Chassis & Mast
FG15N
EF34L-00011-up
FG18N
EF34L-40001-up
FG20CN
EF34L-60001-up
FG20N
EF17DL-00011-up
FG25N
EF17DL-50001-up
FG30N
EF13FL-00011-up
FG35N
EF13FL-50001-up
For use with S4Q2, S4S and K21/K25 Engine
Service Manuals.
Service Manual
FD15N
EF16D-00011-up
FD18N
EF16D-40001-up
FD20CN
EF16D-60001-up
FD20N
EF18C-00011-up
FD25N
EF18C-50001-up
FD30N
EF14E-00011-up
FD35N
EF14E-50001-up
MC/FC
99719-59110
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mitsubishi FG15N
Summary of Contents for Mitsubishi FG15N
- Page 1 Service Manual Chassis & Mast MC/FC FD15N FG15N EF16D-00011-up EF34L-00011-up FD18N FG18N EF16D-40001-up EF34L-40001-up FD20CN FG20CN EF16D-60001-up EF34L-60001-up FD20N FG20N EF18C-00011-up EF17DL-00011-up FD25N FG25N EF18C-50001-up EF17DL-50001-up FD30N FG30N EF14E-00011-up EF13FL-00011-up FD35N FG35N EF14E-50001-up EF13FL-50001-up For use with S4Q2, S4S and K21/K25 Engine Service Manuals.
- Page 2 FOREWORD This service manual is a guide to servicing of Mitsubishi Forklift Trucks. The instructions are grouped by systems to serve the convenience of your ready reference. Long productive life of your forklift trucks depends to a great extent on correct servicing – the servicing consistent with what you will learn from this service manual.
- Page 3 Mitsubishi forklift truck, are OPERATION & MAINTENANCE MANUAL. outlined in the OPERATION & MAINTENANCE Improper truck operation is dangerous and MANUAL for these trucks. could result in injury or death.
- Page 4 19. Tighten connections to the correct torque. Make 10. Always use tools that are in good condition and be sure you understand how to use them before sure that all heat shields, clamps and guards are performing any service work. installed correctly to avoid excessive heat, vibration or rubbing against other parts during operation.
- Page 5 HOW TO USE THIS MANUAL Truck models covered in this manual: • MC Truck (Mechanical Control System) Mechanically controlled hydraulic system (conventional lever system) • FC Truck (Finger-tip Control System) Electronically controlled hydraulic system MC Truck Lever Control valve FC Truck FC lever box Controller Electric wiring...
- Page 6 HOW TO USE THIS MANUAL (continued) (Removal, Installation, Assembly and Disassembly) Disassembly diagram (example) Procedures are described in the text. Disassembling sequence 209603 Sequence 1 Cover , Bolt, Washer (part name) 2 Snap ring ....(part name) Suggestion for disassembling 1.
- Page 7 Symbols or abbreviation Option R1/4 Taper pipe thread (external) 1/4 inch (formerly PT1/4) Rc1/8 Taper pipe thread (internal) 1/8 inch (formerly PT1/8) G1/4A Straight pipe thread (external) 1/4 inch (formerly PF1/4-A) Rp1/8 Straight pipe thread (internal) 1/8 inch (formerly PS1/8) Units 1.
- Page 8 GROUP INDEX GROUP INDEX Items Model view, Truck models covered, Serial number locations, Dimensions, GENERAL INFORMATION Technical data Fan removal and installation, Fan belt inspection and adjustment COOLING SYSTEM Console box, Chassis electrical devices, Battery maintenance, Electrical ELECTRICAL SYSTEM system schematic Main functions, Service tool functions, Input/output monitor, Error CONTROLLERS codes and troubleshooting...
-
Page 9: Table Of Contents
GENERAL INFORMATION Model View ....................1 – 1 Truck Models Covered ................1 – 2 Serial Number Locations ..............1 – 3 Dimensions ....................1 – 4 Technical Data ..................1 – 5... -
Page 10: Model View
GENERAL INFORMATION Model View MC Truck 210991 FC Truck 210992... -
Page 11: Truck Models Covered
LPG engine models Diesel engine models Truck class Model code - Engine Model code - Engine Truck model Truck model mounted serial number serial number mounted FG15N EF34L-00011-up FD15N EF16D-00011-up S4Q2 1 ton class FG18N EF34L-40001-up FD18N EF16D-40001-up S4Q2 FG20CN EF34L-60001-up... -
Page 12: Serial Number Locations
GENERAL INFORMATION Serial Number Locations 210993... -
Page 13: Dimensions
GENERAL INFORMATION Dimensions 210994... -
Page 14: Technical Data
GENERAL INFORMATION Technical Data Unit: mm (in.) Ref. Model Gasoline-engine FG15N FG18N Truck Diesel-engine (FD15N) (FD18N) Truck Item Maximum lift 3000 (118) Free lift 115 (4.5) Fork spread (outside) 200 to 920 (7.9 to 36.2) Fork length 920 (36.2) Tilt angle (forward – backward) 6°... - Page 15 GENERAL INFORMATION Unit: mm (in.) FG20CN FG20N FG25N FG30N FG35N (FD20CN) (FD20N) (FD25N) (FD30N) (FD35AN) 3000 (118.1) 115 (4.5) 140 (5.5) 150 (5.9) 220 to 1000 (8.7 to 39.4) 250 to 1000 (9.8 to 39.4) 920 (36.2) 1070 (42.1) 6° – 12° 3279 (129.1) 3408 (134.2) 3625 (142.7)
- Page 16 COOLING SYSTEM Specification .................... 2 – 1 Structure ....................2 – 2 Removal and Installation ..............2 – 3 Inspection and Adjustment ..............2 – 5 Fan Belt Inspection ..................2 – 5 Fan Belt Tension ..................2 – 5 Connecting Radiator Hoses ...............
-
Page 17: Specification
COOLING SYSTEM Specification Truck Models 1 ton class 2 ton class 3 ton class Items Type Water-cooled, forced circulation Radiator Corrugated fin (pressure) type Cooling System Water pump Centrifugal type Thermostat Wax Pellet Type... -
Page 18: Structure
COOLING SYSTEM Structure Fan (directly coupled to engine) 209610 Radiator Shroud Hose layout S4Q2 engine Lower hose K21, K25 engines Reservoir tank K21, K25 S4Q2, Upper hose S4S engine 209611... -
Page 19: Removal And Installation
COOLING SYSTEM Removal and Installation Fan Belt Removal Engine 209612 Sequence 1 Tension pulley assembly, Bolt 2 Fan belt Start by: Remove the radiator cover. Suggestion for Removal (1) Loosen the tension pulley lock bolt by three or four turns. If the bolt is loosened insufficiently, the tension pulley will not be moved. - Page 20 COOLING SYSTEM Installation To install, follow the removal sequence in reverse. Also follow the instructions given below. (1) Before installing the belt, turn the fan to check for smooth rotation. Replace the bearing if it generates abnormal sound. (2) After installing the belt, push it to make sure that the tension pulley moves, then tighten the pulley lock bolt firmly.
-
Page 21: Inspection And Adjustment
COOLING SYSTEM Inspection and Adjustment Fan Belt Inspection (1) Check the belt for contamination with oil, grease and dust. Replace the belt if required. When the Fan pulley contamination is slight, remove it clean with rag or wiping paper. Do not use gasoline, oil or any other Tension solvent to clean the belt. -
Page 22: Coolant
COOLING SYSTEM Coolant Fill the radiator with coolant containing antifreeze. Start and operate the engine to let it warm up while checking for abnormal noise. Make sure that the quantity of coolant is as specified by checking the level in the reserve tank. Quantity of coolant Unit: liter (U.S. -
Page 23: Electrical System
ELECTRICAL SYSTEM Chassis Electrical Devices Wiring Outline ........3 – 1 Structure ....................3 – 3 Console box ....................3 – 3 Major Electrical Components ..............3 – 5 Lamp Bulb Specifications ................3 – 17 Console Box ..................... 3 – 18 Disassembly .................... -
Page 24: Chassis Electrical Devices Wiring Outline
ELECTRICAL SYSTEM Chassis Electrical Devices Wiring Outline (No. 1) Main harness Harness, rear combination Harness, front combination Harness, front combination 209620... - Page 25 ELECTRICAL SYSTEM Chassis Electrical Devices Wiring Outline (No. 2) Starter switch Main harness Harness, Rear combination Select switch Warning buzzer Back buzzer Harness, Front combination Controller Clip Battery seat Horn Connector bracket Harness, Front combination Fuse box, Fuse Relay box, Relay Vehicle speed sensor (Pulse generator)
-
Page 26: Structure
ELECTRICAL SYSTEM Structure Console box 1 Water temperature gauge 2 Fuel gauge 3 Various warning lights 4 Instrument panel 5 Starter switch 6 Lighting switch, turn signal switch 7 Forward-reverse lever 209622... -
Page 27: Instrument Panel
ELECTRICAL SYSTEM Function of Instrument Panel L1 L 209623 Description of function When illuminated Code Name of monitor When not illuminated Remarks or flashing Brake fluid level warning lamp Normal level Low level ATM: Torque converter fluid temperature warning lamp Normal temperature Overheat ATM truck... - Page 28 ELECTRICAL SYSTEM Major Electrical Components Starter switch The diesel-engine turck, which uses a disributor type injection pump, is provided with an engine automatic sop mechanism of the fuel cut system by the starter switch. The gasoline-engine truck is also provided with an engine automatic stop mechanism of the fuel cut system. Starter switch (with Anti-Restart Lock) This switch has a built-in anti-restart lock, so the key cannot be turned from (ON) to...
- Page 29 ELECTRICAL SYSTEM Lighting switch and turn signal switch Lighting and turn signal lever Boot Horn contact Steering angle sensor Boot Forward-reverse lever Forward of truck Lighting switch, turn signal switch 209625 Forward of truck Lighting switch, turn signal switch Forward-reverse selector switch 209626 Lighting switch and...
- Page 30 BUY NOW Then Instant Download the Complete Manual Thank you very much! ...
