Summary of Contents for Lezyne Mini GPS
- Page 2 It is important that you use compliant peripheral devices and shielded Lezyne is a trademark of Lezyne USA, Inc. and registered both in the United States and cables between system components to reduce the possibility of causing interference to internationally Any unauthorized use is expressly prohibited radios, televisions, and other electronic devices.
- Page 3 In no event shall Lezyne be liable for incidental or consequential damages for any traffic fines or citations, relating to or resulting from the use of this product or any of its parts. Lezyne assumes no liability for any accident, injury, death, loss, or other claim related to or resulting from the use of this product.
-
Page 4: Table Of Contents
• Table of Contents Auto/Preset Notification Set up – • Scroll Getting Started – Pause – Buttons – – Screen Icons – Light (Backlight) – Charging GPS • – Alert Set up Installing GPS – – Turning on GPS Ride Distance –... -
Page 5: Getting Started
Getting Started Buttons ENTER Hold for 2 seconds to turn ON/OFF the device Press to ENTER a selection in the menu screen During a ride, Press to turn Backlight ON/OFF MENU Hold to access the MENU screen Press to move UP in the menu screen During a ride, Press to Scroll bottom data line Press to start a ride Hold to end a ride... -
Page 6: Screen Icons
Getting Started Menu and Pause Screen Button Functions Press Hold Select Down Screen Icons GPS Status Battery Status... - Page 7 Getting Started Charging Before using your Lezyne GPS device for the first time, fully charge battery lezyne.com/gpsroot/gps_downloads.php and it is also recommended to visit and update your GPS device to the latest software. 1. Remove exterior moisture 2. Open USB cover 3.
-
Page 8: Turning On Gps
Getting Started Turning on the GPS Turn on your Mini GPS by holding the left button. Press and hold for 2 seconds to turn on GPS Satellite Signal Before a ride can start there must be a GPS signal present. This can take 30 to 90 seconds. -
Page 9: Starting A Ride
Getting Started Starting a Ride 1. At least 1 GPS status dots will fill solid when ready. 2. Start recording by pressing the bottom right button. 3. Ride data is recorded when the timer is running 4. Press to see other ride metrics Press to start recording a ride Ending a Ride... -
Page 10: Uploading A Ride To Your Computer
2. Connect your Mini GPS to a computer via Micro USB cable. 3. The GPS will read like a USB drive with included folders 4. Within the Lezyne GPS folder find your .Fit ride files in the Activities folder to upload and share at www.lezyne.com/gpsroot... -
Page 11: Screen Set Up
Screen Set up Menu Screen Hold to enter the MENU screen Layout Display There are three display options. • 2 Lines of Data • 3 Lines of Data • 4 Lines of Data The layouts can change but the display fields are set. To change the Layout, 1. - Page 12 Screen Set up Fields Display In Fields you can choose what data metrics to display on the bottom data line Press ENTER to make it Hidden or Visible. Standard data is always visible. Adjustable Data Trip 1 Trip 2 Ascent Descent Avg Speed Max Speed...
-
Page 13: Brightness (Backlight)
Screen Set up Brightness Display In Brightness you can choose what percentage of light is displayed from the backlight. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK. -
Page 14: Time Zone
Time Set up Time Zone Time Zone adjusts time based on your closest location. Press ENTER and use the right buttons to select. Press ENTER to make the selection. Daylight Savings Daylight Savings adjusts time accordingly if it applies to your location. Press ENTER and use the right buttons to select. -
Page 15: Personal Set Up
Personal Set up Sport Type Sport Type gives you the option of ROAD or MOUTAIN to choose what best suits your type riding and how it should be categorized for downloads. Press ENTER and use the right buttons to select. Press ENTER to make the selection. - Page 16 Personal Set up Age Setting Setting your age assists in calorie calculations. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK. Weight Setting Setting your weight assists in calorie calculations. Press ENTER and use the right buttons to select INCREASE or DECREASE.
- Page 17 Personal Set up Height Setting Setting your Height assists in calorie calculations. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK. Gender Setting Setting your gender assists in calorie calculations. Set you gender to Male or Female. Press ENTER and use the right buttons to select.
- Page 18 Auto/Preset Notification Set up Scroll Setting Automatic Scroll set for the bottom data line. Press ENTER and use the right buttons to select On or Off. Press ENTER to make the selection Start/Stop (Pause) Setting The Pause setting is an automatic Start/Stop feature that controls recording of the ride if you stop for a period of time.
-
Page 19: Light (Backlight)
Auto/Preset Notification Set up Lap Preset Notification Set up Lap preset allows you set a notification pop up based on Time or Distance goals. Press ENTER and use the right buttons to select Time or Distance. Press ENTER to make the selection. Press ENTER and use the right buttons to select INCREASE or DECREASE. -
Page 20: Alert Set Up
Alert Set up Ride Distance Alert Set up Ride Distance alert gives you a pop up alert when you complete a set distance goal. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK. To reset, select Off and repeat the steps for set up. -
Page 21: Records
Alert Set up Calories Alert Set up Calories alert gives you a pop up alert when you complete a set goal. Press ENTER and use the right buttons to select INCREASE or DECREASE. Use the ENTER button to make the adjustments. When done select BACK. To reset, select Off and repeat the steps for set up. -
Page 22: Erase Oldest
Records Erase Oldest Erase Oldest will delete the oldest ride recorded and stored on the device. This is for when you need to room for recording and know the oldest file is not important but want to keep other rides. Press ENTER and use the right buttons to select Yes or No. -
Page 23: Reset Trip 1
Records Reset Trip 1 This allows you to delete the recorded miles in Trip 1. Press ENTER and use the right buttons to select Yes or No. Press ENTER to make the selection Reset Trip 2 This allows you to delete the recorded miles in Trip 2. Press ENTER and use the right buttons to select Yes or No. -
Page 24: Reset Odo (Odometer)
Records Reset Odo (Odometer) This allows you to delete the accumulated miles on the Odometer. Press ENTER and use the right buttons to select Yes or No. Press ENTER to make the selection Info Device This is a code used for device support. -
Page 25: Firmware
Info Firmware The numbers in Firmware indicates which version is currently being used on the device. This is where you can reset the GPS chip. A GPS chip reset is good if you travel to other countries and find the device to be slow to gain satellite signal. Warm Start, resets the GPS chip and will reconnect to satellites quickly. -
Page 26: Sats
Info Sats This is the current number of satellites the device is using. HDOP, VDOP This is the quality of the GPS data. Horizontal Dilution of Precession. Vertical Dilution of Precession... - Page 27 Info Battery The current battery voltage. The three existing compliance marks (C-Tick, A-Tick and RCM) are being consolidated into a single compliance mark—the RCM...
-
Page 28: Specifications
Specifications Battery Type Rechargeable Lithium polymer, 290 mAhr Battery Life Up to 10hrs Memory Size Up to 100hrs Operating Temperature Range -20⁰C to 60⁰C (-4⁰F to 140⁰F) Charging Temperature Range 0⁰C to 45⁰C (32⁰F to 113⁰F) Water Rating IPX7 *tested in water 1m for 30min Weight Data Metrics Explained Speed: The current rate of speed... -
Page 29: Troubleshooting
Troubleshooting Updating Software http://www.lezyne.com/gpsroot/gps_downloads.php Software updates/manuals can be found at 1. Connect your device to your computer with the supplied USB cable 2. Go to the GPS Root website Download page and choose the software update that works with your computer 3.
