  • Page 1 Owner’s Manual Email: mail@EcoTrikes.com www.EcoTrikes.com EcoTrikes...

  • Page 2: Table Of Contents

    Table of Contents Technical Information-----------------------------------1 Warning Statement--------------------------------------2 Read Before Riding-------------------------------------3 List of Parts-----------------------------------------------4 Front Bar---------------------------------------------------6 Tool Kits In The Tool Bag------------------------------7 Assembling The Multi-Point---------------------------8 Charging The Batteries-------------------------------12 Charging The Batteries Outside Scooter---------13 Riding The Multi-Point--------------------------------15 Folding The Multi-Point-------------------------------19 Maintenance---------------------------------------------21 Wiring Diagram-----------------------------------------22 Trouble Shooting Guide------------------------------24...
  • Page 3 Warranty-------------------------------------------------26 Instructions for optional attachments-------------31...

  • Page 4: Technical Information

    EcoTrikes Model No. EcoTrikes ET4 and ET6 45 L x 27 W x 44 H inch Product size (115 x 68 W x 113 cm) Permanent-magnet Type of motor brushless DC wheel motor Motor power 500 w Wheel motor, 48 V...

  • Page 5: Warning Statement

    Failure to comply with the standards outlined in the manual could result in fire and/or serious injury. EcoTrikes LLC is not liable for any damage or injuries caused by unsafe or faulty repairs. Any repairs made to this product by unauthorized service technicians are the sole responsibility of the owner.

  • Page 6: Read Before Riding

     The power switch lock must be in the “off” position when the EcoTrikes Scooter is being charged.  Do not use the EcoTrikes Scooter when it is raining.  Do not place the battery near heat or fire. ...

  • Page 7: List Of Parts

    EcoTrikes...
  • Page 8 EcoTrikes Throttle Multi-function Instrument Brake lever Alloy handlebar tub Quick release Connecting tube Seat Charger port Footboard Rear wheel Battery Power connecting plugs Allen set screw Front fender compartment Front fork Motor Front wheel Basket...

  • Page 9: Front Bar

    EcoTrikes 1 Brake lever 2 Lock mechanism switch 3 Horn switch 4 Multi-function Instrument 5 Key switch 6 USB port 7 Throttle...

  • Page 10: Tool Kits In The Tool Bag

    EcoTrikes Screwdriver Allen wrench （2.5mm） Allen wrench （3mm） Allen wrench （5mm） Allen wrench （6mm） Wrench (8 x 10mm) Wrench (16 x 18mm) Wrench (16 x 18mm) Charger...

  • Page 11: Assembling The Multi-Point

    EcoTrikes 1. Unpack the EcoTrikes scooter carefully so that you do not misplace any of the parts. 2. Place the EcoTrikes unit on a flat, level surface. Block the front up 3.5''. This will make the next step easier 3. Remove the bolts and nuts from the connecting tube clamp (B).
  • Page 12 EcoTrikes 4. The two Allen set screws on the front of the connecting clamp are for removing any play after the bolts have been tightened. First, back off the nuts, second, set the screws, third, tighten the nuts to prevent the screws from backing off.
  • Page 13 EcoTrikes align release button to pivot on brake handle side 6. Ensure that the handlebar is facing front, the brake on the left side and the throttle on the right, then tighten the handlebar tube collar clamp using the enclosed 5mm wrench.
  • Page 14 EcoTrikes NOTE: Handle bar height adjustment. Handle bar height can be easily adjusted by opening the quick release on the handlebar tube to preferred height, then firmly closing quick release.

  • Page 15: Charging The Batteries

    EcoTrikes Before you ride the EcoTrikes unit for the first ● time you must charge the batteries for 4-6 hours or until charge light turns green using only the supplied charger. To charge the batteries, plug the charger into ●...

  • Page 16: Charging The Batteries Outside Scooter

    EcoTrikes 1. Turn off the key switch Lift the floor mat. Unscrew two bolts that secure the battery cover and remove it. Unplug the battery connection plug, unlock the battery case, remove the battery, and charge using the optional external charge wire and...
  • Page 17 EcoTrikes...

  • Page 18: Riding The Multi-Point

    Once you have completed the initial charge you ● are ready to ride. Remember, this is not a toy. The EcoTrikes unit can reach speeds up to 16 mph depending on the terrain and the weight of the rider. You must wear a helmet and protective pads.
  • Page 19 EcoTrikes hand will control the throttle. As you turn the throttle towards yourself, the speed will be increased. Release the throttle and apply the brake to stop the scooter. You will control the speed of the scooter by using both the throttle and the brake.
  • Page 20 EcoTrikes NOTE 5: When you use reverse, the scooter must be stopped, and then push the reverse switch to “R”, the horn will send out a noise, then GENTLY turn the throttle to back up. Warning, do not twist throttle to full power when in reverse.
  • Page 21 5V, 2A and will charge two phones or a phone and a tablet at the same time. ET6 USB ET4 USB NOTE 6: The maximum output of the single port USB is 5V 1A which will charge all phones.

  • Page 22: Folding The Multi-Point

    EcoTrikes 1. Turn off the key switch 2. Put the clamp ring to turn to one side. 3. Press the quick release to bottom.

  • Page 23: Maintenance

    EcoTrikes 4. Lift the connecting tube (which is also attached to the handlebar tube). 5. Carefully place the handlebar tube on the footrest frame EcoTrikes Battery: (for professional use only)
  • Page 24 To prolong battery life, recharge the battery after each use. You must also charge your EcoTrikes unit if it has not been used for 30 days or more. If you need to replace the battery pack, it is located inside the battery compartment on the footboard.

  • Page 25: Wiring Diagram

    EcoTrikes...

  • Page 27: Trouble Shooting Guide

    EcoTrikes Problem Cause Solution The power light 1. Battery is 1. Recharge your on the discharged. EcoTrikes unit. instrument 2. Loose 2. Remove the does not connection screws that hold the illuminate when inside EcoTrikes battery compartment the Multi-Point unit.
  • Page 28 1. Adjust the brake lever is are not adjusted by loosening the bolt squeezed the properly. on the brake wheel, EcoTrikes unit pull the cable and does not stop. retighten the bolt. Scooter is 1. Low battery 1. Recharge your losing speed.
  • Page 29 EcoTrikes warrants the EcoTrikes unit for six (6) months according following terms. Batteries and tires are warranted for three (3) months.
  • Page 30 EcoTrikes delivering the EcoTrikes unit to the factory / authorized service dealer for warranty work or the expense of returning it back to the owner after repair/ replacement will be paid for by the owner. EcoTrikes’s responsibility in respect to claims is limited to making the required repairs...
  • Page 31 EcoTrikes products. In addition this warranty does not cover items that experience normal wear and tear. EcoTrikes reserves the right to improve the design of the product without assuming any obligations to modify any product previously manufactured.
  • Page 32 WHAT EcoTrikes WILL DO: EcoTrikes will, at its sole option, either repair, replace or refund the purchase price of any unit that does not conform to this limited warranty.
  • Page 33 EcoTrikes HOW TO GET WARRANTY SERVICE: To obtain warranty service, please call or fax to the following telephone numbers for EcoTrikes Customer Service - warranty repair Tel. 1-239-285-0580 or, Email: mail@ecotrikes.com DO NOT RETURN YOUR PRODUCT TO ANY ADDRESS. Please call, email, or write for the location of the...
  • Page 34 Instructions for optional attachments EcoTrikes Installing the optional dc to ac EcoInverter 1. Turn off the key switch 2. Remove seat post from seat 3. Install special seat post on seat 3. Put floor mat through tube...
  • Page 35 Instructions for optional attachments EcoTrikes 4. Install quick release, put wire harness through tube 5. Connect wire harness with charger port under tube 6. Install tube on scooter, put one side with hole forward, and fasten bolts...
  • Page 36 Instructions for optional attachments EcoTrikes 7. Align nipples to corresponding holes in floor deck 8. Install seat...
  • Page 37 Instructions for optional attachments EcoTrikes 9. Plug the up connector into the inverter socket, 10. When using the inverter, turn on the power switch. Inverter specification: ● Input voltage is DC 48V ● Output voltage is AC 110V 60Hz NOTE 1: Do not expose to water drip or spray.
  • Page 38 Instructions for optional attachments EcoTrikes ac outlet or vent openings. ● Do not under any circumstances. connect the inverter to power utility AC distribution wiring. ● Failure to follow the above instructions may result in personal injury or damage to the inverter.
  • Page 39 Instructions for optional attachments EcoTrikes How to install the EcoCart trailer 1. Turn off the key switch 2. Put the trailer tongue into the slot, after aligning the holes, place the two bolts through the holes. Twist the bolts, and tighten them with the nuts provided.
  • Page 40 Instructions for optional attachments EcoTrikes How to install the EcoSolarShade panel 1. Turn off the key switch 2. Put the front frame(A) and front frame (C) into the front casing (B), after aligning the holes, place the two bolts through the holes and up-clip ring(D), Twist the bolts, and tighten them with the nuts provided.
  • Page 41 Instructions for optional attachments EcoTrikes 4. Install front support (A) onto front frame(B) with the two bolts, and tighten them with the nuts provided.
  • Page 42 Instructions for optional attachments EcoTrikes 5. Install the front support (A) into the under-clip ring (B) with the two bolts, and tighten them with the nuts provided. 6. Install the rear frame onto the scooter with the two bolts, and tighten them with the nuts...
  • Page 43 Instructions for optional attachments EcoTrikes 7. Install the rear support (A) onto rear frame (B) with the two bolts, and tighten them with the nuts provided. 8. Fix the rear support and seat post with one bolt, and tighten them with the nuts provided.
  • Page 44 Instructions for optional attachments EcoTrikes 9. Fix the solar panel onto the front frames and rear frames. the rear frame the front frame 10. Connect the wiring harness well. the upper rear frame...
  • Page 45 Instructions for optional attachments EcoTrikes the lower rear frame...
  • Page 46 Instructions for optional attachments EcoTrikes Instructions on the use of the alarm 1. The first button is the Arm button, when pressing one time gently, the horn will ring one loud, after three seconds, the scooter will be on alert. When touching the scooter firstly,...
  • Page 47 Instructions for optional attachments EcoTrikes sensitivity, there are four sensitivity, one is most sensitive. When getting to appropriate sensitivity, immediately release Find button,the horn will ring one loud and put on alert（the default is third sensitivity.）...
  • Page 48 Instructions for optional attachments EcoTrikes Instructions on the use of the LED undercarriage lighting system When you use the LED system, the head light must be turned on, and then push the LED light switch to “1”, the LED lights will be illuminated.
