- Page 1 StretcherPro-HD User Manual HDMI/DVI-D 2x2 Video Wall Controller Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131...
-
Page 2: Table Of Contents
FRONT PANEL CONTROL RS-232 CONTROL IR REMOTE CONTROL CONTROL VIA ETHERNET LIMITED WARRANTY STATEMENT WHAT'S IN THE BOX? PART NO. DESCRIPTION STRP-HDS StretcherPro-HD CCPWR06 Power supply cord RMT-4KWL IR Remote Control SM-EYE-NY IR receiver EN-QKVM-EAR-P Rack Mounting Brackets Quick Start Guide... -
Page 3: Introduction
INTRODUCTION To create a four-screen video wall with 1 HD video input, the StretcherPro-HD Video Wall Controller pro- vides a truly simple plug-and-play hardware solution. The StrecherPro-HD is HDCP compliant and is capa- ble of stretching any HD source over four screens, resolution up to 1920 x 1080. This powerful new ver- sion stretches the video image in multiple ways including: Video Wall mode, dual horizontal (2x1), dual vertical (1x2), or clone the image (1:1). -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS VIDEO Video Bandwidth Single-link 340MHz [10.2Gbps] Resolution HDTV Up to 1080p PC Resolution up to 1920 x 1200 Input Video Signal 1.2 volts Input DDC Signal 5 volts Single Link Range 1080p Format HDMI DVI Compliance Single-link DVI-D 2.0 Output Cable Length Up to 20 ft. -
Page 5: Hardware Installation
1, the upper right display to port 2, the lower left display to port 3 and the lower right display to port 4. Connect the IR receiver to the IR input jack at the back of the StretcherPro-HD. Optionally connect an RS-232 cable from the PC to the RS-232 port of the unit for additional control. -
Page 6: Front Panel Control
FRONT PANEL CONTROL Front Panel Buttons To switch to Video Wall mode, press the WALL button. To switch to Clone mode, press the CLONE button. To switch to Dual Horizontal mode, press the DUAL H button. To switch to Dual Vertical mode, press the DUAL V button. -
Page 7: Rs-232 Control
USB to RS-232 adapter. Check the RS-232 connections on your computer and the StretcherPro-HD to determine if you need a male to male, female to female or male to female cable. Establish a connection to StretcherPro-HD : 1. -
Page 8: Ir Remote Control
IR REMOTE CONTROL BUTTON DESCRIPTION MENU Activates the OSD menu CLONE Exit OSD menu ▲ Navigate up thru the OSD options ▼ Navigate down thru the OSD options ■ Select or execute ◄ Navigate OSD options ► Navigate OSD options INPUT OUTPUT Internal EDID #1... -
Page 9: Control Via Ethernet
CONTROL VIA ETHERNET StretcherPro‐HD TCP/IP control is a feature that allows mode switching and other configurations to be con‐ trolled remotely via HTTP. Manage your StretcherPro‐HD with ease on your LAN or from anywhere in the world. First you must find the IP address for the StretcherPro‐HD . Finder.exe (Smart IP‐ Finder) is conveniently available on our web‐ site; please visit www.smartavi.com/helpful‐ links.html for this and our full list of com‐ patible third‐party software. Download and execute the IP address Finder software for your product. The StretcherPro‐ HD and its IP address should appear in the display as shown in Figure 9‐1. Figure 9‐1 ... -
Page 10: Limited Warranty Statement
LIMITED WARRANTY STATEMENT A. Extent of limited warranty Smart‐AVI Technologies, Inc. warrants to the end‐user customers that the Smart‐AVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. Smart‐AVI limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. Improper or inadequate maintenance or modifications b. Operations outside product specifications c. Mechanical abuse and exposure to severe conditions If Smart‐AVI receives, during applicable warranty period, a notice of defect, Smart‐AVI will at its discretion replace or repair defective product. If Smart‐AVI is unable to replace or repair defective product covered by the Smart‐AVI warranty within reasonable period of time, Smart‐AVI shall refund the cost of the product. Smart‐AVI shall have no obligation to repair, replace or refund unit until customer returns defective product to Smart‐AVI. Any replacement product could be new or like new, provided that it has functionality at least equal to that of the product being replaced. Smart‐AVI limited warranty is valid in any country where the covered product is distributed by Smart‐AVI. B. Limitations of warranty To the extant allowed by local law, neither Smart‐AVI nor its third party suppliers make any other warranty or condition of any kind whether expressed or implied with respect to the Smart‐AVI product, and specifically disclaim implied warranties or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. C. Limitations of liability ... - Page 11 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no war‐ ranty of any kind with regard to this material, including but not limited to, implied warranties of merchant‐ ability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for inci‐ dental or consequential damages in connection with the furnishing, performance or use of this material. No part of this document may be photocopied, reproduced, or translated into another language without prior written consent from SmartAVI Technologies, Inc. 20160823 ...
