Remote Control Button Locations and Functions

POWER
1
MENU
2
3
VOL
SETUP
TONE
4
VOL
5
VOL
6
DISP
7
SEEK SCAN
8
9
1
EQ
10
4
BAND
AS/PS
11
7
ELAPSE
12
AUDIO SUB.TT
13
1. Power On/Off Button (
unit on or off.
2. Menu Button: Press to access the Menu screen
in movie mode.
3. Sound Control Button (VOL/TONE): Press to
select the sound controls: Bass, Treble and
Balance.
4. Setup Button: Displays the on-screen SETUP
menu.
5. Volume Buttons (VOL
to increase or VOL
VOL
volume level.
6. Display Button (DISP): Press to toggle through
the available display information.
7. Radio SEEK Button: Press and the tuner will
seek up to the next strong station and stop.
8. Radio SCAN Button: Press this button and the
tuner will scan up to the next strong station,
pausing for 10 seconds at each station. Press the
button again to cancel the scan function.
9. Equalizer/Loudness Button (EQ): Press to select
between the preset sound equalization settings.
Press and hold the button to boost high and low
tones at low volume levels (loudness).
10. Band Button: Press to select the radio mode.
Sequential presses will select radio band:
FM 1, FM 2, FM 3, AM 1 or AM 2.
14
MODE MUTE
15
16
17
18
19
20
ENTER
21
22
ZOOM SLOW
23
2 3
5 6
24
8 9
10 +
10/0
): Press to turn the
/ VOL ): Press
decrease the
11. AS/PS Elapse Button:
Radio: Automatic radio station memory storing
(AS) and Preset radio station scanning (PS).
(See "AM/FM Operation" for more details).
Disc: Press to display movie information.
12. Audio Button: Press to select appropriate movie
audio/language setup.
13. Subtitle Button (SUB.TT): Press to access the
movie disc's subtitle languages.
14. Mute Button: Press to mute the volume level.
Press again to restore the volume.
15. Mode Button: Press to select between the
different modes: Radio, Disc, Auxiliary, and
BT Audio Input .
16. Stop Button ( ): Press to stop disc or
BT play.
17. Play/Pause Button (
or BT play, press again to resume play.
18. Backwards (
Disc Play: Press
X 2" appears in the display and the disc
will play backwards at 2 times the normal
speed. Press again and "BACKWARD X 4"
will appear. X8 and X20 speeds can also be
selected. Fast Forward
same way but fast forward. Press the
button at any time to resume normal play.
BT Mode: Press to search for the beginning of
previous track or next track.
19. Enter Button: Executes the selected item.
20. Navigation Buttons (
feature selection up, down, left or right.
21. Down ( ), Up (
Radio Mode: Press to manually tune the radio
to a lower or higher frequency.
Disc Mode: Press to search for the beginning
or next track or chapter.
BT Mode: Press to search for the beginning of
previous track or next track.
22. Slow Button: Press to play the movie in
slow motion.
23. Zoom Button: Press to enlarge or reduce the
movie's on-screen image.
24. Numeric Buttons (1, 2, 3, 4, 5, 6, 7, 8, 9,
10/0 and 10+)
): Press to pause disc
) or Fast Forward (
and "BACKWARD
button works the
, , , ): Moves
) Buttons:
)
5
