include: • Alert • Personal • Screen • Auto • Records • Time • Bike • Phone • Info • Personal • Navigation • Strava* •... -
Page 12: Screen Set Up Page
Screen Set up Page Setup There are three display options for each page: • 2 Lines of Data • 3 Lines of Data • 4 Lines of Data To change the Layout, 1. Scroll up or down to the page number you want to change and press the left ENTER button. - Page 13 Screen Set up Data Selection Display In Fields you can choose what data metrics to display on each data line. Move Up or Down to the line you want to change and Press ENTER. Scroll Up or Down to make the change and Press ENTER. Adjustable Data Distance Calories...
-
Page 14: Brightness (Backlight)
Screen Set up Units Format Display In Units you can choose between Miles or Kilometer format. Press ENTER and toggle up or down, press ENTER to select the setting. Brightness Display In Brightness you can choose what percentage of light that is displayed from the backlight. -
Page 15: Time Set Up Page.16
Screen Set up Notification Display In Notification you can choose what font size is used to displayed phone notifications. Press ENTER and use the right buttons to select size. Use the ENTER button to make the selection. Time Set up Time Format Time Format adjusts time display from 12hr to 24hr format. -
Page 16: Time Zone
Time Set up Time Zone Time Zone adjusts time based on your closest location. Press ENTER and use the right buttons to select. Press ENTER to make the selection. Daylight Savings Daylight Savings adjusts time accordingly if it applies to your location. Press ENTER and use the right buttons to select. -
Page 17: Phone Pairing Page.17
ENTER, this will make the device visible to the phone. 5. The GPS Ally App will show the Lezyne device you are looking to pair. Select the device and a pop up should ask if you want to Pair. Select Pair. -
Page 18: Notification Set Up
Phone Pairing Notifications Set up When the Lezyne GPS devices are paired with the Lezyne GPS Ally App v2 they can display Text, Email, and Call Notifications. * To enable this feature you must first make sure your phone notifications are turned on for Text and Email. -
Page 19: Navigation
Navigation Navigation Set up When the Lezyne GPS devices are paired with the Lezyne GPS Ally App v2 they work together to display Turn by Turn directions. In the Lezyne GPS Ally App v2, on the Navigation tab, you can search •... - Page 20 The Lezyne GPS devices are capable of communicating your location to the Lezyne GPS Ally App v2 to assist in navigation. If you were to get off course an automatic Rerouting would take place within the Lezyne GPS Ally App v2 that would send new directions to your GPS device.
- Page 21 Navigation Navigation GPS Root In the Lezyne GPS Root website, on the Routes tab, you can create Routes. Routes can be based on Cycling, Hiking/Walking, or Driving specifics. Lezyne GPS Root • Saved Route can be accessed from the Lezyne Ally and pushed to GPS devices for Turn by Turn directions.
-
Page 22: Mapping
Mapping Breadcrumb Mapping Once set to record, the Lezyne GPS will record a Breadcrumb Map displaying where you have been. 1. Press the lower right record button and the breadcrumb map will begin to display. Route Mapping When Navigation is being used, a Route Map will show the start, finish, and real... - Page 23 Strava Sync Strava Sync Set up In the Lezyne GPS Root website or in the Lezyne GPS Ally App v2, you can sync your activites to Strava, the popular social network. Strava.com Activites can be set to Sync automatically when uploaded or one at a time While in the Ally App set your account to sync with Strava simply by login through the Settings tab in the Ally App and GPS Root website.
- Page 24 Strava Sync Strava Sync Set up Lezyne GPS Root Sync 1. Click on Settings to Sync with Strava. 2. Click on Connect with Strava button. 3. You’ll be asked to log into to Strava. 4. And then a page will appear to confirm the connection. Click on Authorize to confirm.
- Page 25 Strava Segments Strava Segments Set up *STRAVA Premium Membership Needed* In the Lezyne GPS Root website or in the Lezyne GPS Ally App v2, you can sync Strava Segments from the popular social network. strava.com/premium While in the GPS Root or Ally App set your account to sync with Strava simply by login through the Settings tab in the Ally App and GPS Root website.
-
Page 26: Lezyne Track
3. Turn on Lezyne Track. 4. Type in or search through your contacts to add people to your email contact list 5. Once you hit record on your Lezyne GPS a notice will be sent to the people in your selected contact list. -
Page 27: Sensor Pairing Page.27
Sensor Pairing Sensor Set up The Lezyne Mini and Macro GPS can pair with only Bluetooth Smart or LE Heart Rate Monitors. The Micro, Micro C, and Super GPS can pair to both Bluetooth® and ANT+™ Before you pair your Sensors, see the manufactures instructions on how to pair with devices. -
Page 28: Power Monitor Set Up
Sensor Pairing Power Monitor Set up * Before you pair your Power monitor, see the manufactures instructions on how to set up, pair, and calibrate the monitor with devices. 1. In Power, press ENTER to Pair. The device will search for Power sensors in range. *This could take a couple minutes* 2. -
Page 29: Wheel Size And Circumference
Bike Set up Wheel Circ (Circumference) Set up Wheel Circumference calibrates the speed sensor to accurate display your speed based on the size of your wheel. This is needed if using a speed sensor on an indoor trainer. *Paired Speed Sensors will take over recording speed and distance and no longer use information from the GPS. -
Page 30: Personal Set Up Page.27
Personal Set up Sport Type Sport Type gives you the option to choose what best suits your type or activity and how it should be categorized for downloads. Press ENTER and use the right buttons to select. Press ENTER to make the selection. -
Page 31: Weight
Personal Set up Age Setting Setting your age assists in calorie calculations. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK or press the BACK button Weight Setting Setting your weight assists in calorie calculations. -
Page 32: Height
Personal Set up Height Setting Setting your Height assists in calorie calculations. Press ENTER and use the right buttons to INCREASE or DECREASE. Use the ENTER button to make the selection. Gender Setting Setting your gender assists in calorie calculations. Set your gender to Male or Female. Press ENTER and use the right buttons to select. -
Page 33: Auto/Preset Notification Set Up Page.30
Auto/Preset Notification Set up Scroll Setting Automatic Scroll through the pages on the device while recording. Press ENTER and use the right buttons to select On or Off. Press ENTER to make the selection. Start/Stop (Pause) Setting The Pause setting is an automatic Start/Stop feature that controls recording of the ride if you stop for a period of time. -
Page 34: Light (Backlight)
Auto/Preset Notification Set up Lap Preset Notification Set up Lap preset allows you to set a notification pop up based on Time or Distance goals and stores the data in your .fit file. Press ENTER and use the right buttons to select Time or Distance. Press ENTER to make the selection and use the right buttons to INCREASE or DECREASE. -
Page 35: Alert Set Up Page.32
Alert Set up Ride Distance Alert Set up Ride Distance alert gives you a pop up alert when you complete a set distance goal. Press ENTER and use the right buttons to INCREASE or DECREASE. When done press the ENTER button. To reset, select Off and repeat the steps for set Ride Time Alert Set up Ride Time alert gives you a pop up alert when you complete a set a goal for an amount of time. - Page 36 Alert Set up Calories Alert Set up Calories alert gives you a pop up alert when you complete a set goal. Press ENTER and use the right buttons to INCREASE or DECREASE. When done press the ENTER button. To reset, select Off and repeat the steps for set up. Minimum HR (Heart Rate) Alert Set up Minimum Heart Rate alert gives you a pop up alert when you hit a set minimum limit.
- Page 37 Alert Set up Maximum HR (Heart Rate) Alert Set up Maximum Heart Rate alert gives you a pop up alert when you hit a set maximum limit. Press ENTER and use the right buttons to INCREASE or DECREASE. When done press the ENTER button.
-
Page 38: Erase All
Records Review Review lets you see the details of stored rides on the device. Press ENTER and use the right buttons to select the ride you want to see by date and time. Press ENTER to make the selection. Erase All Erase All will delete all rides recorded and stored on the device. -
Page 39: Erase Oldest
Records Erase Oldest Erase Oldest will delete the oldest ride recorded and stored on the device. This is for when you need to room for recording and know the oldest file is not important but want to keep other rides. Press ENTER and use the right buttons to select Yes or No. -
Page 40: Reset Trip 1
Records Reset Trip 1 This allows you to delete the recorded distance in Trip 1. Press ENTER and use the right buttons to select Yes or No. Press ENTER to make the selection. Reset Trip 2 This allows you to delete the recorded distance in Trip 2. Press ENTER and use the right buttons to select Yes or No. -
Page 41: Reset Odo (Odometer)
Reset Odo (Odometer) This allows you to delete the accumulated miles on the Odometer. Press ENTER and use the right buttons to select Yes or No. Press ENTER to make the selection. Info Device This indicates the device type. Firmware The numbers in Firmware indicates which version is currently being used on the device. - Page 42 Info This is where you can select the GPS chip to run GPS or GPS+Glonass. GPS only offers a longer runtime on the battery. GPS+Glonass gives optimum satellite reception. *GPS+Glonass is available on Super GPS and Micro C GPS devices. Sats (Satellites) This is the current number of satellites the device is using.
- Page 43 Info HDOP, VDOP This is the quality of the GPS data. Horizontal Dilution of Precession. Vertical Dilution of Precession. Battery The current battery voltage.
- Page 44 Info FCC ID FCC certification number for the device Industry Canada certification number The three existing compliance marks (C-Tick, A-Tick and RCM) are being consolidated into a single compliance mark—the RCM Bluetooth LE Software version of Bluetooth LE ANT+™ Software version of ANT+™...
- Page 45 Specifications Battery Type Rechargeable Lithium polymer, 900 mAhr Battery Life Up to 22hrs Memory Size Up to 200hrs (Power GPS) Up to 400hrs (Super GPS) Operating Temperature Range -20⁰C to 60⁰C (-4⁰F to 140⁰F) Charging Temperature Range 0⁰C to 45⁰C (32⁰F to 113⁰F) Water Rating IPX7 *tested in water 1m for 30min Weight...
-
Page 46: Data Metrics Explained Page.42
Data Metrics Explained Ascent: The total measurement of elevation gained that current *Power - 10s Power: A 10 second average output of watts ride *Power - 3s Power: A 3 second average output of watts Auto Scroll: Page scroll changes to show different information. *Power - L/R % Smoothness: The measure of how evenly power Example: Avg Speed, Elevation, Temperature is being applied to the left and right through the pedal stroke... -
Page 47: Troubleshooting
*Resetting the device could delete settings and files • Hold ENTER and MENU for 45 seconds • The device will shut off • Hold for 2 seconds to turn device back on 2015 © Lezyne USA, Inc. All rights reserved...
