Summary of Contents for JKEXER Acute 3925
- Page 1 RACING BIKE Acute 3925 SEMI-COMMERCIAL Owner's Manual Made in Taiwan...
-
Page 3: Table Of Contents
INDEX IMPORTANT SAFETY INFORMATION . . . . . . . . . . . . . . . P . 2 ASSEMBLY PARTS LIST . . . . . . . . . . . . . . . . . . . . . . P . 3 ASSEMBLY INSTRUCTION . -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATIONS WARNING: Before starting any exercise program, it is recommended that you consult your physician, especially for persons with pre-existing health problems . Before using the new equipment, please review this manual to learn about the features, functions, and safety operations . -
Page 5: Assembly Parts List
Assembly Parts List ASSEMBLY PARTS LIST 1 . MAIN FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 . -
Page 6: Assembly Instruction
Assembly Instruction MAIN FRAME MAIN FRAME FRONT STABILIZER REAR STABILIZER Step 1 Step 2 Secure REAR STABILIZER to MAIN Secure FRONT STABILIZER to MAIN FRAME using allen head bolts . FRAME using allen head bolts . SEAT STOPPER SEAT POST SEAT SEAT POST SLIDER... - Page 7 Assembly Instruction HANDLEBAR HANDLEBAR POST HANDLEBAR POST MAIN FRAME Step 5 Step 6 Insert HANDLEBAR POST into front top Securely fix the HANDLEBAR to the top of the MAIN FRAME , fixed by knob . of HANDLEBAR POST by using BOLT and WASHER(A) .
-
Page 8: Operating Instruction
Operating Instruction RESISTANCE ADJUSTMENT: Pedalling resistance is controlled by the tension knob located under the handlebar. To increase resistance, turn the tension knob clockwise. To decrease resistance, turn the tension knob counter clockwise. SPECIAL NOTICE: Every time before riding, make sure both pedals are securely tightened. After finishing riding, use a dry rag to clean sweat and dust off for the whole unit. -
Page 9: Chain Adjustment
Operating Instruction LEVELING: After completing the installation, if the floor/equipment is not even, turn the FOOT PAD to the desired level in order to balance the frame. CHAIN ADJUSTMENT: The chain on this bike has been pre-adjusted and should not require immediate attention. -
Page 10: Parts List
Parts List No . Description Q'ty No . Description Q'ty Frame Tension Knob M8x50L Flywheel Ø460x19kg Emergency Brake Bushing Ø12.7x56.5L Rubber Washer Axle Butterfly Nut Bearing #6000 Nut M8 Washer Ø18xØ8x3.7T Brake Cable Nut 3/8'x26x17x4T Caliper Brake Washer Ø10xØ20x3T Brake Pad Screw M6x57L Screw M6x18L Washer M6x13... -
Page 11: Exploded Drawing
Exploded Drawing... - Page 12 Factory: JIH KAO ENTERPRISE CO ., LTD...
