- Page 1 WholeFruit SlowJuicer INSTRUCTION MANUAL www.fridja.com...
-
Page 3: Introduction
Fridja f1800 INTRODUCTION Thank you for purchasing this Fridja f1800 slow juicer! This product has been designed and manufactured to give you years of trouble free service. Please take time to read these instructions prior to use - they have been written to ensure you get the very best from your purchase. -
Page 5: Table Of Contents
Fridja f1800 CONTENTS INTRODUCTION ............3 SPECIFICATIONS . -
Page 6: Important Safeguards
WholeFruitSlowJuicer IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: Read all instructions. 2. To protect against risk of electrical shock do not put motor or base of unit in water or other liquid. 3. -
Page 7: Safety Warning
Fridja f1800 SAFET Y WARNING Unplug the power cord when not in use. Use a dry towel to clean the power cord. Do not keep or operate the appliance near Do not put the juicer parts in the infants or toddlers. -
Page 8: Parts
WholeFruitSlowJuicer PARTS 1. Feeding Tube 2. Drum Lid 3. Juicing Bowl 4. Pulp Jug 5. Anti Drip Cap 6. Base 7. Juice Jug 8. Rotation Wiper 9. Strainer 10. Auger 11. Pusher 12. Cleaning Brush... - Page 9 Fridja f1800 Align the dots STEP 1 Top-set Assembly Align the red dots on each part and assemble in the order shown. Once assembled, turn the drum lid clockwise to close. STEP 2 Top-set and base assembly Place the bowl on the base so that...
-
Page 10: How To Assemble
WholeFruitSlowJuicer HOW TO ASSEMBLE STEP 1 Top-set Assembly Wash the parts before first use. Check Before Ensure that the silicone lip and silicone ring are assembled Operating properly. Firmly insert the silicone lip into the slot below the pulp spout. The Juicer may leak if not assembled properly. - Page 11 Fridja f1800 Place the drum lid on to the juicing bowl aligning the red dot on the drum lid with the red dot on the juicing bowl. Turn clockwise to close, aligning the red dot on the drum lid with the closemark.
- Page 12 WholeFruitSlowJuicer Open/Close mark on the top-set. Juicer will not operate if parts are not assembled properly. Place the pulp jug under the pulp spout and place the juice jug under the juice spout as shown in the illustration.
-
Page 13: Tips On Operation
Fridja f1800 TIPS ON OPERATION STEP 1 After preparing the ingredients, plug the power cord into a wall outlet. Do not touch the power cord with wet hands. It may cause electrical shock, short-circuit, or fire. Note Check the safety of the wall outlet. -
Page 14: How To Operate
WholeFruitSlowJuicer HOW TO OPERATE STEP 3 Insert the prepared ingredients one piece at a time. Fibrous leafy vegetables (celery, kale, etc.): Separate each stem. Cut the outer stems that are thick and tough to 4 inches long or less. ... - Page 15 Fridja f1800 STEP 5 After juice and pulp are completely extracted, switch the unit OFF. If the remaining ingredients in the juicing bowl have not been extracted completely, the drum lid may not open easily. After each extraction, run the juicer for an additional 30 seconds to let the juicer extract the remaining pulp.
- Page 16 WholeFruitSlowJuicer TIPS ON OPERATION 1. Operating the juicer without ingredients can cause damage to the screw. 2. Do not continuously operate the juicer for more than 30 minutes. This can damage the motor from overheating. After continuous use, let the juicer rest for 30 minutes to cool down before starting another session.
-
Page 17: Tips On Ingredients
Fridja f1800 TIPS ON INGREDIENTS Juicer damage due to owner negligence or from not following the instructions in the owner’s manual will void the warranty service. DO NOT put the following ingredients into the juicer: Peach, nectarines, apricot, plum, mango, etc. -
Page 18: Ingredients Preparation
WholeFruitSlowJuicer INGREDIENTS PREPARATION Before operating: If the juicer is jammed or if the drum lid does not open, press the REVERSE button and hold until it becomes dislodged. Before Repeat REVERSE-OFF-FORWARD as needed. Operating Continue operating the juicer until all the ingredients in the juicing bowl are extracted. - Page 19 Fridja f1800 Juicing with the anti drip tap closed allows mixed juice creations with different fruits, vegetables and liquids. After juicing, close the smart cap to block excess juice from dripping, especially when disassembling the juicing bowl off the base.
- Page 20 WholeFruitSlowJuicer Ingredients with small seeds (e.g. raspberry, pomegranate, grape): Slowly insert Ingredients with small seeds to prevent the seeds from clogging the strainer. Insert ingredients slowly to For best result, juice with minimize the amount of leftover ingredients with higher amount seeds in the strainer.
- Page 21 Fridja f1800 Fibrous and/or tough leafy ingredients (e.g. celery, kale, pineapple): Fibrous ingredients like celery and kale should be cut into small lengths before juicing. When the pulp outlet is blocked by the fibrous ingredients, press the REVERSE-OFF-FORWARD button in this order, switching back and for the 2-3 times.
-
Page 22: How To Disassemble And Clean
WholeFruitSlowJuicer HOW TO DISASSEMBLE AND CLEAN Switch OFF and unplug the power cord from the wall outlet. Note Extract all the remaining pulp in the juicing bowl before stopping the juicer. For easier clean up, operate the juicer for an additional 30 seconds after the juice is extracted. - Page 23 Fridja f1800 Remove the juicing screw/auger, strainer, and rotation wiper unit from the juicing bowl. Clean with provided brush. Note Immediately clean the juicer after each use. If remaining residue in the juicer dries up, it can make disassembling and clean-up difficult. The excess build up can cause poor performance in future uses.
-
Page 24: How To Use The Ice Cream Strainer
WholeFruitSlowJuicer HOW TO USE THE ICE CREAM STRAINER To assemble the top set, place the juicing screw and the blank strainer in the juicing bowl and close the lid. Juicing Screw 1. Insert the blank strainer into the juicing / Auger bowl while aligning the red dots of the *use the same... - Page 25 Fridja f1800 CAUTION The smoothie strainer is used only with frozen ingredients. Depending on the different ingredients, allow the frozen items to thaw for 5 to 20 minutes before use. Slowly process a smaller amount per batch. Do not use ice or process ingredients containing vegetable or animal oil.
-
Page 26: How To Use The Smoothie Strainer
WholeFruitSlowJuicer HOW TO USE THE SMOOTHIE STRAINER 1. To assemble the top-set, place the juicing screw and the smoothie strainer in the juicing bowl and close the lid. 1. Insert the rotation wiper and the smoothie strainer into the juicing bowl Juicing Screw/Auger while aligning the red dots... -
Page 27: Optional How To Use The Smoothie Strainer
Fridja f1800 CAUTION When using frozen ingredients, make sure to thaw your frozen ingredients for about 5 to 20 minutes before use. (The required period to thaw the ingredients will depend on how long the ingredients were in the freezer and the temperature it was kept in.) When making smoothies, add milk or other types of liquid between ingredients. -
Page 28: Troubleshooting Q&A
WholeFruitSlowJuicer TROUBLESHOOTING Q&A When there is no power to the juicer: Check if the power cord is properly plugged in. Check if the drum lid and the juicing bowl are properly assembled. Check if the top-set and the base are properly assembled. ... - Page 29 Fridja f1800 The drum lid will not close: Make sure the juicing screw is pushed all the way in to the strainer in order for the drum lid to close properly. If the juicing screw is not properly in position, the drum lid may not close.
- Page 30 WholeFruitSlowJuicer During juicing, the juicer stopped: Check the power cord and make sure it is plugged in correctly. Check that all the parts are correctly assembled. If too many ingredients are inserted at one time, this can cause the juicer to stop. ...
- Page 31 Fridja f1800 Is it possible to juice ingredients with tough fiber? Ingredients like celery or ginger contain long fibers that may wrap around the juicing screw and affect the juicer’s performance. When juicing fibrous ingredients, do not collect more than 3000 mm. of juice. After collecting this quantity or less, clean the top- set completely before juicing again.
-
Page 32: Plug Safety
WholeFruitSlowJuicer PLUG SAFET Y The appliance is fitted with a 13 amp plug. In the event of having to change the fuse in the plug supplied, a 13 amp ASTA approved (BS 1363) fuse must be used. Should the plug need to be replaced for any reason, proceed as described below. -
Page 33: Non Rewireable Mains Plug
Fridja f1800 NON REWIREABLE MAINS PLUG If your appliance is supplied with a non-rewireable plug fitted to the mains lead and should the fuse need replacing, you must use an ATSTA approved one (conforming to BS1362) of the same rating. If in doubt, consult a qualified electrician. -
Page 34: Guarantee
WholeFruitSlowJuicer GUARANTEE This guarantee is applicable for goods bought directly from Fridja. If you purchased your juicer from another vendor, please contact them. If by chance you are unhappy with your purchase, please contact us within seven days of delivery for a refund. Returned items must be in unused condition with all supplied Fridja accessories and packaging. - Page 35 Fridja f1800 To arrange the return of your item please contact: info@fridja.com. This guarantee is subject to the following provisions: The product must be correctly installed and operated in accordance with the instructions contained in these operating instructions. This guarantee does not cover accidental damage or misuse.
- Page 36 FRIDJA LTD. 82 LOWER CLAPTON ROAD, LONDON, E5 0RN, UNITED KINGDOM. www.fridja.com...
