Summary of Contents for AMPD IGNT-2
-
Page 1: User Manual
PORTABLE SPEAKER & AMPLIFIER USER MANUAL... -
Page 2: Table Of Contents
USB Charging .........14 Getting to Know the IGNT-2 Night Light Operation What’s in the Box ......4 Night Light Operation .....15 Getting to Know the IGNT-2 ...4 Making EQ Adjustments Powering and Charging the IGNT-2 Making EQ Adjustments ....15 Powering and Charging ....6 Battery Life Indication ......7... -
Page 3: Important Safety Instructions
WARNING! Do not place near any naked flame source, such as lighted candles on the Keep out of reach of young children. This electrical apparatus. apparatus is not suitable for use by young children or infirm persons without supervi- IGNT-2 User Manual Page 2... - Page 4 No liability will be accepted for any personal injury or damage caused by failure to follow these instructions. IGNT-2 User Manual Page 3...
-
Page 5: What's In The Box
WHAT’S IN THE BOX Please check that all appropriate accessories have been supplied. The IGNT-2 includes the following: • IGNT-2 Speaker and Amplifier • Power Cable • Cable Storage Bag • User Manual • Quick Start Guide GETTING TO KNOW THE IGNT-2... - Page 6 GETTING TO KNOW THE IGNT-2 Handle 12. Power ON / OFF Switch 10. Telescopic Pull-Up Handle 13. AC Outlet 11. Battery Level Indication Lights 14. Wheels IGNT-2 User Manual Page 5...
-
Page 7: Powering And Charging The Ignt-2
POWERING AND CHARGING THE IGNT-2 Power Connection Connect the AC cable included with the IGNT-2 to AC power input on the side of the unit. Connect the AC plug to the appropriate 230-240V~50 Hz wall outlet. Press the ON / OFF switch on the side panel of the speaker. -
Page 8: Battery Life Indication
POWERING AND CHARGING THE IGNT-2 Battery Life Indication When the IGNT-2 is not connected to mains power, you can check its battery life by pressing the battery indicator button on the side panel of the speaker. When the IGNT-2 is on low battery, the Low LED will flash red. -
Page 9: Standby Instructions
STANDBY INSTRUCTIONS There is a main power switch on the IGNT-2 which will power the IGNT-2 speaker ON / OFF. The IGNT-2 also has Standby ON / OFF function. Turning Standby ON / OFF To turn Standby ON / OFF, push down on the main volume knob. When in standby mode the green LED light will remain a constant green. -
Page 10: Making A Bluetooth Connection
Note: Once connected, you can increase this distance up to 10 metres. On the top panel of the IGNT-2, press the source button until ‘BT’ is displayed on LED screen. Press the Bluetooth button on the top panel to enter Bluetooth Pairing Mode. -
Page 11: Nfc Pairing
NFC enabled device within centimetres of the NFC area on the IGNT-2. Turn on the NFC function on your selected device. Place your NFC-enabled device on the symbol ‘NFC’ on top of the IGNT-2 speaker. Once a connection is established, the Bluethooth LED light will remain a constant blue. -
Page 12: Pairing Two Ignt-2 Speakers
PAIRING TWO IGNT-2 SPEAKERS The IGNT-2 is equipped with a technology called TWS (True Wireless Stereo) that allows you to dual pair two IGNT-2 speakers together wirelessly. This wireless dual pairing will provide you with true 2.0 stereo (left and right) audio. -
Page 13: Connecting A Guitar Or Microphone
CONNECTING A MICROPHONE OR GUITAR You can connect a guitar and / or microphone to your IGNT-2 speaker directly through the Microphone and Guitar inputs on the top panel. Microphone and Guitar Input: 6.5mm Gain and Echo can be controlled through the individual knobs located on the top panel of the IGNT-2. -
Page 14: Tuning And Storing Fm Radio Stations Manual Tuning
IGNT-2 speaker to manually tune FM radio stations and find your desired frequency. Move the IGNT-2 to find the ideal reception for your selected station / frequency. Use to tune FM Radio Stations... -
Page 15: Storing Fm Radio Stations
FM Radio Station Presets USB CHARGING The IGNT-2 has a built-in power bank that allows you to charge device(s) from either of the two USB ports on the top panel. The combined output of the two USB ports is 2.1 Amps. -
Page 16: Night Light Operation
NIGHT LIGHT OPERATION The IGNT-2 is equipped with white LED lights to help with use in dark environments or at night. Press the button on the top panel to turn on the lights. This will automatically switch on to the lowest brightness level. -
Page 17: Having Issues With The Ignt-2
Ensure there is charge left in the battery. No Sound Make sure the device connected by AUX cable to the IGNT-2 has the volume set to a reasonable level. Make sure the device connected by Bluetooth has the volume set to a reasonable level. -
Page 18: Specifications
Input Sources Bluetooth / AUX / FM / Microphone / Guitar Bluetooth Range 8-10 metres (no obstacles) Power Input 230-240V ~ 50Hz Product Dimensions 42.4 x 52.3 x 22.9 cm Approx Weight 9.5kg Output USB (5V/2.1A) IGNT-2 User Manual Page 17... -
Page 19: Warranty Ignt-2 Warranty
At AMPD, we are always happy to help and discuss any issues or faults that you may have experienced with your product.
