Divus VIDEOPHONEBOX User Manual page 13

To save the changes made in this menu click on "Submit"; the VoIP gateway will reboot and will then be reachable
on the new IP address.
Note: The default line is Line 2.
Proxy
VoIP server (for example 192.168.0.100).
Display Name User ID
to register on the VoIP server, must be specified. These parameters must all use the same value; you can freely
choose between the pre-defined values 901, 902, 903, 904, 905, 906, 907, 908, 909, 910. Nevertheless, it is
recommended to start with 901. Those values stand for the 10 pre-configured external intercom units supported
by Videophone.
Dial Plan this is the string through which the VoIP server is informed about which destination device to call
when a button is pushed. The first thing to know is whether the outdoor station in use is capable of sending no,
one or more 3 digit numbers when pushing its button(s).
1. It can send one number only (or none). In this case, the number to call can be inserted directly into the
a. For DIVUS VS1 with IP address 192.168.0.123 the string to insert is
<S0:dooropener0111@192.168.0.123>
b. For DIVUS KNX Server with IP address 192.168.0.234 the string to insert is
<S0:111@192.168.0.234>
2. It can send 2 or more 3 digit numbers (like e.g. Siedle). In this case the outdoor station has to be
configured to call the 2 (or more) chosen numbers using its own setup software or web interface.
Password
DIVUS Videophone-Box User Manual .
or the IP address of the
13
