Summary of Contents for Smart-M StretcherPro-HD
- Page 1 StretcherPro-HD HDMI/DVI-D 2x2 Video Wall Controller The ideal video wall controller and video matrix hardware solution with On Screen Display and stunning 4K resolution, no software required Installation Manual...
-
Page 2: Table Of Contents
USING RS-232 CONTROL 9-11 FIRMWARE UPDATE LIMITED WARRANTY STATEMENT What’s in the Box? PART NO. QTY DESCRIPTION STRP-HDS StretcherPro-HD: Expand any HDMI source among 4 HD screens in Multi-layout. Power supply cord (CCPWR06) RS-232 Cable RS-232 (male-to-female) SRC-2A IR Remote Control... -
Page 3: Technical Specifications
Technical Specifications VIDEO Video Bandwidth Single-link 340MHz [10 2Gbps] Resolution HDTV 480i,480p,720i,720p,1080i,1080p PC Resolution 800 x 600 up to 1920 x 1200 Input Video Signal 1 2 volts Input DDC Signal 5 volts Single Link Range 1080p Format HDMI 1.4 DVI Compliance Single-link DVI-D 2.0 Output Cable Length... -
Page 4: Introduction / Features
Introduction To create a four-screen video wall with four HD video inputs, the StretcherPro-HD Video Wall Controller provides a truly simple plug-and-play hardware solution with incredible 4K resolution. The StrecherPro-HD is HDCP compliant and is capable of stretching any HD source over four screens, while maintaining any resolution up to 1920 x 1080 on each screen. -
Page 5: Applications
• Corporate or Educational Presentations • Airport Installations • Wall Displays • Digital Signage • Dealer Rooms • Control Rooms • Shopping Centers • Security • Point-of-Sale • Entertainment Venues • Corporate Lobbies • Restaurants StretcherPro-HD HDMI Input HDMI Output DVD Player... -
Page 6: Hardware Installation / Available Configurations
HDMI cables for HDMI monitors and TVs, or HDMI-to-DVI adapters for DVI displays. 4. Connect the IR receiver to the IR input jack at the back of the StretcherPro-HD. 5. Optionally connect an RS-232 cable from PC to the RS-232 port of the unit for additional control. -
Page 7: Control Using The Front Panel
Control Using the Front Panel Front Panel Buttons • For Menu, press the DUAL H and DUAL V buttons simultaneously. • To switch to Video Wall mode, press the WALL button. • To switch to Clone mode, press the CLONE button. • To switch to Dual Horizontal mode, press the DUAL H button. -
Page 8: Using On-Screen Display / Ir Remote Control / Osd Using Front Panel
IR Remote Control and through the Front Panel Buttons. IR Remote Control The StretcherPro-HD will only respond to the remote control unit provided in the box. Below is the list of commands on how to control using the remote control: DATA: Activates the OSD Ch. -
Page 9: Using Rs-232 Control
Establish a connection to StretcherPro-HD: 1. Connect a straight-through male-to-female RS-232 cable to the RS-232 connector on the PC. 2. Connect the other end of the cable to the RS-232 port of the StretcherPro-HD. 3. Power on the device. Setting up the Terminal Application: 1. - Page 10 There are two primary modes of operation for StretcherPro-HD: Command Mode and CLI Mode. When connecting to the StretcherPro-HD via RS-232, it will start in Command Mode. CLI Mode is a more user- friendly way of operating the StretcherPro HD and includes instructional menus. The following section details the use of the CLI Mode.
- Page 11 Dual Vertical //DV<CR> Stretch the input over two vertically ar- ranged two times over Reset //RESET<CR> Resets the StretcherPro-HD box <CR> is carriage return (0x0D). All commands sent from PC end with <CR> (or the <enter> key if using HyperTerminal).
-
Page 12: Firmware Update
Below are instructions on how to upgrade the firmware of your StretcherPro-HD: 1. Power OFF the StretcherPro-HD. 2. Connect the RS-232 cable from computer to the RS-232 port of the StretcherPro-HD. 3. Download and install the chip45boot2 GUI 4. Open the chip45boot2 GUI. - Page 13 At SmartAVI, we offer a complete line of audio/video solutions for high-quality signal switching and distribution. Our devices support multiple signal types including VGA, DVI, HDMI, USB, RS232, IR and more. EXTENDERS CAT5/5e/6 UTP/STP FIBER OPTIC COMPUTER DISPLAY EXTENDER SPLITTERS BLUERAY PLAYER SPLITTER DISPLAYS...
