Summary of Contents for Warm Audio WA-2A
- Page 7 600 ohms impedance pin 2/tip=positive, pin line level, transformer 3/ring=negative, pin 1/sleeve=ground balanced input 600 ohms impedance pin 2/tip=positive, pin line level, transformer 3/ring=negative, pin 1/sleeve=ground balanced output frequency response +/- 1 DB, 15 HZ TO 20KHZ +40 dB ±1dB maximum gain -40 dB ±3dB maximum peak reduction...
