- Page 1 VARIFOCAL DAY/NIGHT MINI VANDAL-PROOF DOME CAMERA USER MANUAL VSXR-508DV...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 DISTRIBUTED BY...
-
Page 4: Specifications
⊙ Specifications SIGNAL SYSTEM NTSC TOTAL / EFFECTIVE PIXEL 410K / 380K Pixels 470K / 440K Pixels IMAGE SENSOR 1/3” SONY interline transfer CCD HORIZONTAL RESOLUTION 540 TV Line MINIMUM ILLUMINATION 0.3 Lux /F 1.2, 0.05Lux with Sensitive Up (Auto) 3.7 mm Manual Lens 4-9mm Auto Iris Lens LENS... - Page 5 ■ Precautions Only use the camera in conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting changes or flicker from It is one of the most important parts of fluorescent lights can cause the camera the camera.
- Page 6 ⊙ Features Horizontal Resolution 540 TVLines Clear image quality has been achieved by employing a SONY CCD with 410,000 (effective) pixels, which provides a horizontal resolution of 540 TV lines. Electronic IRIS The electronic IRIS function enables continuous automatic control of the shutter between 1/60~1/120,000 seconds.
- Page 7 ⊙ Cable Connection POWER VIDEO ⊙ Dimensions...
-
Page 8: Assembling The Camera
⊙ Assembling the Camera Dome cover to protect the camera Camera lens There are 2 screws to adjust the angle of the camera. There are 3 holes to mount camera on a ceiling or wall... - Page 9 * How to install the camera ① Mount the camera body on a ceiling or wall via the 3 mounting holes. ② Loosen the two screws to adjust the angle of the camera. ③ Position the camera lens to the desired position and retighten the 2 screws.
