INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE
AND FREE STANDING UNITS
FS-26-922
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sierra Flame FS-26-922
Summary of Contents for Sierra Flame FS-26-922
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR ZERO CLEARANCE AND FREE STANDING UNITS FS-26-922 SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Sierra flame product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................3... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3. -
Page 4: Grounding Appliance
GROUNDING APPLIANCE This appliance is for use on 120 Volts. The cord has a plug as shown in (A). An adapter as shown in (C) is available for connecting three-blade grounding type plugs to two-slot receptacles. The green grounding lug extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box. -
Page 5: Fs-26-922
FS-26-922 This appliance has been tested in Description Free Standing Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1500W Max electric room appliances in the United NO HEATER States and Canada. If you need... -
Page 6: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. -
Page 7: Media Options
MEDIA OPTIONS Your fireplace shipped with the following media: 3 bags of sable glass and an 11 piece log set. Customers decorate their fireplace according to their wishes with supplied media. This fireplace includes the following decorative media: The glass panel is hooked by 2 hooks on each side. -
Page 8: Operation
OPERATION The fireplace can be operated either by the switches located on the left front of the fireplace unit or by supplied remote control. MANUAL OPERATION Push to reveal the manual control panel. (As shows in bellow picture) Push here to open the manual control panel 1. -
Page 9: Remote Control Operation
NOTE: If operated at the Low heat setting, the fireplace will not provide as much heat output as in the High heat setting, however the low setting will not require as much electrical power to operate. To avoid overloading a circuit, do not plug the fireplace into a circuit that already has other appliances working. -
Page 10: Installing Wall Thermostat
FLASH button: Switches mood light into flash mode, this cycles through all mood light colors. HEATER ON/OFF button: Switching the heater ON/OFF. It has functions of setting memory. HIGHT button: Press the high button to switch the heater to high heat setting 1500W. LOW button: Press the low button to switch the heater to low heat setting 750W. -
Page 12: Replacement Parts
REPLACEMENT PARTS This list contains replacement parts PART NUMBER DESCRIPTION QTY. 10701213 FRONT CLEAR GLASS (MIDDLE) 10701214 FRONT CLEAR GLASS (SIDES) 10702166 BOTTOM GLASS BACK BLACK PLASTIC GLASS 3126010 10104002 SWITCH 3126512 FLICKER ASSEMBLY 10101201C FLAME MOTOR 601137B LED STRIP FOR TRAY 601136B LED STRIP FOR FLAME 3001506B... -
Page 13: Exploded View
EXPLODED VIEW... -
Page 14: Wiring Diagram
Wiring Diagram... -
Page 15: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Back black cloth is falling off Change a flicker and back black cloth. and rolled up in the flicker Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 16: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
